Summary of Contents for decakila KEEN005W
- Page 1 说明书材质要求:105g铜版纸过哑油 说明书成品尺寸: 175x120mm 第一:CMYK油墨要求：单色黑 第二：特别注意： 1.印刷时看样请参考我司提供的实物样品颜色。不得偏色 black （单色印刷） 折叠方式：骑马钉 备注: 特别注意：此页内容不印刷,也不用保留...
- Page 2 KEEN005W GARMENT STEAMER...
-
Page 4: Table Of Contents
CONTENTS PRODUCT INTRODUCTION PRECAUTIONS NOTICES PRODUCT VIEW PARAMETERS PRODUCT INSTALLATION PRODUCT OPERATIONS PRODUCT MAINTENANCE FAULT RECOVERY... -
Page 5: Product Introduction
PRODUCT INTRODUCTION FEATURES AND PURPOSE: Thank you for choosing our Garment Steamer. The device is a kind of strong steam ironing machine with cleaning function as a supplement. It is elegant in design, simple, economical and safe, especially applicable for household, garment, wedding dress, curtain, sofa, hotel, restaurant, etc. The machine irons especially well the pure silk, woolens, chemical fiber, cotton and blending textiles, flattens them fast without damage and also sterilizes and cleans them. -
Page 6: Notices
Only use the detachable accessories when there is no steam and they are cooled down to avoid scalds. Conduct the installation in accordance with the instructions. Do not dismantle without authorization. The liquid or steam must not be directed towards equipment containing electrical components, such as the interior of ovens. NOTICES Do not operate the machine unless you read this manual thoroughly. - Page 7 Keep power cords and steam pipes from metals or other heating elements. Do not leave the machine operating without attention. The machine shall not be operated by these people (including children): the physically, tactilely or mentally disabled or those who lack of experience and knowledge, unless they are supervised or guided by someone who is responsible for their safety in respect of the application of the machine.
- Page 8 Push the support pole to move the machine. Do not move the machine by force when it is tough to be moved. Discharge the water before checking the wheels. Turn off the power supply and pull out the plug before moving the machine. Turn off the power supply and pull out the plug before discharging water from or filling water in the tank.
-
Page 9: Product View
PRODUCT VIEW Do not pull or plug the plug with wet hand in respect of electric shock. Built in fur brush Iron brush Keep away from the steam hole to avoid burn. Hook Keep it away from the children or others unable to operate. -
Page 10: Parameters
PARAMETERS Product type: Power: 1600W Voltage: 220-240V~ 50/60Hz Steam pressure: 1.0bar Steam flow: 35±3g/min (max) Tank capacity: 1400ml Executive standard: KEEN005W... -
Page 11: Product Installation
PRODUCT INSTALLATION 1. unpack the machine and stretch the power cord. 2. Take out the support pole, (as shown in picture), pull out the Pole 3, screw it clockwise into Pole 4, then pull out the pole 2, screw it clockwise into pole3, the last pull out the pole 1, screw it clockwise into pole 2. -
Page 13: Product Operations
PRODUCT OPERATIONS 1. Stand the machine assembled on flat and stable floor. Adjust the height and spread range of the hanger as required and hang the clothes on it. Ensure there is enough water in the water tank and the tank is located properly. Notice: when you take out the water tank, please press the water tank removable button and then take out the water tank. - Page 14 Insert the electrical plug into the suitable power socket, open the power switch and let the machine preheat for about 45s, waiting for steam of ironing brush.. According to the different materials chosing the different gears. Notice: Do not iron the clothes immediately when the steam is out. Because there are some water drop at first. Iron the clothes after the machine working for 15s.
- Page 15 Put on the gloves before ironing. Presentation: Press gently the metal panel of ironing brush on the clothes, move the brush up and down at such a speed that the steam penetrates into the fibers appropriately for hot forming. Do not move so fast and the steamer will permeate to the fiber to finalize the design.
-
Page 16: Product Maintenance
PRODUCT MAINTENANCE 1. Purified water is recommended in order to avoid contaminating the textiles. The contents of mineral substance differ in various kinds of water, so there would be sediments to respective extents if the ironing machine is applied with water of different qualities, which makes the steam flow lessens, intermits or even stops. Purified water is recommended in order to avoid contaminating the textiles. - Page 17 Clean the machine frequently to keep the best function. Thus clean every 1 month which period may be prolonged or shortened according to the actual water quality. Maintenance steps: Close the steam first and pull out the power code. After one hour to cooler the machine and then begin to maintain the machine. Please ensure that the water is over the least water line and put the product aside the water outlet.
- Page 18 3. Storage Keep the machine in a dry, cool and ventilated place and away from flammable and explosive objects. Keep properly the hood of connecting hole and put it back when pulling out the ironing brush after the work is done, in order to prevent water and dust away from the connecting hole.
-
Page 19: Fault Recovery
FAULT RECOVERY Fault Recovery Fault Cause Solution Power-off or fusion of fuse Check and confirm The socket is not connected or plugged in Connect to the power supply and ensure properly the plug is plugged in thoroughly The machine does not work or the indicator light of switch is not lighted Unfavorable connection of socket Check whether the power socket is normal... - Page 20 There is no steam when the machine is Clean the machine Maintain the machine accordingly working The water in water tank does not reach the Fill water promptly designed water level The sound is loud in machine Clean the machine Maintain the machine accordingly Back water sound is frequently Overflow of water tank...
- Page 21 User guide decakila decakila Made in China Jiangsu China. 2021.D01 www.decakila.com Global Links Technology Co. Pte. Ltd.
