Service Manual
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not
contain warnings or cautions to advise non-technical individuals of potencial dangers in attempting to service a product. Products
powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or repair the
product or products deal within this service information by anyone else could result in serious injury or death.
There are special components used in this equipment which are important for safety. These parts are marked
Schematic Diagrams, Circuit Board Diagrams, Explorer Views and Replacement Parts List. It is essential that these
critical parts should be replaced with manufacturer´s specified parts to prevent shock, fire or other hazards. Do not
modify the original design without permission of manufacturer.
Warning
IMPORTANT SAFETY NOTICE
ORDER No. PCZ1604118CE
LED TV
TX-55DX650B
LA64 Chassis
in the
© Panasonic Corporation 2016.
Unauthorized copying and
distribution is a violation of law.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TX-55DX650B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic TX-55DX650B

Summary of Contents for Panasonic TX-55DX650B

  • Page 1 Schematic Diagrams, Circuit Board Diagrams, Explorer Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer´s specified parts to prevent shock, fire or other hazards. Do not modify the original design without permission of manufacturer. © Panasonic Corporation 2016. Unauthorized copying and distribution is a violation of law.

  • Page 2: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ........... 3 SCHEMATIC DIAGRAMS NOTE ......60 GENERAL GUIDE LINES ........3 A-BOARD (1 OF 16) SCHEMATIC DIAGRAM ..61 TOUCH – CURRENT CHECK ....... 3 P-BOARD (1 OF 3) SCHEMATIC DIAGRAM .... 77 PREVENTION OF ELECTROSTATIC DISCHARGE K-BOARD SCHEMATIC DIAGRAM ......

  • Page 3: Safety Precautions

    Safety Precautions General Guide Lines When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.

  • Page 4: Devices

    Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor "chip"...

  • Page 5: About Lead Free Solder (Pbf)

    About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu). That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.

  • Page 6: Service Navigation

    Service Navigation Chassis Board Layout P-BOARD A-BOARD K-BOARD Board Name Function A-Board AV Terminal, HDMI, USB, WIFI, Ethernet, Digital Audio Out, CI Slot, INTEGRATED TUNER A/DVB-T2/T/C, DVB-T2/T/C Dem, Peaks IC_MTK, Speaker out, HP, eMMc Memory, DDR SDRAM P-Board Main Input, Power Supply, LED Driver, KEY Control, Power Switch K-Board Remote Receiver, Power and Timer LED, C.A.T.S...

  • Page 7: Service Hints

    Service Hints How to remove the pedestal assembly How to remove the backcover Lay the main unit face down. (see Fig.5) Fig.5 Remove the 4 fixing screws and Pedestal assembly. (see Fig.6) SCREWS (1) THE5ZL002N /4pcs/ Fig.6 Remove the 27 fixing screws and the back cover. (see Fig.7) SCREWS (2) THEC1509 /21pcs/ (3) THTD037J /6pcs/...
  • Page 8 Service Hints Preparation of replacement of LCD panel Remove screws and Metal Bezel out of replacement panel according to specifications bellow. Unscrew and remove Metal Bezel from LCD panel (see Fig.8,Fig.9) Note: Be careful to damage edge of LCD panel by remove of Metal Bezel! Screws and Metal Bezel not to use for further.
  • Page 9 Service Hints Assembly of LCD panel and cabinet assy Insert and screw cabinet assy to LCD panel in order according to specification bellow. (see Fig.10,Fig.11) Cabinet Assy Top side of LCD panel LCD panel Fig.10 10pcs Front View 5pcs 5pcs 8pcs Fig.11 SCREWS...

  • Page 10: Applicable Signals

    Applicable Signals Component (Y, Pb, Pr) (from AV terminal), HDMI Signal name COMPONENT HDMI 525 (480) / 60i,60p 625 (576) / 50i, 50p 750 (720) / 60p, 50p 1,125 (1,080) / 60i, 50i 1,125 (1,080) / 60p, 50p, 24p 3,840 x 2,160 / 60p, 50p, 30p, 25p, 24p 4,096 x 2,160 / 60p, 50p, 30p, 25p, 24p Note: ...

  • Page 11: Specifications

    CATV S1-S20 CATV S21-S41(Hyperband) PAL 525/60 (AV only) M.NTSC (AV only) NTSC (AV only) Aerial - Rear: TX-55DX650B (UK) TX-55DX650B (Ireland) VHF/UHF 0°C  35°C Operating Conditions: Temperature: 20%  80% RH (non condensing) Humidity: Terminals: AV IN (COMPONENT/VIDEO) VIDEO Video (RCAx1) 1V p-p 75...
  • Page 12 Audio Output: 20W (10W + 10W) Headphones: 3.5mm, 8 Impedance Accessories supplied : Remote Control 2 x R6 Batteries Dimensions: Width: Height: Depth: Including TV stand 1,244mm 776mm 364mm TV set only 1,244mm 723mm 69mm Mass: Including TV stand 21.0kg TV set only 18.0kg Design and Specifications are subject to change without notice.

  • Page 13: Technical Description

    MTK for MTK for MTK HDMI HDMI TX-55DX650B USB HDD Recording: General information: Digital TV programmes can be recorded in USB HDD. C2MOD key generated in A-board by SELF CHECK binds TV and USB-HDD for communication. That key is only one key for them. If the key is different, TV can not access USB-HDD.

  • Page 14: Setting Inspection

    Setting Inspection Voltage Confirmation A board Description Test point Voltage PNL12V TP4059 12V ± 1.2V USB5V TP5241 5.17V ± 0.25V USB1 TP8705 5.00V ± 0.25V USB2 TP8711 5.00V ± 0.25V USB-WiFi TP8718 5.14V ± 0.20V SUB3.3V TP5201 3.33V ± 0.15V HDMISW3.3V TP4514 3.35V ±...

  • Page 15: Cs Maintenance Menu

    CS Maintenance Menu MPU controls the functions switching for each IICs through IIC bus in this chassis. The following setting and adjustment can be adjusted by remote control in Service Menu How to enter into CS Maintenance Menu Purpose After exchange parts, check and adjust the contents of adjustment mode. While pressing [VOLUME ( - )] button on the main unit, press the [RED] button on the remote control for 3 times within 2 seconds.
  • Page 16 EDID Clock 1.Select [EDID CLK] in CS Maintenance Menu. 2.Press [OK] button or Cursor key [Right] on the remote control. CS Maintenance Menu EDID-CLK S-HIGH EDID CLK Clock speed DRV CHECK HDMI HDMI Number WB-ADJ Exit: Press the [EXIT] button or the [RETURN] button on the remote control. DRV Check (USB HDD Drive Check) 1.Select [DRV CHECK] in CS Maintenance Menu.

  • Page 17: System Information

    System Information How to access While pressing [MENU] button on the remote control. To select [ Help] and then to select [System Information].(see Fig.12, Fig.13) Sample only Fig.12 Fig.13 System Information SW version 3200-10000 3200 Peaks SW 10000 STBY SW Status1 0d 7301-0003 0000-0100 Outer model ID...

  • Page 18: Hotel Mode

    Hotel Mode 1. Purpose Restrict a function for hotels. 2. Access command to the Hotel mode setup menu. In order to display the Hotel mode setup menu, please enter the following command (within 2 second). [TV] : Vol.[Down] + [REMOTE] : AV (3 times) Then, the Hotel mode setup menu is displayed.

  • Page 19: Data Copy By Usb Memory

    Data Copy by USB Memory Purpose a) Board replacement (Copy the data when exchanging A-board): When exchanging A-board, the data in original A-board can be copied to USB Memory and then copy to new A-board. Following data can be copied. (Before exchanging) User setting data Copy to USB Memory...

  • Page 20: Data Copy From Tv Set To Usb Memory

    Data Copy from TV set to USB Memory Turn on the TV set. Insert USB Memory with a startup file (pwd file) to USB Terminal. On-screen Display will be appeared according to the startup file automatically. Input a following password for (a) or (b) by using remote control. (a) For Board replacement: 2770 (b) For Hotel: 4850 Data will be copied from TV set to USB Memory.

  • Page 21: Data Copy From Usb Memory To Tv Set

    Data Copy from USB Memory to TV set Turn on the TV set. Insert USB Memory with Data to USB Terminal. On-screen Display will be appeared according to the Data folder automatically. Input a following password for (a) or (b) by using remote control. (a) For Board replacement: 2771 (b) For Hotel: 4851 Data will be copied from USB Memory to TV set.

  • Page 22: Option Bytes Description

    Option Bytes Description OPTION1 TEXT Ch Refresh ON (1) / OFF (0) ID-1 ON (1) / OFF (0) Macrovision Auto-judge ON (1) / OFF (0) Reserved Enable HDMI force reset ON (1) / OFF (0) Reserved OPTION2 Adjust Igain enable ON (1) / OFF (0) A2 BG enable (5.5MHz) ON (1) / OFF (0)

  • Page 23: Self Check

    While pressing [VOLUME ( - )] button on the main unit, press [MENU] button on the remote control for more than 3 seconds. How to exit Switch off the power with the [POWER] button on the main unit. TX-55DX650B Self Check Complete H14TUN O.K.

  • Page 24: Power Led Blinking Timing Chart

    Power LED blinking timing chart Subject Information of LED Flashing timing chart. Contents When abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the defective block can be identified by number of blinking of the Power LED on the front panel of the unit. Blinking Blinking timing Contents...

  • Page 25: Wiring Diagram

    Wiring Diagram LCD PANEL P-BOARD KEY CONTROL K-BOARD...

  • Page 26: Block Diagram (1 Of 2)

    SP_R SP_L Block Diagram (1/2) JK8703 JK8705 JK8702 TO K10 JK6400 ETHERNET USB2 WIFI USB1 CI SLOT JK8600 17,18 51,52 2,3 5,6 SUB3.3V IC6800 10,11 14,15 26,27 30,31 DMD_1.2/1.1V AGC1 [C1AB00004028] DVB-T/T2/C DEM IC3800 FEF_FLAG 9,16 [C1AB00003984] 25,32 3,4,5,8 IC8920 AUDIO AMP TSVAL T8600...
  • Page 27 Block Diagram (2/2) TO A02 P-BOARD SW2851 SW2852 SW2853 SW2854 SW2855 Q7203 D7105 K-BOARD RM2800 D7104 STBY 3.3V REMOTE SUB3.3V SN2800 R LED G LED STBY 3.3V STBY 3.3V SUB3.3V REMOTE D2802 R LED G LED MAIN INPUT TO PANEL TO PANEL...

  • Page 28: Parts Location

    Parts Location Bottom View Bottom View Here thread it SCREWS XTS3+10JFJ /4pcs/ SCREWS THEC217J /2pcs/ Note: During screwing pedestal cover BTM L/R Press in arrob direction Bottom View Top View SCREWS XSS /4pcs/...
  • Page 29 Parts Location K PCB Bottom Back Cover BOTTOM VIEW Bottom AV Bracket REAR VIEW FK201 SEC A-A FK303 SP Bracket Lower L/R Circuit Board A SP Bracket Lower L REAR VIEW FK301 TOP VIEW SP Bracket Lower R AL301 REAR VIEW FK302 TOP VIEW...
  • Page 30 Parts Location Cabinet assy AL304 AL305 AL303 AL306 Note:Al tapes must not exceed groove at the edge of cbinet assy AL311 AL312 Groove Groove AL Foil tape Cabinet assy Note:Al tape centre according to cabinet´s hole. AL307 AL310 AL309 AL308 Note: AL cushion tape must be through theal tapes.

  • Page 31: Location Of Lead Wiring

    Location of Lead Wiring A16A JK8705 WIFI SP_R SP_L...

  • Page 32: Location Of Heat Rubbers And Gaskets

    Location of Heat Rubbers and Gaskets A PCB Detail sticking ALA01 FA04 FA05 FA06 BOTTOM SIDE TOP SIDE ALA01 FA03 FA02 FA01 GA04 GA03 GA01 GA02 HEATSINK A BTM FA09 FA11 FA08 FA10 FA07 FA13 FA12 GA08 GA07 GA06 GA05...

  • Page 33: Packing Structure

    Packing Structure Pedestal assy TV SET...

  • Page 34: Replacement Parts List Note

    Replacement Parts List Note Note: All parts except parts mentioned [PAVCCZ] in the Remarks column are supplied by AVC-CSPC. Parts mentioned [PAVCCZ] are supplied by PAVCCZ. Notice: Be sure to make your orders of replacement parts according to this list. RTL (Retention Time Limited) Note: The marking (RTL) indicates that the Retention Time is Limited for this item.

  • Page 35: Replacement Parts List

    Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks BAT-C-1010 BATTERY COVER OF RC PAVCCZ K1HY05YY0242 USB CABLE PAVCCZ K2CT2YY00107 AC CORD (UK) PAVCCZ L0EYAA000086 SPEAKER PAVCCZ L5EDDYY00872 LCD PANEL PAVCCZ N2QAYB001010...
  • Page 36 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks AL302 TEWF481 AL PET TAPE(W10XL80) PAVCCZ AL303 TEW5ZF024 AL FOIL TAPE PAVCCZ AL304 TEW5ZF024 AL FOIL TAPE PAVCCZ AL305 TEW5ZF024 AL FOIL TAPE...
  • Page 37 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks A-55DX650B CIRCUIT BOARD A (RTL)PAVCCZ TXN/K1WJUZ CIRCUIT BOARD K (RTL)PAVCCZ TXN/P1ZWVE CIRCUIT BOARD P (RTL)PAVCCZ A02A K1KY16BA0484 16P CONNECTOR PAVCCZ K1KY07BA0483 7P CONNECTOR...
  • Page 38 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks C3205 F1G1A105A047 C 1000NF, , 10V PAVCCZ C3206 F1G1A105A047 C 1000NF, , 10V PAVCCZ C3801 F1K1E106A167 C 10UF, , 25V PAVCCZ C3802 F1K1E106A167...
  • Page 39 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks C5210 F1G1C104A146 C 0.1UF, , 16V PAVCCZ C5212 F1G1E103A144 C 0.01UF, , 25V PAVCCZ C5240 F1K1E106A167 C 10UF, , 25V PAVCCZ C5241 F1K1E106A167...
  • Page 40 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks C6843 F1J1A106A043 C 10UF, , 10V PAVCCZ C6847 F1G1C104A146 C 0.1UF, , 16V PAVCCZ C6849 F1G1C104A146 C 0.1UF, , 16V PAVCCZ C6950 F1G0J1050007 C 1UF, K, 6.3V...
  • Page 41 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks C7324 F1J1H102A909 C 1NF, , 50V PAVCCZ C7325 F1J1H103A900 C 10NF, , 50V PAVCCZ C7401 F1J1H104A902 C 100NF, , 50V PAVCCZ C7402 F1J1E105A287...
  • Page 42 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks C8015 F1G1C104A146 C 0.1UF, , 16V PAVCCZ C8016 F1J1A106A043 C 10UF, , 10V PAVCCZ C8017 F1G1C104A146 C 0.1UF, , 16V PAVCCZ C8021 F1G1A105A047...
  • Page 43 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks C8205 F1G1C104A146 C 0.1UF, , 16V PAVCCZ C8206 F1G1C104A146 C 0.1UF, , 16V PAVCCZ C8207 F1G1C104A146 C 0.1UF, , 16V PAVCCZ C8208 F1J1A106A043...
  • Page 44 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks C8267 F1G1C104A146 C 0.1UF, , 16V PAVCCZ C8268 F1G1C104A146 C 0.1UF, , 16V PAVCCZ C8269 F1G1E153A144 C 0.015UF, , 25V PAVCCZ C8270 F1G1C104A146 C 0.1UF, , 16V...
  • Page 45 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks D3108 DZ2J140M0L DIODE PAVCCZ D3109 DZ2J140M0L DIODE PAVCCZ D3110 DZ2J140M0L DIODE PAVCCZ D3111 DZ2J140M0L DIODE PAVCCZ D3112 DZ2J140M0L DIODE PAVCCZ D3113 DZ2J140M0L DIODE...
  • Page 46 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks D8105 B0ADCK000001 DIODE PAVCCZ D8106 B0JCGD000016 DIODE PAVCCZ F2000 ERBRD4R00X FUSE PAVCCZ F5200 ERBRD4R00X FUSE PAVCCZ F5700 ERBRD1R00X FUSE PAVCCZ F7101 K5E502YYA213 FUSE...
  • Page 47 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks JK8703 K1FY109B0047 USB3.0 TERMINAL PAVCCZ JK8705 K1FY105E0025 USB TERMINAL PAVCCZ JS2000 D0GAR00JA039 M 0 OHM, J, 1/16W PAVCCZ K1KY07AA1311 7P CONNECTOR PAVCCZ L2200...
  • Page 48 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks PC7302 B3PAA0000704 PHOTO COUPLER PAVCCZ PC7303 B3PAA0000707 PHOTO COUPLER PAVCCZ Q2200 B1ABCF000231 TRANSISTOR PAVCCZ Q2201 B1ABCF000231 TRANSISTOR PAVCCZ Q4501 B1ABCF000231 TRANSISTOR PAVCCZ Q4502...
  • Page 49 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R2004 D0GA102JA039 M 1K OHM, J, 1/16W PAVCCZ R2009 D0GA680JA039 M 68 OHM, J, 1/16W PAVCCZ R2011 D0GA102JA039 M 1K OHM, J, 1/16W...
  • Page 50 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R3807 D0GA102JA039 M 1K OHM, J, 1/16W PAVCCZ R3808 D0GA473JA039 M 47K OHM, J, 1/16W PAVCCZ R3809 D0GA102JA039 M 1K OHM, J, 1/16W...
  • Page 51 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R4606 D0GA680JA039 M 68 OHM, J, 1/16W PAVCCZ R4607 D0GA680JA039 M 68 OHM, J, 1/16W PAVCCZ R4610 D0GA473JA039 M 47K OHM, J, 1/16W...
  • Page 52 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R5741 D0GDR00J0004 M 0 OHM, J, 1/8W PAVCCZ R5748 D0GDR00J0004 M 0 OHM, J, 1/8W PAVCCZ R5904 D0GA473JA039 M 47K OHM, J, 1/16W...
  • Page 53 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R6795 D0GAR00JA039 M 0 OHM, J, 1/16W PAVCCZ R6804 D0GA471JA039 M 470 OHM, J, 1/16W PAVCCZ R6806 D0GA103JA039 M 10K OHM, J, 1/16W...
  • Page 54 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R7301 D1BD3003A066 M 300K OHM, F, 1/8W PAVCCZ R7302 D0GF391JA047 M 390 OHM, J, - PAVCCZ R7303 D0GF391JA047 M 390 OHM, J, -...
  • Page 55 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R7487 D1BB3602A073 M 36K OHM, F, 1/10W PAVCCZ R7492 D0GD243JA052 M 24K OHM, J, 1/8W PAVCCZ R7495 D0GB100JA065 M 10 OHM, J, 1/10W...
  • Page 56 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R7909 ERG2SJ103V M 10K OHM, J, 2W PAVCCZ R7910 ERG2SJ103V M 10K OHM, J, 2W PAVCCZ R8007 D0GAR00JA039 M 0 OHM, J, 1/16W...
  • Page 57 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R8717 D0GA103JA039 M 10K OHM, J, 1/16W PAVCCZ R8718 D0GA103JA039 M 10K OHM, J, 1/16W PAVCCZ R8719 D1H8R0040016 M 0 OHM, -, -...
  • Page 58 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks R8951 D0GA473JA039 M 47K OHM, J, 1/16W PAVCCZ RM2800 B3RBB0000018 IR RECEIVER PAVCCZ SN2800 B3JB00000223 IC AI SENSOR PAVCCZ SW2851 EVQ11G05R LIGHT TOUCH SWITCH...
  • Page 59 Model No. : TX-55DX650B Parts List Ref. Change Safety Part No. Part Name & Description Q'ty Remarks ZA0325 K4AD01D00012 TERMINAL PAVCCZ ZA0327 K4AD01D00012 TERMINAL PAVCCZ ZA0328 K4AD01D00012 TERMINAL PAVCCZ ZA0329 K4AD01D00012 TERMINAL PAVCCZ ZA0330 K4AD01D00012 TERMINAL PAVCCZ ZA0332 K4AD01D00012 TERMINAL...

  • Page 60: Schematic Diagrams Note

    Schematic Diagrams Note IMPORTANT SAFETY NOTICE Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturers' specified parts. NOTE RESISTOR All resistors are carbon ¼W resistor, unless marked otherwise. Unit of resistance is OHM () (k=1,000, M=1,000,000) CAPACITORS All capacitors are ceramic 50V unless marked otherwise.

  • Page 81: (Esd) To Electrostatically Sensitive (Es) Conductor Views

    Conductor Views A-BOARD - TOP A16A JK8705 R8940 R8941 R4151 L4007 L4005 L4003 A 1 0 R4095 D2203 A 1 6 R4157 L4006 R4155 R4154 R4153 L4002 L4001 L4000 R4105 C4116 C2258 J K 8 7 0 5 A 1 7 L8706 A 1 2 C4117...
  • Page 82 A-BOARD - BOTTOM R4050 R4038 R4049 ZA0327 ZA0308 ZA365 ZA0313 ZA0325 ZA0350 R2131 R4039 ZA0343 ZA368 ZA367 R4046 Q2201 R4041 R2262 Q4002 Q4004 C4073 R2072 R2075 R4043 R8945 D2205 R2074 R8946 R2077 R4051 R4047 C4107 TP8718 TP8721 TP8720 TP8719 R8947 C2259 TP4050 TP4051...
  • Page 83 P-BOARD - TOP JS7416 L7413 J108 C7870 D7805 J611 J316 L7802 J315 J212 ZA7103 C7813 Q7804 L7812 JS7808 C7819 L7814 J412 J314 C7101 C7814 R7871 R7840 J211 J105 J609 R7909 J210 C7104 J208 J411 R7910 J207 J209 J107 D7101 C7812 J106 J410 J409...
  • Page 84 P-BOARD - BOTTOM JS7416 R7432 C7430 R7803 L7413 R7833 C7426 C7862 TP7412 C7869 R7827 C7860 C7868 C7419 TP7411 C7425 C7852 TP7410 J108 J611 D7805 C7870 C7431 J316 C7478 R7475 D7438 C7477 L7802 D7812 J315 J212 C7466 ZA7103 TP7405 C7465 CL7803 C7813 Q7804 D7428...
  • Page 85 K-BOARD - TOP K-BOARD - BOTTOM R2807 R2808 R2800 R2809 R2801 R2816 TD2805 TD2801 TD2807 R2802 C2806 TD2806 TD2802 R2822 C2808 TD2804 TD2803 R2821 D2802 D2802A...
