Audio Partnership WD752-BD-N User Manual

150mbps wireless lite n usb adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WD752-BD-N
150Mbps Wireless Lite N USB Adapter

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WD752-BD-N and is the answer not in the manual?

Questions and answers

Related Manuals for Audio Partnership WD752-BD-N

Summary of Contents for Audio Partnership WD752-BD-N

  • Page 1 WD752-BD-N 150Mbps Wireless Lite N USB Adapter...
  • Page 2 FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 3 CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. National restrictions This device is intended for home and office use in all EU countries (and other countries following the EU directive 1999/5/EC) without any limitation except for the countries mentioned below: Country Restriction...
  • Page 4 Industry Canada Statement Complies with the Canadian ICES-003 Class B specifications. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. This device complies with RSS 210 of Industry Canada. This Class B device meets all the requirements of the Canadian interference-causing equipment regulations.

  • Page 5: Table Of Contents

    CONTENTS Package Contents ....................1 Chapter 1 Introduction ..................2 Product Overview .................... 2 Main Features ....................2 LED Status ...................... 2 Chapter 2 Installation Guide ................. 3 Hardware Installation ..................3 Software Installation ..................3 2.2.1 Overview ......................3 2.2.2 Installation Guide ....................

  • Page 6: Package Contents

    The following items should be found in your package:  One WD752-BD-N Wireless Adapter  One USB extension cable  Quick Installation Guide  One Resource CD for WD752-BD-N Wireless Adapter, including:  Drivers and Utility  User Guide  Other Helpful Information ...

  • Page 7: Chapter 1 Introduction

    TKIP, AES，WPA and WPA2 encryption to prevent outside intrusion and protect your personal information from being exposed. The adapter is easy to install and manage. The WD752-BD-N supports WPS function, which can help you create a wireless connection immediately. Quick Setup Wizard is supported and detailed instructions are provided step by step in this user guide.

  • Page 8: Chapter 2 Installation Guide

    Windows XP for example. 2.2.2 Installation Guide 1. Insert the Resource CD into your CD-ROM drive, then go to My Computer to double-click CD-ROM WD752-BD-N, and you will see the screen as Figure 2-1. Double-click Setup.exe to start the installation. - 3 -...
  • Page 9 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 2-1 Start the Installation 2. You’ll see the screen as below. You can choose which to be installed and click Next. Figure 2-2 Setup Type 3. In the following screen, select the configuration tool and click Next.
  • Page 10 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 2-3 Setup Type 1) If you want to install the RL52 Wireless N Client Utility, please select the Wireless Configuration Tool. 2) If you only want to use the Microsoft Zero Configuration Tool to configure the wireless connection, please select Microsoft Zero Configuration Tool.
  • Page 11 WD752-BD-N 150Mbps Wireless Lite N USB Adapter 5. You will see the next screen as below. Click Install to continue. Figure 2-5 Ready to Install the Program 6. The following screen for installing will appear. Figure 2-6 Setup Status ...
  • Page 12 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 2-7 Windows XP Warning Box 7. After the files have been successfully copied, the screen in Figure 2-8 will appear. Click the Finish button to finish the installation and reboot the system.

  • Page 13: Uninstall Software

    WD752-BD-N 150Mbps Wireless Lite N USB Adapter 2.3 Uninstall Software 2.3.1 Uninstall the utility software from your PC On the Windows taskbar, click the Start button, point to All programsWireless, and then click Uninstal-RL52 Wireless N Client Utility. Follow the Install Shield Wizard to uninstall the utility software from your PC.

  • Page 14: Chapter 3 Configuration

    Chapter 3 Configuration 3.1 Configuration of Utility WD752-BD-N Wireless Adapter can be configured by its utility for Windows XP/ Vista/ 7. This section will take the configuration in Windows XP for example and guide you to configure your wireless adapter for wireless connectivity with trustable data security encryption features.

  • Page 15: Site Survey

    WD752-BD-N 150Mbps Wireless Lite N USB Adapter 3.1.1 Site Survey Click the Site Survey icon on the screen of the Utility and the Site Survey screen with many available wireless network choices will appear. The AP list will be updated every two seconds.
  • Page 16 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Edit a profile  Import a profile   Export a profile Add a WPS profile  Figure 3-3 Profile List - Click to add a new profile.  - Deletes an existing profile.
  • Page 17 Infrastructure - All wireless clients will connect to an access point or wireless router.  Ad Hoc - Directly connecting to another computer, for peer-to-peer communication, using wireless network adapters on each computer, such as two or more WD752-BD-N wireless adapters. ...
  • Page 18 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 3-5 Authentication and Encryption  Authentication - You can choose the Authentication Type from the pull-down list with seven options, Open, Shared, WPA, WPA-PSK, WPA2, WPA2-PSK, and 802.1X. Encryption - Displays which encryption type that the adapter is using. When you select ...
  • Page 19 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 3-7 Use Pre-logon Connection Use Pre-logon Connection - Use ID and Password in Profile.  5. Some advanced settings can be made in Figure 3-8. Figure 3-8 Profile Tx Power - Manually force the AP’s transmitting power.
  • Page 20 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 3-9 Profile Added Successfully 3.1.2.2. Delete a profile Highlight the desired profile name on Profile List and click the Delete icon . The profile will be removed from the list. Figure 3-10 Delete a Profile 3.1.2.3.
  • Page 21 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 3-11 Edit a Profile 3.1.2.4. Import a profile From the Profile List screen (shown in Figure 3-3), click the Import icon . Then the Import Profile screen will appear below. Browse to the directory where the profile is located.
  • Page 22 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 3-13 Export a Profile 3.1.2.6. Add a WPS profile Click the Add WPS Profile icon of the Utility and you can configure the WPS function to join an existing network quickly in the following screen.
  • Page 23 WD752-BD-N 150Mbps Wireless Lite N USB Adapter PBC Method If your Access Point is equipped with a push-button for Wi-Fi Protected Setup, you can connect the adapter to the Access Point by Push-Button Configuration (PBC) method. Step 1 Press the WPS button on your Access Point device.
  • Page 24 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Step 5 The Adapter will search for the AP to establish connection automatically. Figure 3-18 Step 6 Wait a moment until Figure 3-19 appears. Figure 3-19 II. PIN Method If your Access Point supports Wi-Fi Protected Setup and the PIN method, you can add the...
  • Page 25 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 3-20 Step 3 Choose the Config Mode as Enrollee and click the Next icon on the screen below. Meanwhile, enter the PIN code of the adapter (here takes 51349417 in the screen for example) into the configuration utility of the AP. For the detailed instructions of the AP configuration, please refer to the User Guide of the AP.
  • Page 26 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Enter a PIN from my Access Point Step 1 Click the Add WPS Profile icon on the screen as Figure 3-14. Step 2 Tick PIN/numeric code and then select the desired SSID from the WPS AP List (take Network for example) on the screen below.

  • Page 27: Link Information

    WD752-BD-N 150Mbps Wireless Lite N USB Adapter Step 5 When Figure 3-19 appears, the configuration is complete.  Note: The default PIN code of the AP always can be found in its label or User Guide. 3.1.3 Link Information Click the Link Information icon of the Utility and you will see the following screen displaying the receiving and transmitting statistical information.
  • Page 28 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 3-27 Throughput  Link Quality - Displays connection quality based on signal strength and TX/RX packet error rate. Signal Strength - This shows the strength of the signal.  Link Speed - Shows current transmit rate and receive rate.

  • Page 29: Advanced

    WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 3-29 Receive Statistics  Received Successfully - The number of frames successfully received.  Received With CRC Error - The number of frames received with a CRC error.  Dropped Due To Out-of-Resource - The number of frames dropped due to a resource issue.

  • Page 30: About

    WD752-BD-N 150Mbps Wireless Lite N USB Adapter the access point with which it associates.  Enable TX Burst - It can translate more data when it is enabled. Enable TCP Window Size - It can enhance the TCP throughput when it is enabled.

  • Page 31: Configure With Windows Xp Wireless Zero Configuration

    WD752-BD-N 150Mbps Wireless Lite N USB Adapter list. Enter Test for the Profile Name, and select Infrastructure for the Network Type, then click Next icon to the next page. Select WPA2-PSK for the Authentication, AES for the Encryption and click Next icon to continue.
  • Page 32 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 3-34 Enter Network Key 4. If the connection is finished, you will see the screen as Figure 3-35 shows. Figure 3-35 Connected - 27 -...

  • Page 33: Chapter 4 Ap Mode

    At this time, if your PC has Installed other network card (wireless or wired), you will be prompted “ICS Select WAN Adapter” to select one of them to be “WAN”. With this function WD752-BD-N can serve as wireless router based on the selected card connecting to the Internet, which will make the APs of the LAN share the Internet.

  • Page 34: Config Ap

    WD752-BD-N 150Mbps Wireless Lite N USB Adapter Config AP Click the Config AP icon to load the following screen and set the AP as you need. Step 1. Click Config AP icon , the following screen will pop up. Click Next icon continue.

  • Page 35: Advanced

    WD752-BD-N 150Mbps Wireless Lite N USB Adapter Step 3. The AP’s authentication mode and encryption type can be set in the following figure. Figure 4-6 Step 4. Enter the Key in the empty field to make your AP security enabled (here takes 1234567890 for example).

  • Page 36: Access Control List

    WD752-BD-N 150Mbps Wireless Lite N USB Adapter Interval value determines the time interval of the beacons. The default value is 100. TX Power - Manually force the AP’s transmitting power. System default is 100%.  Idle Time - Manually force the Idle Time using a selected value. The default is 300.
  • Page 37 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 4-10 Add an Mac Address to the List Figure 4-11 Remove an existing Mac Address from the List - 32 -...

  • Page 38: Associate List

    WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 4-12 Clear All MAC Addresses 4.4 Associate List Figure 4-13 shows the link status page. It displays detailed station information of current connection. Figure 4-13 Mac Table Function MAC Address - The station’s Mac address of the current connection.

  • Page 39: About

    WD752-BD-N 150Mbps Wireless Lite N USB Adapter  AID - Raise value by current connection.  Power Saving Mode - Support Power Saving Mode on the currently connected station. Status - The link status of the current connection.  4.5 About The About page displays the wireless card and driver version information as shown in Figure 4-14.

  • Page 40: Chapter 5 Example For Application

    Configuration of PSP XLink Online game Please ensure the software and hardware environments are well established before configuring. For hardware, at least a PC, a WD752-BD-N Wireless Adapter and a PSP device are needed. For software, the WD752-BD-N Adapter driver should be properly installed.
  • Page 41 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Right-click “My Computer” and select Management. In the prompt page, click Device Step 5. Manager, then right-click “Wireless N Client Adapter “and select Properties. Then set the value of “PSP Xlink Mode” as Enable following the red marked instruction in the figure.
  • Page 42 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 5-4 Step 8. In the prompt page shown below, select Use the Following IP Address, and set the IP and Subnet mask. After completing setting, click OK. Figure 5-5  Note: Please set the IP address in different network segment with the other network card to avoid conflict.
  • Page 43 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Figure 5-6 Step 11. Click the icon on the right top corner to enter the Arena Mode, highlight the arena of your wanted game, and then join or start a new game. Figure 5-7...

  • Page 44: Appendix A: Glossary

    WD752-BD-N 150Mbps Wireless Lite N USB Adapter Appendix A: Glossary 802.11b - The 802.11b standard specifies a wireless networking at 11 Mbps using direct-sequence spread-spectrum (DSSS) technology and operating in the unlicensed radio spectrum at 2.4GHz, and WEP encryption for security. 802.11b networks are also referred to as Wi-Fi networks.
  • Page 45 WD752-BD-N 150Mbps Wireless Lite N USB Adapter Spread Spectrum - Spread Spectrum technology is a wideband radio frequency technique developed by the military for use in reliable, secure, mission-critical communications systems. It is designed to trade off bandwidth efficiency for reliability, integrity, and security. In other words,...

  • Page 46: Appendix B: Specifications

    WD752-BD-N 150Mbps Wireless Lite N USB Adapter Appendix B: Specifications General Interface USB 2.0 Connector Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Operating System Windows XP/ Vista/ 7 Safety & Emission FCC, CE 2.412 ~ 2.472 GHz (For CE Area) Frequency 2.412 ~ 2.462 GHz (For FCC Area)
