Matrix MAGNUM 2003M Quick Start Manual

Select training weight by using both
weight-stack pins. Move back pad into
desired position, supine (positions 3-8)
or seated (positions 1-2). Place feet in
desired position on footplate. Adjust
starting position with handle under
seat so legs are bent to 90 degrees
at start.
© 2013 Johnson Health Tech. All Rights Reserved.
M AG NUM SERIES
2003M / LEG PRESS
MAINTENANCE CHECKLIST
ACTION
Clean Upholstery *
Inspect Cables
Clean Guide Rods
Inspect Hardware
Inspect Frame
Clean Machine
Clean Grips *
Lubricate Guide Rods †
* Upholstery & Grips should be cleaned with a mild soap and
water or a non-ammonia based cleaner.
† Guide rods should be lubricated with Teflon based lubricant. Apply
the lubricant to a cotton cloth and then apply up and down the
guide rods.
PRODUCT SPECIFICATIONS
TECH SPECS
Maximum User Weight
Maximum Training Weight
Product Weight
Overall Dimensions
(L x W x H)*
Weight Horn Diameter
(Weight Plate Storage)
2003M
* Ensure a minimum clearance width of 914 mm / 36" for access
862-111 Leg Press
Rev 1.2
to and passage around MATRIX strength equipment.
October 2, 2013
Die lines. Do not print.
Black
WARRANTY
Pantone 4715C
Pantone 719C
Pantone 1795C
Pantone 7409C
Valid in USA only
Pantone 7461C
Background Greys
Frame (not coatings) *
85% Black
70% Black
Weight stacks
Size:
559 x 162 mm
Pulleys
22 x 6.4 in
Pivot bearings
Any items not specified
Labor (excludes upholstery/cables/grips)
Upholstery/cables/grips/springs
* Frame is defined as the welded metal base of the unit and does
not include removable parts.
FREQUENCY
Daily
Daily
Monthly
Monthly
Bi-Annually
As Needed
As Needed
As Needed
159 kg / 350 lbs.
139 kg / 305 lbs.
307 kg / 675 lbs.
178 x 117 x 175 cm /
70" x 46" x 69"
47.63 mm / 1.875"
10 years
5 years
5 years
5 years
3 years
3 years
1 year
Rev 1.0 / 2013.12.11
