Samplex Europe SEC-1260E Owner's Manual

Switch mode battery charger

Advertisement

Quick Links

AUTOMATIC BATTERY CHARGER
Switch Mode Battery Charger
Model No.
SEC - 1245E
SEC - 1260E
SEC - 1280E
SEC - 2425E
SEC - 2440E
OWNER'S MANUAL
Please read this manual before operating your charger

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SEC-1260E and is the answer not in the manual?

Questions and answers

Summary of Contents for Samplex Europe SEC-1260E

  • Page 1 AUTOMATIC BATTERY CHARGER Switch Mode Battery Charger Model No. SEC - 1245E SEC - 1260E SEC - 1280E SEC - 2425E SEC - 2440E OWNER’S MANUAL Please read this manual before operating your charger...
  • Page 2: Table Of Contents

    CONTENTS Important safety precautions Description Features Components and accessories Specifying lead acid batteries and chargers Charging stages Cooling Protections Installation Preparing the charger for operation Remote Panel Operation Troubleshooting Internal / external fuse ratings Speci cations Warranty information...
  • Page 3: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS Hazardous conditions may result if the charger is not installed or operated correctly. Please read the following instructions to prevent personal injury or damage to the charger. BATTERY RELATED • To reduce the risk of battery explosion, follow these instructions and those marked on the battery.
  • Page 4: Description

    DESCRIPTION SEC-1245E/SEC-1260E/SEC-1280E (for 12 V batteries) SEC-2425E and SEC-2440E (for 24 V batteries) are high current, 3 Stage Chargers that deliver 45 A 60 A, 80 A, 25 A and 40 A respectively for almost 75% to 80% of the charging cycle ensuring a very fast, safe and complete charging of lead acid batteries.
  • Page 5: Components And Accessories

    COMPONENTS AND ACCESSORIES 1. Output Connnector + Bank 1 2. Output Connector + Bank 2 3. Output Connector - Common 4. Charging Indicator LED 5. DIP Switches for mode selection 6. Jack for Remote Panel 7. Push Switch for Half Power Mode 8.
  • Page 6: Specifying Lead Acid Batteries And Chargers

    SPECIFYING LEAD ACID BATTERIES AND CHARGERS FLOODED / WET CELL AND SLA (SEALED LEAD ACID) BATTERIES There are two categories of lead acid batteries – Flooded/Wet Cell and Sealed Lead Acid (SLA). A flooded/wet cell battery has a high tolerance to overcharging. However, it will release hydrogen gas when charging that must be properly vented and the water level must be checked frequently.
  • Page 7 UNITS OF BATTERY CAPACITY The battery capacity is the measure of the energy the battery can store and deliver to a load. It is determined by how much current any given battery can deliver over a stipulated period of time. The energy rating is expressed in Ampere Hours (AH). For example, as one of the bench marks, the battery industry rates batteries at 20 hour rate i.e.
  • Page 8 DEPTH OF DISCHARGE AND BATTERY LIFE The more deeply a battery is discharged on each cycle, the shorter the battery life. Using more batteries than the minimum required will result in longer life for the battery bank. A typical cycle life chart is given at Table 2 below: Table 2.
  • Page 9 Parallel Connection Battery 4 Battery 3 Battery 2 Battery 1 Cable A 12V Charger Cable B Fig 2. Parallel Connection When two or more batteries are connected in parallel, their voltage remains the same but their AH capacities add up. Fig. 2 above shows 4 pieces of 12 V, 100 AH batteries connected in parallel to form a battery bank of 12 V with a capacity of 400 AH.
  • Page 10 CAUTION! CAUTION When 2 or more batteries / battery strings are connected in parallel and are then connected to a charger (See Figs. 2 and 3 given above), attention should be paid to the manner in which the charger is connected to the battery bank. Please ensure that if the positive output cable of the battery charger (Cable “A”) is connected to the positive battery post of the first battery (Battery 1 in Fig.
  • Page 11 CHARGING BATTERIES The batteries can be charged by using good quality AC powered battery charger or from alternative energy sources like solar panels, wind or hydro systems. Make sure an appropri- ate battery charge controller is used. It is recommended that the batteries may not be charged at current >...
  • Page 12: Charging Stages

    CHARGING STAGES Stage 2 Stage 3 Stage 1 Uo Phase I Phase U Phase Timed for 4/8 Hours Curve for Volta g e U, U 80% of current 10% of current ca p acit y of char g er ca p acit y of char g er Curve for Current, I Time, Hours...
  • Page 13 60 A (SEC-1260E), 80 A (SEC-1280E) and 25 A (SEC-2425E), 40 A (SEC-2440E). The charger will exit current limit condition and will now output constant voltage of U = 13.8 V (SEC-1245E SEC-1260E and SEC-1280E) or constant voltage U = 27.6 V (SEC-2425E SEC-2440E).
  • Page 14 When the charging current reduces to approximately 10% of the charger capacity “I” (4.5A+/-0.5A for SEC-1245E, 6 A +/0 .5 A for SEC-1260E, 8 A +/0 .5 A for SEC-1280E 2.5A+/-0.5A for SEC-2425E and 4 A +/- 0.5 A for SEC-2440E), the charger automatically changes over to “Stage 3 - Float / Maintenance Charge Mode (U Phase)”.
  • Page 15 5A+/-0.5A Stage 3 – Constant Voltage, Float or Maintenance Charge Mode (U Phase): During this mode, the charger outputs a constant voltage U = 13.8 V (SEC-1245E, SEC-1260E and SEC-1280E) or 27,6 V (SEC-2425 and SEC-2440E). This helps in maintaining full capacity of the battery and also provides replacement charge to overcome self discharge of the battery.
  • Page 16: Cooling

    Please note that the fan will be off in the Float Stage 3 (The Charging Indicator LED will be Green). The operation of the fan is controlled by the current supplied by the charger as follows: SEC-1245E SEC-1260E SEC-1280E SEC- 2425E SEC-2440E Switches on when change over from Float stage (“U” Phase) to Boost stage (“Uo”...
  • Page 17: Protections

    The current drawn by the load is automatically limited to a maximum of 45 A for SEC-1245E (22.5 A in “Half Power Mode”), 60 A for SEC-1260E (30 A +/- 1 A in “Half Power Mode”), 80 A for SEC-1280E (40 A +/- 1 A in “Half PowerMode”) 25 A for SEC-2425E (12.5 A +/- 1 A) and 40 A for SEC-2440E (20 A +/- 1 A when in “Half...
  • Page 18: Installation

    3 pieces of “pin” style terminal lugs have been provided as follows: • For SEC-1245E Will accomodate up to 25 Mmq cable • For SEC-1260E Will accomodate up to 35 Mmq cable • For SEC-1280E Will accomodate up to 35 Mmq cable •...
  • Page 19: Preparing The Charger For Operation

    AC power is available to the charger (the maximum charging current of 45A of SEC-1245E , 60 A of SEC-1260E, 80 A of SEC-1280E, 25A of SEC-2425E and 40 A of SEC-2440E will be shared among the connected banks of the batteries depending upon their discharged states).
  • Page 20 Always change the DIP Switch setting when the charger is off, i.e. after disconnecting the charger from the AC input power). NOTE: The voltages are for battery temperature of 26,7º C DIP Switch Setting for SEC-1245E, SEC-1260E & SEC-1280E Float Boost...
  • Page 21 DIP Switch Setting for SEC-2425E, SEC-2440E Float Boost Battery Type Charging Stages / Application Stand-alone charging OFF * ON * 27.6 V * 29.6 V * Fleece / AGM * 3 Stages (Stages 1, 2, 3) 27.6 V 28.8 V Wet / Gel 3 Stages (Stages 1, 2, 3) Charging loaded battery...
  • Page 22 A provision has been made to reduce the maximum charging current to approxi- mately half: 22.5A +/- 1 A for SEC-1245E 30 A +/- 1 A for SEC-1260E, 40 A +/- 1 A for SEC-1280E, half: 12.5 A +/- 1 A for SEC-2425E and 20 A +/- 1 A for SEC-2440E.
  • Page 23: Remote Panel

    • Red LED “I Phase” is lighted – Indicates that charger is in Stage 1 - ConstantCurrent, Bulk Charge Mode (“I” Phase) and is delivering 45 A to 36 A (SEC- 1245E), 60 A to 48 A (SEC-1260E), 80 A to 64 A (SEC-1280E), 25A to 20 A (SEC-2425E) or 40 A to 32 A (SEC-2440E)
  • Page 24: Operation

    Constant Overcharge Voltage, Timed Absorption / Boost Charge Stage (“Uo” Phase) and is delivering between 36 A to 4.5 A (SEC-1245E),48 A to 6 A (SEC-1260E), 64 A to 8 A (SEC-1280E), 20 A to 2.5 A (SEC-2425E) or between 32 A to 4 A (SEC2440E) •...
  • Page 25 Stage 3 - Constant Voltage, Float or Maintenance Charge Mode (“U” Phase). The charger is delivering < 4.5 A +/- 0.5 A (SEC-1245E) < 8.5 A +/- 0.5 A (SEC-1260E), < 10 A +/- 0.5 A (SEC-1280E), < 2.5 A +/- 0.5 A (SEC-2425E) or < 2.5 A +/- 0.5 A (SEC- 2440E).
  • Page 26 Negative (Neg, N, -) post. 2. Attach a piece of at least 1.8mtr. of 16 Mmq (SEC-1245E/2425E) 25 Mmq (SEC-1260E/1280E/2440E) 4 insulated battery cable to the Negative battery post. 3. Connect the Positive (Red) DC cable from the charger to the Positive battery post 4.
  • Page 27 POWERING OTHER DC LOADS The charger can be used as a power supply or as a DC UPS (DC Un-interruptible Power Supply. For both these applications, first set switches S1 and S2 of DIP Switch (5) to off position to set the charger to work in 2 stage mode (See under “Selecting the Type of Battery and Charging Stages”).
  • Page 28: Troubleshooting

    TROUBLESHOOTING The symptoms of abnormal operation and the possible cause(s) and remedies are given in the succeeding paragraphs There is no output. The AC power on / off switch (9) does not illuminate when switched on. The charging indicator LED (4) is off (On the Remote Panel (15), the Green LED under “Power”...
  • Page 29 45A for “Half Power Mode” & 22.5 A +/- 1 A for SEC-1245E, 60 A (30 A +/- 1 A for “Half Power Mode”) for SEC-1260E, 80 A (40 A +/- 1 A for “Half Power Mode”) for SEC-1280E, 25A for “Half Power Mode” 12.5+/- 1A for SEC-2425 or more than 40 A (20 A +/- 1 A for “Half Power Mode”) for SEC-2440E.
  • Page 30: Internal / External Fuse Ratings

    22.5 A+/- 1 A for SEC-1245E, 30 A +/- 1 A for SEC-1260E, 40 A +/- 1 A for SEC-1280E, 12.5A +/- 1 A for SEC-2425E and 20 A +/-1 A for SEC-2440E. Hence, the charging time will increase. Switch off the “Half Power Mode”...
  • Page 31: Speci Cations

    SPECIFICATIONS PARAMETER SEC-1245E Nominal Input Voltage 230 VAC /50 Hz (207 to 253 VAC) Input Current At 230 VAC input 5.2A Output Voltage, VDC Absorption / Boost, “Uo”* 14.8 V/14.4 V +/-0.05 V Float / Maintenance, “U”* 13.8 V +/-0.05 V Maximum Bulk Charging Current, I Normal operation Half Power Mode...
  • Page 32 SPECIFICATIONS PARAMETER SEC-1260E Nominal Input Voltage 230 VAC /50 Hz (207 to 253 VAC) Input Current At 230 VAC input 6.8A Output Voltage, VDC Absorption / Boost, “Uo”* 14.8 V/14.4 V +/-0.05 V Float / Maintenance, “U”* 13.8 V +/-0.05 V...
  • Page 33 SPECIFICATIONS PARAMETER SEC-1280E Nominal Input Voltage 230 VAC /50-60 Hz (207 to 253 VAC) Input Current At 230 VAC input 8.7A Output Voltage, VDC Absorption / Boost, “Uo”* 14.8 V/14.4 V +/-0.05 V Float / Maintenance, “U”* 13.8 V +/-0.05 V Maximum Bulk Charging Current, I Normal operation Half Power Mode...
  • Page 34 SPECIFICATIONS PARAMETER SEC-2425E Nominal Input Voltage 230 VAC /50-60 Hz (207 to 253 VAC) Input Current At 230 VAC input 5.6A Output Voltage, VDC Absorption / Boost, “Uo”* 29.6 V/28.8 V +/-0.05 V Float / Maintenance, “U”* 27.6 V +/-0.05 V Maximum Bulk Charging Current, I Normal operation Half Power Mode...
  • Page 35 SPECIFICATIONS PARAMETER SEC-2440E Nominal Input Voltage 230 VAC /50-60 Hz (207 to 253 VAC) Input Current At 230 VAC input 8.7A Output Voltage, VDC Absorption / Boost, “Uo”* 29.6 V/28.8 V +/-0.05 V Float / Maintenance, “U”* 27.6 V +/-0.05 V Maximum Bulk Charging Current, I Normal operation Half Power Mode...
  • Page 36: Warranty Information

    WARRANTY INFORMATION 2 YEAR Limited Warranty SEC-1245E / SEC-1260E / SEC-1280E / SEC-2425E / SEC-2440E battery chargers manufactured by Samlex Europe, (the “Warrantor”) are warranted to be free from defects in workmanship and materials under normal use and service. This warranty is in effect for 2 years from the date of purchase by the user (the “Purchaser”).
  • Page 37 Notes:...
  • Page 38 Attach receipt...
  • Page 39 www.samlex.com www.samlex-solar.com...
