User Manual

WNFF90JGR

Safety information.......................................2

Safety instructions...................................... 3

Product description.....................................7

Before first use........................................... 9

Hob - Daily use......................................... 10

Hob - Hints and tips.................................. 12

Hob - Care and cleaning...........................13

CONTENTS

www.white-westinghouse-intl.com

Oven - Daily use ...................................... 14

Oven - Clock functions............................. 16

Oven - Using the accessories...................17

Oven - Hints and tips................................ 19

Oven - Care and cleaning.........................23

Troubleshooting........................................26

Installation................................................ 28

Table of Contents

Need help?

Do you have a question about the WNFF90JGR and is the answer not in the manual?

Questions and answers

Summary of Contents for White-Westinghouse WNFF90JGR

Page 1: Table Of Contents
User Manual WNFF90JGR CONTENTS Safety information........2 Oven - Daily use ........14 Safety instructions........3 Oven - Clock functions......16 Product description........7 Oven - Using the accessories....17 Before first use........... 9 Oven - Hints and tips........ 19 Hob - Daily use......... 10 Oven - Care and cleaning......23...
Page 2 SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability.
Page 3: Safety Information
SAFETY INFORMATION Metallic objects such as knives, forks, spoons and lids • should not be placed on the hob surface since they can get hot. Remove any spillage from the lid before opening. Let the hob • surface cool down before closing the lid. Internally the appliance becomes hot when in operation.
Page 4: Safety Instructions
SAFETY INSTRUCTIONS • Make sure that the electrical information This appliance is suitable for the following on the rating plate agrees with the power markets: BH KW OM QA AE supply. If not, contact an electrician. Installation • Always use a correctly installed shockproof socket.
Page 5 SAFETY INSTRUCTIONS • The information about the gas supply is • Do not let sparks or open flames to on the rating plate. come in contact with the appliance when • This appliance is not connected to a you open the door. device, which evacuates the products of •...
Page 6 SAFETY INSTRUCTIONS • Use only stable cookware with the correct shape and diameter larger than • Do not change the specification of the the dimensions of the burners. lid. • Make sure the flame does not go out • Clean the lid regularly. when you quickly turn the knob from the •...
Page 7 SAFETY INSTRUCTIONS • Remove the door catch to prevent children and pets to get closed in the appliance. • Flat the external gas pipes. Service • To repair the appliance contact an Authorised Service Centre. • Use original spare parts only.
Page 8: Product Description
PRODUCT DESCRIPTION Cooker specification Check the table to see your appliance's detailed specification. MODEL DENOMINATION AND PNC NUMBER Cooling fan Initial gas settings Natural gas Additional gas injectors Hob integrated ignition on the control knob Hob ignition on the spark generator button Oven integrated ignition on the control knob Oven ignition on the spark generator button Hob thermocouple...
Page 9 PRODUCT DESCRIPTION General overview Button for the spark generator Knob for the Minute Minder Knob for the grill Knob for the oven functions Button for the lamp Knobs for the hob Grill Lamp Turnspit hole Shelf positions Cooking surface layout Auxiliary burner Steam outlet - number and position depend on the model...
Page 10: Before First Use
BEFORE FIRST USE WARNING! Refer to Safety chapters. Initial Cleaning Remove all accessories from the appliance. Refer to "Care and cleaning" chapter. Clean the appliance before first use. Put the accessories back to their initial position. Preheating Preheat the empty appliance to burn off the remaining grease.
Page 11: Hob - Daily Use
HOB - DAILY USE Adjust the flame after it is regular. WARNING! WARNING! Refer to Safety chapters. Do not keep the knob pushed for more Ignition of the hob burner than 15 seconds. If the burner does not light after 15 seconds, release the knob, turn it into the off position and try to light the burner again after minimum Always light the burner before you put...
Page 12 HOB - DAILY USE A) Burner cap B) Burner crown C) Ignition candle (if applicable) D) Thermocouple (if applicable) Turning the burner off To put the flame out, turn the knob to the off position WARNING! Always turn the flame down or switch it off before you remove the pans from the burner.
Page 13: Hob - Hints And Tips
HOB - HINTS AND TIPS • When the liquid starts to boil, turn down WARNING! the flame to barely simmer the liquid. Refer to Safety chapters. Cookware WARNING! Do not put the same pan on two burners. WARNING! Do not put unstable or damaged pots on the burners to prevent from spill and injury.
Page 14: Hob - Care And Cleaning
HOB - CARE AND CLEANING WARNING! Be very careful when you replace Refer to Safety chapters. the pan supports to prevent the hob top from damage. General information 2. The enamel coating occasionally can • Clean the hob after each use. have rough edges, so be careful when •...
Page 15: Oven - Daily Use
OVEN - DAILY USE WARNING! Refer to Safety chapters. Oven Functions OVEN FUNCTION APPLICATION Off position The appliance is off. 1 - 8 Heat settings Range of temperature levels adjustment for the oven. Grilling + Turnspit To grill flat food in the middle of the grill. To make toast.
Page 16 OVEN - DAILY USE Manual ignition of oven gas Turning off the oven burner burner To put out the flame, turn the knob to the off position In case of absence of the electricity you can ignite the oven burner without an Grilling electrical device.
Page 17: Oven - Clock Functions
OVEN - CLOCK FUNCTIONS Minute Minder This function has no effect on the operation of the appliance. Turn the knob for the timer as far as it goes, then turn it to necessary time period. After the time period is completed, an acoustic signal sounds.
Page 18: Oven - Using The Accessories
OVEN - USING THE ACCESSORIES Using the turnspit WARNING! WARNING! Refer to Safety chapters. Be careful when you use the turnspit. Inserting the accessories The forks and the spit are sharp. There is a risk of injury. Wire shelf: WARNING! Use oven gloves when you remove the turnspit.
Page 19 OVEN - USING THE ACCESSORIES 5. Install the first fork on the spit, then put the meat on the turnspit and install the second fork. Make sure that the meat is in the middle of the spit. 6. Use the screws to tighten the forks. 7.
Page 20: Oven - Hints And Tips
OVEN - HINTS AND TIPS • You can extend baking times by 10 – 15 WARNING! minutes if you bake cakes on more than one shelf position. Refer to Safety chapters. • Cakes and pastries at different heights do not always brown equally at first. If this occurs, do not change the temperature setting.
Page 21 OVEN - HINTS AND TIPS Cooking tables Casseroles THERMOSTAT SHELF POSI- FOOD QUANTITY (KG) TIME (MIN) POSITION TION 2.5 - 4.0 45 - 50 Lasagna Cannelloni 2.5 - 4.0 45 - 50 Potato gratin 2.5 - 3.0 45 - 50 Macaroni oven 4.0 - 4.5 40 - 45...
Page 22 OVEN - HINTS AND TIPS Pizza THERMOSTAT SHELF POSI- FOOD QUANTITY (KG) TIME (MIN) POSITION TION Thin 1.5 - 2.5 20 - 30 Thick 1.5 - 2.0 25 - 30 Calzone 1.5 - 2.5 25 - 30 1) Preheat the oven for 15 minutes. Cakes THERMOSTAT SHELF POSI-...
Page 23 OVEN - HINTS AND TIPS QUANTITY SHELF POSI- FOOD GRILL POSITION TIME (MIN) (KG) TION Mackerel 2.5 - 3.0 20 - 25 Toast browning 1.0 - 1.2 5 - 8 Toast Hawai 1.0 - 2.0 15 - 20 1) Preheat the oven for 10 minutes. Revolving frying QUANTITY SHELF POSI-...
Page 24: Oven - Care And Cleaning
OVEN - CARE AND CLEANING WARNING! Refer to Safety chapters. Spots or discolouration of the catalytic surface have no effect on catalytic Notes on cleaning properties. • Clean the front of the appliance with a WARNING! soft cloth with warm water and a cleaning agent.
Page 25 OVEN - CARE AND CLEANING 2. Lift and turn the levers on the two 4. Put the door on a soft cloth on a stable hinges. surface. 5. Use a screwdriver to remove 2 screws from bottom edge of door. 3.
Page 26 OVEN - CARE AND CLEANING WARNING! Danger of electrocution! Disconnect the fuse before you replace the lamp. The lamp and the lamp glass cover can be hot. 1. Deactivate the appliance. 2. Remove the fuses from the fuse box or deactivate the circuit breaker.
Page 27: Troubleshooting
TROUBLESHOOTING WARNING! Refer to Safety chapters. What to do if... PROBLEM POSSIBLE CAUSE REMEDY There is no spark when you The hob is not connected to Check if the hob is correctly try to activate the spark an electrical supply or it is connected to the electrical generator.
Page 28 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE REMEDY The oven does not heat up. The necessary settings are Make sure that the settings not set. are correct. The turnspit does not rotate. The turnspit is not correctly Refer to "Using the turn- installed into the turnspit spit".
Page 29: Installation
INSTALLATION Minimum distances WARNING! DIMENSION Refer to Safety chapters. Location of the appliance You can install your freestanding appliance with cabinets on one or two sides and in the corner. Technical data Keep a distance of about 1 cm between the appliance and the back DIMENSION wall to make sure that the lid opens.
Page 30 INSTALLATION BURNER Ø BYPASS 1/100 MM Oven Gas burners for NATURAL GAS G20 20 mbar NORMAL POWER INJECTOR MARK BURNER REDUCED POWER KW 1/100 MM Dual Rapid 0.72 Semi-rapid 0.43 Auxiliary 0.35 Oven Gas burners for LPG G30 28-30 mbar NORMAL POWER INJECTOR MARK BURNER...
Page 31 INSTALLATION WARNING! When installation is complete, make sure that the seal of each pipe fitting does not leak. To check the seal use a soap solution, not a flame. The gas supply ramp is on the rear side of the control panel. WARNING! Before you connect the gas, disconnect the appliance from the...
Page 32 INSTALLATION If the supply gas pressure is not constant or it is different from the necessary pressure, install an applicable pressure adjuster on the gas supply pipe. Adjusting the minimum gas level on the hob burner 1. Disconnect the appliance from the electricity.
Page 33 INSTALLATION Refer to "Hob - Daily use" chapter. 5. Turn the knob for the hob to the minimum position. 6. Remove the knob for the hob again. 7. Screw on slowly the bypass screw till the flame becomes minimum and stable.
Page 34 INSTALLATION 9. Set the maximum gas flow position on the knob for the oven functions and let the oven heat for at least 10 minutes. 10. Quickly turn the knob for the oven functions from maximum to the minimum gas flow position. Control the flame.
Page 35 INSTALLATION Make sure that the surface behind the appliance is smooth. You must install the anti-tilt protection. If you do not install it, the appliance can tilt. Your appliance has the symbol shown on the picture (if applicable) to remind you about the installation of the anti-tilt protection.
Page 36 INSTALLATION 126-130 275- 280 2. You can find the hole on the left side at the back of the appliance. Lift the front of the appliance and put it in the middle of the space between the cupboards. If the space between the bench cupboards is larger than the width of the appliance, you must adjust the side measurement to centre the appliance.
Page 37 ENVIRONMENT CONCERNS dispose appliances marked with the symbol Recycle the materials with the symbol with the household waste. Return the Put the packaging in applicable containers product to your local recycling facility or to recycle it. Help protect the environment contact your municipal office.
