Summary of Contents for Connevans Azden IRR-40P
- Page 1 Connevans.info Solutions to improve the quality of life This product may be purchased from Connevans Limited DeafEquipment.co.uk secure online store at www.DeafEquipment.co.uk...
- Page 2 Azden IRR-40P Soundfield User & Installation Guide for IRR-40P systems with Swift & handheld transmitters IRR-40P receiver/amplifier Pages Transmitter microphones Pages 6-11 Installation guide Pages 12-18 Cautions & troubleshooting Pages B460IRR40P V1.0...
-
Page 3: Table Of Contents
................. Azden IRR-40P ‒ User & Installation Guide... -
Page 4: Introduction
Azden IRR-40P Soundfield Introduction Thank you for selecting the Azden IRR-40P system as your wireless classroom solution. We are confident that it will perform beyond your expectations. For over 50 years Azden Corporation has been creating technologically advanced products. By taking advantage of the latest in CAD design and SMT production techniques, Azden’s engineers are able to produce products that... -
Page 5: Irr-40P Receiver/Amplifier
Azden IRR-40P Soundfield IRR-40P receiver/amplifier B. Channel 1/2 C. Line 1/2 Receiver front panel volume volume A. Power switch Receiver rear panel G. Ext. sensor H. Ext. sensor input 1 input 2/3 Azden IRR-40P ‒ User & Installation Guide B460IRR40P V1.0... - Page 6 If a DVD player, CD player or MP3 player is used, the audio from this can be attached to either LINE 1 or LINE 2 on the back of the IRR-40P. B460IRR40P V1.0 Azden IRR-40P ‒ User & Installation Guide...
-
Page 7: Transmitters
Note ‒ replacement straps are available, please see www.DeafEquipment.co.uk 45IRTXSTRAP Replacement strap 45IRTXSCLIP Replacement clip The two parts of the neck clasp may be pushed together or pulled apart either directly or by sliding. Azden IRR-40P ‒ User & Installation Guide B460IRR40P V1.0... -
Page 8: Charging The Swift Tx Transmitter
‒ please contact our Soundfield Technical Helpline for advice should you experience short battery life. Charger 45IRTXCHG2 for charging a Swift or beltpack transmitter 1.3mm plug B460IRR40P V1.0 Azden IRR-40P ‒ User & Installation Guide... - Page 9 ON (green indicator) ‒ in this mode, although the battery needs to be fitted, the Swift now powered from the charger rather than the battery. Using external power will preserve battery life when connected to an external sound source. Azden IRR-40P ‒ User & Installation Guide B460IRR40P V1.0...
- Page 10 Inside, just above the battery, you will be able to see a small switch labelled ‘A channel B’. Use the end of a paperclip to slide the channel switch. Always replace the battery compartment cover afterwards. B460IRR40P V1.0 Azden IRR-40P ‒ User & Installation Guide...
-
Page 11: Handheld Microphone Transmitter
Remember to switch off the handheld mic before charging. Use the external charger 45IRTXHCHG2 plugged into a mains socket. Charge time is 16-20 hours from flat (i.e. overnight). 2.1mm plug Charge socket Azden IRR-40P ‒ User & Installation Guide B460IRR40P V1.0... - Page 12 Please note that the label fitted to the outside of the battery compartment indicates the switch positions as ‘CH1’ (= Channel A) and ‘CH2’ (= Channel B). CH2 (B) The left hand switch should always be left on ‘Hi’. Default setting: B460IRR40P V1.0 Azden IRR-40P ‒ User & Installation Guide...
-
Page 13: Irr-40P Installation Guide
‘lighting’ plan to give the best pattern for the students ‒ perhaps avoiding the window, an unused end Speaker position allowing for a window of a classroom or a teachers desk. Azden IRR-40P ‒ User & Installation Guide B460IRR40P V1.0... -
Page 14: Fitting The Intra Red Sensors
The dome sensor is normally fitted near the centre of the room and as far away from lights or other obstructions as possible. Normal room: Large room: 2 dome sensors 1 dome sensor L-shaped room: 1 dome sensor + 1 wall sensor B460IRR40P V1.0 Azden IRR-40P ‒ User & Installation Guide... -
Page 15: Mounting The Infra Red Sensors
2 and 2.5m above the floor, preferably not higher than the loudspeakers. The bracket for the wall mounted sensor needs to be bent 70mm from the flat end of the bracket. 70mm Azden IRR-40P ‒ User & Installation Guide B460IRR40P V1.0... -
Page 16: Fitting The F-Connectors
4. Mounting the IRR-40P receiver amplifier Usually, the IRR-40P receiver is installed near the front of the room, on a convenient shelf. An optional wall mount bracket is available. Wall mount bracket 4530BKT B460IRR40P V1.0 Azden IRR-40P ‒ User & Installation Guide... -
Page 17: Setting Up And Testing The System
Buzzing or distortion from a particular speaker may indicate a faulty speaker or loose mount. A 3.5mm to phono plug pair lead is supplied in the Connevans Soundfield AV lead pack (45SIBPK1) if this has been purchased. Check the transmitter As long as the transmitter has been on charge for at least 30 minutes, you will have enough charge in the batteries to test and demonstrate the system. -
Page 18: Demonstrate And Set The Volume For The User
The tone control can now be adjusted if necessary to optimise vocal clarity. B460IRR40P V1.0 Azden IRR-40P ‒ User & Installation Guide... - Page 19 ‘performance’. If the system has been supplied with a handheld microphone you must now go through the same procedure with this microphone using the ‘Channel 2’ volume control. Azden IRR-40P ‒ User & Installation Guide B460IRR40P V1.0...
-
Page 20: Troubleshooting
‒ you don’t need to take the photo but the emitters will show up really clearly! The camera will see the infra red light from the emitters. B460IRR40P V1.0 Azden IRR-40P ‒ User & Installation Guide... - Page 21 Equipment for Deaf and Hard of Hearing People in Education, Employment, the Home & Leisure Bridge House, 1 Nutfield Road, Merstham, Surrey RH1 3EB Telephone 01737 247571 Email soundfield@connevans.com Information www.connevans.info/soundfield © 2016 Connevans Limited B460IRR40P Azden IRR-40P User & Installation Guide V1.0 2016...
