Grizzly H6151 Parts Breakdown

35
32
37
10
REF PART # DESCRIPTION
1 PH6151001 HANDLE KNOB
2 PH6151002 PLATEN ARM
3 PH6151003 PLATEN SPRING
4 PH6151004 PLATEN
5 PH6151005 SILICON RUBBER STRIP
6 PS01M PHLP HD SCR M4-.7 X 18
7 PH6151007 HINGE
8 PH6151008 HINGE BRACKET
9 PH6151009 SEALER BASE
10 PH6151010 METAL PLATE
11 PH6151011 LOWER TEFLON ELEMENT
12 PH6151012 UPPER TEFLON CLOTH
13 PH6151013 STRAIN RELIEF
14 PH6151014 POWER CORD
15 PH6151015 HEATING ELEMENT
16 PH6151016 PILOT LAMP
17 PH6151017 TIMER KNOB
18 PH6151018 CONTROL PANEL ASSEMBLY
20 PH6151020 SWITCH LEVER
21 PH6151021 WIRE CONNECTOR
22 PH6151022 INTERNAL WIRING
-4-
H6151 Parts Breakdown & List
2
5
36
8
20
11
15
39
16
18
17
12
43
1
3
6
4
14
7
30
13
9
38
12
10
REF PART #
23 PH6151023 HEATER TRANSFORMER
24 PH6151024 WIRE CONNECTOR
25 PH6151025 MICROSWITCH
26 PH6151026 SWITCH BRACKET
27 PH6151027 SWITCH INSULATION
28 PH6151028 SWITCH LEVER SPRING
30 PH6151030 HEATER TERMINAL ASSEMBLY
31 PH6151031 GROUNDING WIRE
32 PH6151032 COVER PLATE
35 PH6151035 RUBBER FOOT AND SCREW
36 PSS81M
37 PS12M
38 PFH57M
39 PS17M
40 PS18M
41 PS59M
42 PS07M
43 PSB04M
47 PLW09M
48* PTLW01M
* Part not shown in breakdown
48*
47
42
41
20
31
30
40
21
37
DESCRIPTION
SET SCREW M3-.5 X 5
PHLP HD SCR M3-.5 X 6
FLAT HD SCR M3-.5 X 8
PHLP HD SCR M4-.7 X 6
PHLP HD SCR M4-.7 X 25
PHLP HD SCR M3-.5 X 14
PHLP HD SCR M4-.7 X 8
CAP SCREW M6-1 X 10
LOCK WASHER 3MM
EXT TOOTH WASHER 4MM
H6151-54 Heat Sealing Machines
27
25
26
28
22
24
23
39
