JOSAM homebase 4 Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Operator manual
Homebase, I-track ll and Tire Manager
T 194 1 1901
16538

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the homebase 4 and is the answer not in the manual?

Questions and answers

Summary of Contents for JOSAM homebase 4

  • Page 1 Operator manual Homebase, I-track ll and Tire Manager T 194 1 1901 16538...
  • Page 2 This page is intentionally left blank...

  • Page 3: Table Of Contents

    4 EC Declaration of Conformity ................ 11 Homebase 4 user guide .................. 15 System description ..................17 Introduction ....................17 System requirements ................19 Technical data ................... 19 Measurement setup .................. 20 Safety signs and labels ................20 Wheel angle definitions ................21 Measurement references ................
  • Page 4 4 Software settings..................... 57 Reports...................... 58 Units ......................59 Communication ..................60 Licenses ....................62 About ......................63 I-track II user guide..................64 Measurement preparations................65 Preparation for the magnetic wheel adapters ........... 66 System start-up ....................73 Connect the measuring head and distance laser ........74 Frame centre line measurement ..............
  • Page 5 4 Measure twinsteer ..................105 Measure without play procedure ............. 105 Measure twinsteer with play procedure........... 106 Adjust twinsteer axles................... 109 Adjust twinsteer without play ..............110 Adjust twinsteer with play ................ 110 Adjust max turn ..................... 113 ADAS/Safety system calibration ..............117 Tire Manager user guide ................
  • Page 6 This page is intentionally left blank...
  • Page 7 4 Read me first! – Everyone working with the equipment should be well acquainted with the system, and able to work in compliance with the manual. – Observe the safety instructions and warning labels. – It is the responsibility of the system owner to replace damaged safety devices such as fuses and warning labels immediately.
  • Page 8 This page is intentionally left blank...
  • Page 9 4 Information NOTE Notes, usage tips or additional information. This Indicates a physical button to press font This Indicates emphasis font [This Indicates a software button to click font]...
  • Page 10 This page is intentionally left blank...

  • Page 11: Ec Declaration Of Conformity

    4 EC Declaration of Conformity EC Declaration of Conformity Car-O-Liner Group AB Hulda Mellgrens gata 1 SE-421 32 Västra Frölunda Sweden herewith declare under the sole responsibility that the product: Type of equipment: JOSAM distance laser Model(s) / Type(s):...
  • Page 12 This page is intentionally left blank...
  • Page 13 Model(s) / Type(s): JT731 Serial number(s): — for use together with JOSAM battery charger JT603 is in conformity with the provisions of the following EU directive(s): EMC Directive 2014/30/EU References of standards and/or technical specifications applied for this declaration of conformity:...
  • Page 14 This page is intentionally left blank...

  • Page 15: Homebase 4 User Guide

    4 Homebase 4 user guide...
  • Page 16 This page is intentionally left blank...

  • Page 17: System Description

    4 System description Introduction Homebase 4 serves as a software platform for wheel alignment systems. Customer, order, user, vehicle and measurement information is stored and edited in Homebase. Backup, restoring and updating of Homebase is performed on the database manager.
  • Page 18 This page is intentionally left blank...

  • Page 19: System Requirements

    4 System requirements Recommended Computer CPU: Intel i 3 or equivalent. RAM (Memory): 4GB. Hard drive: 128GB with at least 2GB of free space. At least 2x USB connectors (2.0/3.0) available when peripherals are connected. Peripherals and other related equipment Computer screen with a resolution of minimum 1380x768.

  • Page 20: Measurement Setup

    4 Measurement setup Fixed workplace Mobile workplace Safety signs and labels Prod. ID: JT731 Serial #: 00000 Prod. year: 201x www.josam.se Every measuring head is marked with a serial number, a CE and ETL symbol that certifies that the product is approved.

  • Page 21: Wheel Angle Definitions

    4 Wheel angle definitions Wheel angles Total Toe The angle of the horizontal lines drawn through the wheels of the same axle, from a top view. Individual Toe The angle of a horizontal line drawn through the wheel in relation to the measurement reference line, from a top view.
  • Page 22 4 Parallelism (EU) / Scrub angle (US) The angle formed by the thrust line of the measured axle and the thrust line of a reference axle. Caster The angle of the axle in relation to the vertical, as viewed from the side of the vehicle.
  • Page 23 4 TOOT (Toe out on turns) The angle difference between the inner wheel and the outer wheel when the inner wheel is angled at 20°. Offset When the axle is offset from the chassis.

  • Page 24: Measurement References

    4 Measurement references Geometrical centre line The geometrical centre line of a vehicle is a reference line drawn through the calculated centre points of the front axle and the main driven axle. This is the standard reference used in I-track II when measuring wheel angles without performing a frame reference measurement prior to the wheel angle measurements.

  • Page 25: Component Description

    4 Component description I-track II components Measuring head The measuring head is a battery powered device for measuring toe, camber, caster, KPI and max turn angles. When aimed at the targets the measuring head sends a laser beam that scans the reflex strips on the surface of the target.
  • Page 26 4 Frame gauge extensions left and right For use on a trailer. The gauges are equipped with a numbered scale to ensure that the reflective target scales are assembled at the same position on both ends of the gauge and a spirit level to ensure that the gauges are correctly levelled.
  • Page 27 4 Front adapters The front adapters are assembled to the front of the vehicle to support the frame gauges. Frame reference target Is assembled with various front adapters to the tow bars on the vehicle to create a reference point for the centre line tool.
  • Page 28 This page is intentionally left blank...

  • Page 29: Abbreviations

    4 Abbreviations The following abbreviations may occur in this manual: King Pin Inclination Light Emitting Diode Not Applicable TOOT Toe out on turns Vehicle Identification Number ADAS Advanced Driver Assistance Systems The following components may differ in software and technical documentation.
  • Page 30 This page is intentionally left blank...

  • Page 31: Homebase Start

    4 Homebase start Homebase start Click on the Homebase Icon to start the Homebase software. New Order: Used to create new orders for Tire Manager and I-track ll. Navigator: Used to access the order administration menu, customer administration menu, vehicle administration menu, employee administration menu and order deletion menu.
  • Page 32 This page is intentionally left blank...

  • Page 33: New Order

    The software will display the choice of applications for: – I-track ll – Tire Manager (JOSAM TM) NOTE The number of plugins will be subject to change in future software versions. Click on the [I-track ll] button to access New order I-track ll.
  • Page 34 4 New order Select a wheel size and wheel diameter. Selecting the wheel size informs the software how far the vehicle is to be rolled in the rolling sequence. Click on [Next] to continue with the selected dimensions. Click on [Back] to return to the axle choice window.
  • Page 35 4 New order A new order number is being automatically generated. Enter the VIN (Vehicle Identification Number or vehicle number plate). Add customer and employee information and comments. Click on [Save and start measure]. The software will proceed automatically to the pre-selected measurement process.
  • Page 36 This page is intentionally left blank...

  • Page 37: Navigator

    4 Navigator Navigator Navigator serves as the administrator of the database. Press on [Navigator] in the Start Menu to access the Navigator menu. Navigator window is displayed. Order information. Customer information. Vehicle information. Employee information. Deleted orders.

  • Page 38: Order Information

    4 Navigator Order information The order information window displays information regarding existing orders. All orders are created and stored in the database. Create a new order. Edit an existing order: (Only accessible if the administrator rights function is enabled).

  • Page 39: Customer Information

    4 Navigator Customer information Displays all information regarding existing customers. Create new customer information. Edit existing customer: (Only accessible if the administrator rights function is enabled). Delete existing customer information: (Only accessible if the administrator rights function is enabled).

  • Page 40: Vehicle Information

    4 Navigator Vehicle information Displays all vehicle information related to existing vehicles. Create a new vehicle specification. Edit vehicle specification: (Only accessible if the administrator rights function is enabled). Delete a vehicle specification: (Only accessible if the administrator rights function is enabled).

  • Page 41: Employee Information

    4 Navigator Employee information Displays information related to existing employees. Create a new employee specification. Edit employee specification: (Only accessible if the administrator rights function is enabled). Delete an employee specification: (Only accessible if the administrator rights function is enabled).

  • Page 42: Deleted Orders

    4 Navigator Deleted orders Displays all deleted orders. Restore Order: Will restore a deleted order to the order menu.

  • Page 43: Definitions

    4 Definitions Definitions The Definitions tab contains the settings for Homebase and the plugin I-track ll. To enter the configurations window click on [Definitions] The Definitions window contains Axle configuration, Tire configuration and Frame configuration. Axle configuration Click on the axle configuration in the list to the left to display configurations for that particular vehicle.
  • Page 44 4 Definitions Create a new axle configuration Click on [New] in the axle configuration window. Choose the vehicle type, manufacturer, model and enter the model year. Choose left or right steering. Click on [Next] This window will vary according to the chosen vehicle type.
  • Page 45 4 Definitions To build a new axle configuration, click on an axle type in the window to the left. The chosen axle will then appear in the window to the right. To remove the axle from the sequence, click on the red cross to the right of the axle to be removed.
  • Page 46 4 Definitions Edit an existing axle configuration Choose the axle configuration to be edited from the list. Click on [Edit] in the axle configuration window. Choose the vehicle type, manufacturer, model and enter the model year. Choose left or right steering.
  • Page 47 4 Definitions Enter the modifications and click on [Save] The changes are now saved.

  • Page 48: Tire Configuration

    4 Definitions Tire configuration Existing tire configurations can be edited and new tire configurations created. To see instructions for editing and creating new tire configurations, see chapter "New order" on page 33. If the tyres of the vehicle are different in size, select the most common dimension or an average...

  • Page 49: Frame Configuration

    4 Definitions Frame configuration NOTE This software configuration will be released at a later date. To enter frame configuration click on [Frame configuration]. Create a new configuration Click on [New] First, choose a frame type from the list to the left.
  • Page 50 4 Definitions Then enter the lengths for sections A, B and C and also specify a file name for the configuration. Add the required frame members by clicking once on the cross icon. A new frame member will be created for each click on the cross.
  • Page 51 4 Definitions Edit a frame configuration Click on [Edit] in the frame configuration window to edit an existing frame configuration. When done, click on [Save]...
  • Page 52 This page is intentionally left blank...

  • Page 53: Report And Preview

    4 Report and preview Report and preview To enter the report preview, click on [Print] in the order menu. The report window can be viewed in four different formats. Separate Displays before and after adjustment values on separate pages.

  • Page 54: Graphical

    4 Report and preview Graphical Displays before and after adjustment values on the same page. Text Displays before and after adjustment values on the same page, without any images.

  • Page 55: Tire Management

    4 Report and preview Tire management Displays the report for tire management.

  • Page 56: Toolbar Icons

    4 Report and preview Toolbar icons Displays the previous page. Displays the first page. Displays the next page. Displays the last page. Refresh: Refresh the page after changes. Print Report. Print Layout Preview the layout before printing. Page Setup: Change the page setup configurations.

  • Page 57: Software Settings

    4 Software settings Software settings The settings menu contains information for plugins homebase and I-track ll. To access the settings menu click on [Settings] in the start screen. Workflow Sets the type of measurements and the work flow. Workflow: Choose to measure starting from the rear axle or front axle.

  • Page 58: Reports

    4 Software settings Reports Report customization Enter workshop information and logo to be displayed in the header. Click on to import a logotype. Report settings Check or uncheck the boxes in the report settings list to choose which measurement results should be displayed in the report.

  • Page 59: Units

    4 Software settings Units Select units (mm/m, Degrees & Minutes, Decimal Degrees, etc.) in which the measurement results will be displayed. The selection made here will be displayed on both the printed reports and on the screen.

  • Page 60: Communication

    4 Software settings Communication Displays the serial numbers for the measuring heads used and the centerline tool. The centerline tool is only visible if pre-selected in the workflow window. When connected the serial numbers for the measuring heads (measuring heads 1 and 2) are displayed in the boxes to the right.
  • Page 61 4 Software settings Customization Activate login: Check the box to activate login. If activated the user must use a password to login. Text Auto Completion: Check the box to activate automatic text completion when entering data. Set the minimum road legal tread depth for tires: Enter value in mm.

  • Page 62: Licenses

    4 Software settings Licenses Displays status of licenses. Licenses can also be registered by clicking on For the Activate license instruction, see the Installation and Registration Manual.

  • Page 63: About

    4 Software settings About Displays information for contact details, service and remote support. For online assistance click on [Remote Support] The Teamviewer window will display instructions to connect.

  • Page 64: I-Track Ii User Guide

    i-track II I-track II user guide...

  • Page 65: Measurement Preparations

    i-track II Measurement preparations Measurement preparations Pre-measurement checks Before carrying out measurements, check with the help of play detectors, that the vehicle has no excess play in the bushings and steering linkage. The following items should be checked before performing wheel and axle measurements: 1.

  • Page 66: Preparation For The Magnetic Wheel Adapters

    Rotate the spirit level holder so that the bubble is levelled and lock it. The wheel adapter is now ready to be used in measurements. If JOSAM i-track II classic wheel adapters are being used, make sure to mount every wheel adapter with the main knob facing upwards.
  • Page 67 i-track II Measurement preparations Scales mounted on the vehicle Assemble the self-centering frame gauges, gauge extensions and the scales at the front and at the rear of the vehicle. For trailers or semi-trailers, use the special clamp for tow eyelet or king-pin. Windy environment Attach the stabilizer bracket to the hangers.
  • Page 68 i-track II Measurement preparations Adjustment of target scales Position the target scale and the measuring head so that they face each other centre to centre. Notice numerical markings on the extensions, note the reading indicated on the inner edge of the target scale.
  • Page 69 i-track II Measurement preparations Mobile target scales Before measurement, assemble the front and rear target pairs as displayed in the diagram below: The four aluminum rails are for storing the scales on wall. NOTE Check the calibration of the portable work bay regularly. See the instructions in the installation guide.
  • Page 70 i-track II Measurement preparations 5. Place the front targets directly against the front bumper, centred in relation to the vehicle's centre line. 6. Place the rear targets at least 2 m (~6 feet) behind the rear most axle of the vehicle, and centred in relation to the frame centre line.
  • Page 71 i-track II Measurement preparations 10. Move the front targets according to the distances in the software. 11. Click on [Next] 12. Start the measurement. NOTE Important! The mobile targets are not to be used with the centre line tool. NOTE Important! The mobile targets are not to be used with the optional trailer bar.
  • Page 72 This page is intentionally left blank...

  • Page 73: System Start-Up

    During installation and if experiencing communication problems: To prevent Bluetooth conflicts during installation and communication problems, the internal Bluetooth should be disabled before the JOSAM Bluetooth dongle (JT621) is inserted. For Bluetooth connection instructions, see the Homebase Installation Guide and Registration Manual.

  • Page 74: Connect The Measuring Head And Distance Laser

    i-track II System start-up Connect the measuring head and distance laser Click on the drop down menus for measuring head 1 and measuring head 2 and choose the correct serial number for the unit. The software will display a list of serial numbers with Bluetooth connection in the drop down list. The centre line tool is only visible if pre-selected in the Workflow settings window, see page 57.
  • Page 75 i-track II System start-up Click on [Connect to Units] The Bluetooth LED on the unit will display a steady blue light to indicate that they are connected. The software will now display that the units are connected. If the software cannot find the units, click on [Search for units] NOTE Check the calibration of the measuring heads regularly, see "Measuring unit...
  • Page 76 This page is intentionally left blank...

  • Page 77: Frame Centre Line Measurement

    i-track II Measure frame reference Frame centre line measurement NOTE Measure Frame Reference for chassis centre line is to be performed according to customer requirements. Mount measuring head on to the inner groove of the axle on the centre line tool. In the Start window click on either [New Order] if starting a new order.
  • Page 78 i-track II Measure frame reference Displays the connected units. Displays the centre line tool (if pre-chosen) is connected. Displays units are disconnected. Setup Access to the Main menu and Calibration and demo mode. Check the demo box to run the software in demo mode. No measuring heads are needed. Measure Starts the measurement process.
  • Page 79 i-track II Measure frame reference The symbol informs the user that connection between the target and the measuring head has not been established. When the red cross is no longer displayed , the measuring head has established contact with the targets. 2.
  • Page 80 i-track II Measure frame reference 6. Roll the centre line tool to the rear on the right side of the vehicle. Make sure that the laser is aimed at a similar position as on the left side of the chassis. 7.

  • Page 81: Measure Truck Or Bus

    4 Measure truck or bus Measure truck or bus Measure toe and camber Up to two operators may measure at the same time using two measuring heads, on each side of the vehicle. Note that only one measuring head at a time can measure and collect data. The second measuring head is only activated once data sent from the first measuring head has been acknowledged by the PC.
  • Page 82 4 Measure truck or bus 7. During rolling the screen will display the roll distance. The software always displays the direction in which the vehicle is physically moving. 8. When the required distance is reached the software will display a stop sign.
  • Page 83 4 Measure truck or bus After measuring is complete, the following options are visible: Measure: Measure all axles. Measure turn angles: (only visible when a drive axle is selected). See chapter: Measure Turn Angles (page 103). Measure twinsteer: (only visible when other steerable axles are selected).
  • Page 84 This page is intentionally left blank...

  • Page 85: Measure A Trailer

    i-track II Measure a trailer Measure a trailer Select scale setup for the coming measurement. Note! Carefully check the setup options for every new vehicle. Checkbox "Scales are reversed": Used if the vehicle is reversed into the work bay so that the front of the vehicle is facing the rear targets.
  • Page 86 i-track II Measure a trailer Press [Measure] to enter the measurement sequence. If using the "No boxes checked" or the "Scales are reversed" options you will be required to level the trailer bar. If using "Scales are mounted on the vehicle" the software will proceed directly to the measurement sequence.

  • Page 87: Measuring For The First Time

    i-track II Measure a trailer Measuring for the first time Place both measuring heads on the trailer bar, then press OK to start levelling the trailer bar. Adjust the trailer bar in level, indicated with green digits, using the instructions on the display. When ready, move the trailer bar sideways so that the laser points exactly in the centre of the king-pin or tow eyelet.

  • Page 88: Perform A Second Measurement

    i-track II Measure a trailer ATTENTION! Do not use the measuring equipment to rotate the wheel! When the wheels have been measured the operator is instructed to rotate the wheels 180°. Perform a second measurement Perform a second measurement of toe, camber and wheel positions, starting as instructed in the software.

  • Page 89: Measure A Semi-Trailer

    4 Measure a semi-trailer Measure a semi-trailer Mount a wheel adapter on each wheel of the vehicle. Make sure that each wheel adapter is levelled. Select scale setup for the coming measurement. Checkbox "Scales are reversed": Used if the vehicle is reversed into the work bay so that the front of the vehicle is facing the rear targets.
  • Page 90 4 Measure a semi-trailer Press [Measure] to enter the measurement sequence. If using the "No boxes checked" or the "Scales are reversed" options you will be required to level the trailer bar. If using "Scales are mounted on the vehicle" the software will proceed directly to the measurement sequence.
  • Page 91 4 Measure a semi-trailer Continue the flow by placing measuring head on a wheel adapter on the first axle and press the button on the measuring head to take the initial measurements of toe, camber and position of that wheel.

  • Page 92: Perform A Second Measurement

    4 Measure a semi-trailer Perform a second measurement Perform a second measurement of toe, camber and wheel positions. Start as instructed by the software. The software will display the results for toe, camber, out of square and parallelism measurements.

  • Page 93: Measure A Combined Vehicle

    i-track II Measure a combined vehicle Measure a combined vehicle Conditions All axles are measured simultaneously before adjustment. Mount a wheel adapter on each wheel of both vehicles. Make sure that all wheel adapters are levelled. Lock the steering wheel in the straight ahead position.
  • Page 94 i-track II Measure a combined vehicle When all wheels have been measured the operator is instructed to roll all wheels 180°. Rotate the wheels 180°. When the vehicle has reached the position the software shows a stop sign. ATTENTION! Do not use the measuring equipment to rotate the wheel! NOTE For a vehicle with varying tire sizes: Choose the most common tire size on the vehicle.

  • Page 95: Perform A Second Measurement

    i-track II Measure a combined vehicle Perform a second measurement Perform a second measurement of the toe, camber and wheel position, starting with the front axle. After the rolling measurement, the software has measured toe, camber, out of square, parallelism, and steering box position.
  • Page 96 This page is intentionally left blank...

  • Page 97: Measure An Articulated Bus

    i-track II Measure an articulated bus Measure an articulated bus With the I-track ll measuring method, all axles are measured simultaneously before adjustment. Mount a wheel adapter on each wheel of the vehicle and make sure that they are levelled. Lock the steering wheel in straight ahead position.
  • Page 98 i-track II Measure an articulated bus 3. Mount the measuring head on the wheel adapter as instructed by the software. 4. Press [OK] to start the measurements for toe, camber and wheel position for that particular wheel. Repeat the process on the wheels on both sides of the axle, one at a time. 5.

  • Page 99: Perform A Second Measurement

    i-track II Measure an articulated bus Perform a second measurement 6. After rolling, all wheels have to be measured again by moving the measuring head according to the software instructions. 7. After the second measurement the software has measured toe, camber, out of square, parallelism and steering box position alignment.
  • Page 100 This page is intentionally left blank...

  • Page 101: Adjust Toe And Camber

    i-track II Adjust toe and camber Adjust toe and camber The Adjust toe and camber mode displays live values during measurement. Adjustment to toe and camber can be made after measurements. Make sure that the measuring heads are placed on the selected axle for adjustment.
  • Page 102 This page is intentionally left blank...

  • Page 103: Measure Caster, Kpi, Toot And Max Turn

    i-track II Measure caster, KPI, TOOT and max turn Measure caster, KPI, TOOT and max turn This mode is used to measure the turn angles on a steering axle. Measuring max turn angles uses the camber values by default. ATTENTION Brake the wheels of the axle to be measured.
  • Page 104 i-track II Measure caster, KPI, TOOT and max turn 7. Turn 20° to the left or until the figures are displayed in green. 8. Press [OK] in the software or wait for I-track II to continue. 9. Turn to the maximum left. 10.

  • Page 105: Measure Twinsteer

    i-track II Measure twinsteer Measure twinsteer The Twinsteer axle menu is used to measure the parallelism of two steering axles. There are two methods implemented in the software, one including measurement of play and one without play. To change method, see "Software settings"...

  • Page 106: Measure Twinsteer With Play Procedure

    i-track II Measure twinsteer Measure twinsteer with play procedure 1. Perform a toe and camber measurement on all axles. For measurement procedure see "Measure toe and camber" on page 2. Lift both axles and put low friction plates under the wheels. 3.
  • Page 107 i-track II Measure twinsteer 7. Turn the wheel out to the green area (at least -100 mm/m) and hold until the stop sign disappears. 8. Turn the wheel back to the green area (between -25 and -35 mm/m) and hold until the stop sign disappears.
  • Page 108 i-track II Measure twinsteer 10. Turn the wheel out to the green area (at least +100 mm/m) and hold until the stop sign disappears. 11. Centre the steering wheel until the marker is within the green area. Hold until the stop sign disappears. 12.

  • Page 109: Adjust Twinsteer Axles

    i-track II Adjust twinsteer axles Adjust twinsteer axles The Adjust twinsteer axle mode displays the toe values simultaneously during the adjustment of the twin steered axles. 1. Click on [Adjust] 2. Click on [Adjust twinsteer]...

  • Page 110: Adjust Twinsteer Without Play

    i-track II Adjust twinsteer axles Adjust twinsteer without play To adjust twinsteer without play, follow the same procedure as for measuring without play, see "Measure without play procedure" on page 105. Adjust twinsteer with play 1. Mount the measuring heads to the wheel adapters as shown. 2.
  • Page 111 i-track II Adjust twinsteer axles 4. Center the steering wheel so that the marker is within the green area. 5. The system will now display the live values. Press [OK] to exit and save the twinsteer value. Twin steer values. 6.
  • Page 112 This page is intentionally left blank...

  • Page 113: Adjust Max Turn

    4 Adjust max turn Adjust max turn The Adjust max turn mode displays live values under measurement. Adjust max turn is made after toe, camber and max turn measurements. 1. Brake the wheels. 2. Make sure that the steering axle is slightly jacked up using two jacks and make sure that it is levelled.
  • Page 114 4 Adjust max turn 5. In the main window click on [Adjust max turn]. 6. Live values are shown in the adjust max turn window. 7. Turn the steering wheel to the left and press [OK] when finished adjusting.
  • Page 115 4 Adjust max turn When the result window appears, the results are saved. See the values marked with red circles.
  • Page 116 This page is intentionally left blank...

  • Page 117: Adas/Safety System Calibration

    i-track II ADAS/Safety system calibration ADAS/Safety system calibration ADAS = Advanced driver assistance systems NOTE A wheel alignment must have been made prior to ADAS calibration. 1. Choose [ADAS/Safety system calibration] 2. Mount the measuring heads on the calibration rod. 3.
  • Page 118 i-track II ADAS/Safety system calibration Lower the feet and make sure the platform is levelled. Press Next. Rotate the platform until the angle indicator turns green. Press Next. 7. Set the height on target according to the vehicle's configurations given in Tech Tool. When setting the height make sure that the yellow or blue arrow is level with the lower edge of the calibration target.
  • Page 119 This page is intentionally left blank...
  • Page 120 i-track II ADAS/Safety system calibration Calibration of target The target must be calibrated once a week or after a new installation to check that the Out of Square is within tolerance ie, ± 2mm/m. 2000 mm To oor LPOS calibration with high setting (2000 mm) 1.
  • Page 121 i-track II ADAS/Safety system calibration 1050 mm To oor LPOS calibration with low setting (1050 mm) 1. Adjust the height of the target by rotating the crank counterclockwise. 2. Adjust the height of the target until the little blue arrow is exactly level with the bottom edge of the red target holder.

  • Page 122: Tire Manager User Guide

    tire manager Tire Manager user guide...

  • Page 123: Tire Manager

    Tire Manager Tire Manager The Tire Manager (JOSAM TM), together with Homebase installed on a PC, is a measuring software designed for tracking tire wear. The Tire Manager is free to use in combination with an I-track ll license.
  • Page 124 tire manager Tire Manager Select vehicle. Click on [Next] to continue Enter VIN, Customer, Employee and additional comments if needed. Click on [Save and Start Measure]...
  • Page 125 tire manager Tire Manager The selected axle is highlighted in blue in the list to the left. General information per tire Information for each tire can be saved individually. When saving individually, click on the tire to be saved. The tire will be highlighted by a blue rectangle. The following tire information can be entered: –...
  • Page 126 This page is intentionally left blank...

  • Page 127: Maintenance Of Magnetic Wheel Adapter

    i-track II Maintenance: Magnetic wheel adapter Maintenance of magnetic wheel adapter Periodic maintenance Once a month – Check for any visible damage. – Tighten the nuts as necessary. – Clean the magnet feet from metallic dust. Once a year – Check the reference axle.
  • Page 128 i-track II Maintenance: Magnetic wheel adapter Replace an inner sleeve of a magnet foot 1. Remove the wheel adapter leg from the frame and turn it upside down. 2. Check if the polarization of the 4 magnets is clearly marked, as shown in illustration.

  • Page 129: Maintenance Of Low Friction Plate

    i-track II Maintenance: Low friction plate Maintenance of Low friction plate Preventive Maintenance Once a week – Check for any visible damage and that the low friction plate turns freely. Replace the V-rail and ball bearings 1. Remove the screw, Seat and O-ring. 2.
  • Page 130 i-track II Maintenance: Low friction plate Grease -APS2 or Q8 Rembrant EP2 Grease -APS2 or Castrol Rubber Grease 3. Replace with new ball bearings and V-rail. When replacing the ball bearings and the V-rail, lubricate with Q8 Rembrant EP2 Grease -APS2 (for ball bearings) Castrol Rubber Grease (for V-rail).

  • Page 131: Maintenance Of Measuring Head

    i-track II Maintenance: Measuring head Maintenance of measuring head Charger connector Detector Protection cover Spirit level Buttons and LED´s on the measuring unit The measuring head is powered on with the ON/OFF button and should be kept switched on. Connect to a charger at (A), when not in use. Power LED Green: 30–100 % battery capacity.

  • Page 132: Periodic Maintenance

    i-track II Maintenance: Measuring head Periodic maintenance Once a week • Wipe the detector lens with a dry clean cloth. • Calibrate the measuring heads. Battery The measuring heads are supplied with Li-Ion batteries. When the control unit is not in use it shall be connected to the charger connector.

  • Page 133: Calibration

    i-track II Maintenance: Measuring head Calibration To ensure that the system keeps the accuracy within limits, the measuring heads must be regularly calibrated. Tools needed: - locking excenter JT31117 WARNING It is imperative that all calibration is performed with the highest precision. Mistakes in the calibration procedure will result in incorrect measuring values.
  • Page 134 i-track II Maintenance: Measuring head Unit 2 7. Switch to measuring unit number 2, still working on the same wheel. 8. Centre the bubble on top of the measuring unit. 9. Press the OK button on the measuring head, to get the values for unit 2. 10.
  • Page 135 i-track II Maintenance: Measuring head Toe calibration ATTENTION The axle should not be jacked up. The toe calibration menu is used to calibrate the Toe angle function in the measuring heads. Mount a wheel adapter and measuring head on the left side of a non-steering axle. The distance to scale preferably 3 meters.
  • Page 136 i-track II Maintenance: Measuring head 6. Loosen the measuring head on the wheel adapter reference axle using the locking excenter. 7. Rotate the measuring unit 180° until upside down. 8. Adjust until the top bubble indicates the measuring head is horizontal. 9.

  • Page 137: Calibrate Camber

    i-track II Maintenance: Measuring head Calibrate camber ATTENTION The axle should not be jacked up. The camber calibration is used to calibrate the camber angle function in the measuring heads. To do this, perform a camber measurement. The same measurement is then repeated with the measuring head turned 180°...
  • Page 138 i-track II Maintenance: Measuring head Old calibration and new calibration camber values are shown. The difference between readings should not exceed 2’ (= 0.6 mm/m). To save the calibration in the measuring head, click on [Store calibration] To set the calibration to default click on [Restore factory calibration] If difference exceeds 2´...

  • Page 139: Error Messages

    i-track II Error messages Error messages The following error messages can appear in the measurement window. The Centre line tool is incorrectly placed. Check position of measuring heads Check measuring heads.
