BRUKSANVISNING I ORIGINAL för /
Translation of ORIGINAL INSTRUCTIONS for
Magnetlyft / Permanent Lifting Magnet
SVENSKA/ENGLISH
Forankra AB
Box 100, SE-44723 Vårgårda, Sweden. Besöksadress: Verkstadsgatan 2
Tel: +46 (0)322 667800. Fax: +46 (0)322 667810.
www.forankra.se
Forankra AB is part of Axel Johnson International
Type PLM
PLM 100
PLM 300
PLM 600
PLM 1000
PLM 2000
info@forankra.se
P/N 240910006
P/N 240910007
P/N 240910008
P/N 240910009
P/N 240910010
Rev 201712

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLM 100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Forankra PLM 100

  • Page 1 P/N 240910008 PLM 1000 P/N 240910009 PLM 2000 P/N 240910010 Rev 201712 SVENSKA/ENGLISH Forankra AB Box 100, SE-44723 Vårgårda, Sweden. Besöksadress: Verkstadsgatan 2 info@forankra.se Tel: +46 (0)322 667800. Fax: +46 (0)322 667810. www.forankra.se Forankra AB is part of Axel Johnson International...

  • Page 2: Table Of Contents

    Läs igenom denna bruksanvisning innan Magnetlyften tas i bruk. Spara bruksanvisningen i nära anslutning till bruksplatsen för konsultation vid behov. Felaktig användning kan innebära fara. Read this manual before using the lifting magnet. Keep this instructions in close proximity to the work station for consultation if necessary.

  • Page 3: Specifikationer Specifications

    Huvudmått / main dimensions (Kg) Modell/ belastning Vikt/weight model Rundstål / /Test max (kg) Flat plåt / Plate pull of Round steel force (kg) PLM 100 30-50 PLM 300 90-150 1050 12,4 PLM 600 180-300 2100 23,6 PLM 1000 1000 300-500...

  • Page 4: Handhavande Och Användning Operation And Usage

    Handhavande och användning / Operation and usage 1 Utgångspunkten är placering enligt figuren nedan 1 The starting position is according to the drawing above. 2 Före användning, uppskatta lyftkapaciteten enligt omvandlingsekvationen ovan, baserat på ytråhet (Fx), stålmaterial (Mx) och den permanenta lyftmagnetens lyftkapacitet. Överbelastning är förbjuden. 2 Before operation, estimate the hoisting capacity of the permanent magnetic hoisting machine according to the above- mentioned conversion equation based on the flatness roughness(Fx), Material of the steels (Mx) and the hoisting capacity.Overloading is prohibited.

  • Page 5: Säkerhetsanvisningar

    Användning / Use 7 Kontrollera magnetens skick före varje användning. Torka grundligt av magnetens polskor och arbetsstyckets kontaktyta. Fila bort eventuella spånor/ojämnheter 7 Check the condition of the magnet each time before use. Wipe the pole shoes on the magnet and the contact surface of the workpiece clean.

  • Page 6: Safety Instructions

    Safety instruction Faulty handling or use can lead to injury of persons and/or damage to equipment/property. • Never use this magnet before these instructions have been read and understood. • Persons fitted with a pacemaker or other medical equipment should never use the magnet without first consulting a medical specialist.

  • Page 7: Förvaring Storage

    Annually Have the lifting capacity of your magnet checked by your supplier or an authorised agent at least once a year Förvaring / Storage Förvaras torrt / Keep stored in a dry environment. Beskrivning / description Passar / Fits to Forankra AB P/N PLM 100 240910011 Reservdel Magnetlyft PLM | PLM 300...

  • Page 8: Eg-Försäkran Om Överensstämmelse

    Forankra AB takes no responsibility for the product if the buyer/user, anyone appointed by any of them or anyone else make any kind of changes on the product without permission from Forankra AB.

This manual is also suitable for:

Plm 300Plm 600Plm 1000Plm 2000240910006240910007 ... Show all
