Daytona bemodern User Instructions

Daytona Users Instructions
User's Instructions for Fan Heater Model with Thermostat control.
These instructions should be read carefully and retained for future reference.
Important Notes
•
For the fitting of the fire in the surround please see the instructions supplied with the surround
•
These Instructions should be read carefully and retained for the future reference.
•
This heater must not be located immediately below a fixed socket outlet.
•
Do not use the heater in the immediate surrounds of a bath, a shower, or a swimming pool.
•
Do not cover this heater, or obstruct the air inlet or outlet, otherwise there is a risk of overheating.
•
Do not stand the fire on the carpet – stand on a firm surface which projects 250 mm (10 inches) beyond the front of the fire and is free
of dust and lint.
•
Certain carpets can be discoloured by heat. Ensure that furniture, curtains and other combustible materials are positioned no closer
that 1m from the front of the fire.
•
On heaters where the supply cord passes through a slot in the side of the casing, alternative positions are provided in the other side.
•
This heater must be placed against a vertical surface i.e. back panel against a fireplace.
•
Under no circumstances should the heater be used as a free standing appliance.
•
During normal operation this appliance will emit noise from the internal fan unit.
•
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
Warning: This appliance must be earthed.
The wires in the mains lead connected to this appliance are coloured in accordance with the following code:
GREEN and YELLOW
BLUE
Brown
As the colour of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
•
The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is marked with the letter E or by the
earth symbol or coloured Green or Green and Yellow.
•
The wire which is coloured Blue must be connected to the terminal which is marked with the letter N or coloured Black.
•
The wire which is coloured Brown must be connected to the terminal which is marked with letter L or coloured Red.
Fire Installation
Unpack the heater carefully and retain all packaging for future use. Ensure that all packing items are moved and read any warning labels
carefully (see Maintenance Section).
If the fire is to be installed in front of an existing chimney opening and there is any risk of chimney debris falling down onto the fire it
is recommended that before installation the flue or opening is sealed off with non-combustible non-fibrous insulation materials. Do
not install into an existing fireplace that is prone to dampness. Should it be
necessary to cap and seal the chimney to prevent personal injury, a
professional should be hired to do the work.
The appliance must be positioned so that plug is accessible. Only when you
are certain that you have completed the installation should you plug in and
switch on at the wall socket.
Preparation for Use.
Check that the supply voltage details on your fuel effect fire are in accordance with
your electricity supply. Your fire is fitted with a plug incorporating a 13 Amp fuse.
In the event of replacing the fuse in the plug supplied, a 13 Amp fuse approved by
ASTA to BS 1362 must be used. Before switching on, please read the following
operation instructions:
Safety Thermal Cut-out
The appliance is fitted with an Electric Safety Control (E.S.C). This is a safety
device, which switches off the fire if for any reason, the appliance overheats. The
E.S. Control will only be re-set after the appliance has cooled down, in order to re-
set the E.S. Control proceed as follows:
•
Switch off the appliance and leave for approximately 5-10 minutes.
•
Switch on the appliance and E.S. Control should normally re-set. Ensure that
the appliance is functioning correctly.
Daytona Electric Fire
Earth
Neutral
Live
