Classy Caps SSL810 Lighting Instructions

Classy Caps Mfg. Inc.
Kingsville, Ontario, Canada
www.fencecaps.com
Mod. SSL810
Lighting Instructions

How Your Solar Powered Street Light Works

• The solar panel converts sunlight energy into electricity during the day. The
photocell automatically turns the light on at night with the electricity stored in
the batteries. It requires no wiring, because it runs off the sunlight energy to
recharge the batteries so there is no cost to run the solar fixture.
• The number of hours the light stays on depends on your geographical location, weather conditions
and seasonal sunlight availability. Allow 24 hours for the fixture to fully charge. Avoid placing the
fixture by other light sources, as this may cause the solar light to turn off automatically.

Includes:

1 – Solar Light Fixture
1 – Installation Accessories

Installation

Loosen four nuts on the end of the lamp body, put the post of wall bracket into the
•
lamp body, then retighten four nuts and press the green switch to "ON.". – Fig. 1.
•
•
Pole Mount: Install the light fixture to the pole using included pole bracket
and mounting bolts. –

Remote Options

A) Turn the switch to ON. The light fixture will turn on to 100% brightness,
after approximately 30 seconds the light will turn to 50% brightness. When
the motion sensor is activated, the light will return to 100% brightness. – Fig. 2
B) Push the corresponding button to activate the light from 25%, 50%,
75%, 100% brightness (continuous). – Fig. 2
C) Timer Function: Push the corresponding button to activate the light from
2 hours, 3 hours, 5 hours, 6 hours, or 8 hours at 100% brightness. After the
time elapses the light will turn to 50% brightness. When motion is detected,
the light returns to 100% brightness for approximately 30 seconds. – Fig. 2

To Replace The Battery

1) Unscrew the battery cover located on the bottom of the solar light fixture. –
2) Replace the battery with a new rechargeable battery of equal capacity. Ensure the
polarity is correct.
3)
Allow the fixture to receive a minimum of 24 hours of sunlight to allow the
rechargeable battery to reach maximum capacity.

Troubleshooting

If the light does not turn on at dusk after 24 hours of charging:
• Check the battery to make sure it is making secure contact with the terminal.
• Be sure the solar panel is in a relatively sunny location.
• Make sure the solar panel is not affected by other light.

Maintenance

Periodically clean light fixture with soft cloth and warm soapy water.

One Year Limited Warranty

This product is warranted to be free from defects in workmanship or materials at the time of purchase for one year,
(excluding batteries). Should a defect occur, please contact our customer service line at 1-866-460-4604 for service. Should
any evidence of defects in material or workmanship appear within the warranty period after the date of purchase, Classy
Caps Mfg. Inc. will either repair or replace the product at its option. Classy Caps Mfg. Inc. is not responsible for injury,
property damage, or other consequential damages or damages to third parties arising directly or indirectly from an actual or
alleged defect in material or workmanship of the product.
1 – Wall Bracket & Post Mount
1 – Remote Control
Fig. 4
Mod. SSL810
Lighting Instructions
FIG 1
ON/OFF
FIG 2
Brightness Control
2 Hour Timer 6 Hour Timer
3 Hour Timer
8 Hour Timer
5 Hour Timer
Pre-drilled Holes
FIG 3
Mounting Anchors
FIG 4
Fig. 5
FIG 5
