No.
Description
1
Vitoria High Level Cistern inc. Flush Fittings
2
Vitoria High Level Pipe Kit
3
Vitoria Oak Toilet Seat
4
Vitoria High / Low Level Pan
200mm
397mm
FAQ's
What side is the inlet located? Left or right - reversible
Are there any other compatible seats? Vitoria White Toilet Seat - TS850WSC
Can this pan be used with a side connection outlet pipe? Yes
The cistern lid won't shut/the cistern isn't working correctly.
heights. Refer to instruction manual supplied with WC.
Can the pull chain be installed on the left? No
© Roper Rhodes Ltd.
Tavistock, Brassmill Lane Trading Estate, Bath, BA1 3JF
T. 01225 787870 | F. 01225 448877 | E. tavistock@roperrhodes.co.uk | W. www.tavistock-bathrooms.co.uk
Product Code
Fixings included
CH850S
HLK850S
TS850NOSC
PL850S
1
2
3
4
481mm
Ø102mm
195mm
HIGH LEVEL WC
Gross Weight
Yes
---
Yes
---
Yes
---
Yes
---
Cistern Settings:
Full Flush Volume: 6L
Floor Fixing Kit:
x2
x2
158mm
375mm
REF: JS.TAV | 08.13 V1.00
Net Weight
---
---
---
---
x2
x2
DIAGRAMS NOT TO SCALE
ALL DIMENSIONS IN MM
TOLERANCE OF ± 5MM
