PSoC
3
®
QUICK START GUIDE
PSOC3-DEV-BOARD-Rev2
New & Improved!
Current Features:
- CapSense
- RGB Color Mixing
- USB Communication
Recently added features:
- Analog Input
- JTAG Debugging
- Additional Expansion Connector
to allow for parallel application
development
Programming USB Interface
Analog Input
Touch Pad
Contact your local Future Advanced Engineering Team
with your design requirements today!
www.FutureElectronics.com
PSoC is a registered trademark and Creator is a trademark of Cypress Semiconductor Corp.
User USB Interface
FX2LP Programming Device
JTAG Connector
FX2LP / MiniProg Selector
PSoC 3
Boost Regulator
Expansion Connectors
Reset Button
1-888-880-3449
Advertisement
Summary of Contents for Future Electronics PSoC 3
- Page 1 User USB Interface QUICK START GUIDE FX2LP Programming Device Analog Input JTAG Connector PSOC3-DEV-BOARD-Rev2 FX2LP / MiniProg Selector New & Improved! PSoC 3 Current Features: - CapSense Boost Regulator - RGB Color Mixing - USB Communication Recently added features: Expansion Connectors...
- Page 2 PSoC ® QUICK START GUIDE PSOC3-DEV-BOARD-Rev2 Verify the kit contents Connect the PSoC 3 board to the Using a small screwdriver, move the computer using a USB cable attached potentiometer from right to left and to programming connector see the blue LED change intensity...
