June 2021© Toro MP5700 ROPS Cab Operation Manual
Toro MP5700 4-Post ROPS
* Shown with optional Features *
* Operator must wear respirator when operating sprayer *
Toro MP5700 4-Post ROPS
This ROPS is designed and built to fit the Toro MP5700 (2011 Update) and MP5800.
Designed and Built by:
Tektite Manufacturing Inc:
427 Buffalo Street
P.O. Box 639
Winkler, MB
R6W 4A8
Canada
PH: 204-331-3463
Fax: 204-331-4159
sales@tektite.ca
www.tektite.ca
One year standard product warranty provided by Tektite.
Advertisement
Summary of Contents for Tektite Toro MP5700
- Page 1 * Shown with optional Features * * Operator must wear respirator when operating sprayer * Toro MP5700 4-Post ROPS This ROPS is designed and built to fit the Toro MP5700 (2011 Update) and MP5800. Designed and Built by: Tektite Manufacturing Inc: 427 Buffalo Street P.O.
- Page 2 June 2021© Toro MP5700 ROPS Cab Operation Manual Tektite Manufacturing Incorporated thanks you for purchasing a Toro MP5700 4-post ROPS! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of ROPS protection.
- Page 3 “as is” basis; c) wiper blades, light bulbs, fuses, clear vinyl or other consumables; d) glass where the point of failure has not been preserved intact and delivered to Tektite for analysis of the cause of the failure;...
-
Page 4: Safety Precautions
June 2021© Toro MP5700 ROPS Cab Operation Manual Safety Precautions Safety First Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use the features that are on this cab/ROPS. - Page 5 June 2021© Toro MP5700 ROPS Cab Operation Manual General Safety 1. Never let an unqualified or untrained driver operate the spray vehicle. 2. Keep a fire extinguisher, with ABC rating securely fastened in the ROPS. Maintain it and be familiar with its use.
- Page 6 June 2021© Toro MP5700 ROPS Cab Operation Manual Safe Operation on Rough Terrain 1. Drive the spray vehicle slowly on hillsides and curves to eliminate the danger of tipping. Avoid slopes which are too steep for safe operation. Avoid sharp uphill turns.
- Page 7 3. New ROPS decals and spray vehicle decals are available from your spray vehicle dealer. ROPS Safety 1. Install the ROPS in accordance with Tektite mounting instructions. Failure to do so may affect the ROPS ability to withstand a roll over.
-
Page 8: Switch Plate
June 2021© Toro MP5700 ROPS Cab Operation Manual Operating Instructions Important The following section locates, identifies and briefly describes the functions of all cab controls. All operators should familiarize themselves with control location and function prior to operating the utility vehicle. Failure to do so may result in unsafe operation of the utility vehicle and possible injury or death to operators and bystanders. - Page 9 Note: indicator light activates when 4-way flashers are on. Cab Circuit Protection The Tektite ROPS cab is wired to provide maximum protection against accidental circuit overload. The cab electrical components are also fused individually, and the fuse block is located behind the switch plate, in the centre of the ROPS. Locate access door labelled Fuses, and remove for access to examine the fuses.
- Page 10 June 2021© Toro MP5700 ROPS Cab Operation Manual After your ROPS has been installed: Before starting a spray vehicle equipped with a Tektite ROPS: 1. Clear the operator platform of all tools. Tools left in or around the ROPS and spray vehicle can cause operator interference which could lead to bodily injury and/or damage the machine.
- Page 11 Imp. Daryl Furkalo 2014-10-01 transmitted. The material remains the property of specified Tektite and shall be returned upon request. The Checked By: Date: Size: material may not be reproduced or disclosed to third X.X = 1/16"...
