Summary of Contents for Shuangdie SD-36VB-500W
- Page 1 Isolation transformer Model: SD-36VB-500W SD-36VB-1000W Instruction Manual Please read the instructions carefully before use.
- Page 2 The transformer must be applicable to the security of power supply voltage for the ship building and repairing, boiler manufacturing, enterprise etc. also the transformer is provide to the 36V safely series axial-flow ventilator of SHUANGDIE Brand. The transformer have the characteristics of a solid structure, overloading ability, safety and durable etc.
- Page 3 Ⅲ.ELECTRIC SCHEMATIC DIAGRAM 1. Connect the shore cable to the terminals indicated with “INPUT”. 2. Connect the load to the terminals indicated with “OUTPUT”.
