Summary of Contents for Gartenhaus-King Irina
- Page 1 Name Irina 200x155/19 Zeichnung/Drawing Profil/Profile Datum/Date 1.9x11.4 02.12.2016...
- Page 2 2200 2000 1880 1842 2.56 m2 KU-2 84x173 Name Irina 200x155/19 Zeichnung/Drawing Grundplan; Plan Profil/Profile Datum/Date 1.9x11.4 02.12.2016...
- Page 3 Giebeldeckleiste Gable cover strip Dachbrett 1750 Roof board Giebelbrett Gable board Dachbalke/Wanbohle Roof beam/Wall beam Wand/Wall A 1392 6019 1960 1411 1550 Name Irina 200x155/19 Zeichnung/Drawing WAND/WALL A Profil/Profile Datum/Date 1.9x11.4 02.12.2016...
- Page 4 1750 Wand/Wall B 1392 6019 1960 1411 1550 Name Irina 200x155/19 Zeichnung/Drawing WAND/WALL B Profil/Profile Datum/Date 1.9x11.4 02.12.2016...
- Page 5 Dachbrett Roof board Traufenleiste 009 009 Eaves strip Traufenbrett Eaves board Wand/Wall 1 1842 6019 1960 1861 2000 Name Irina 200x155/19 Zeichnung/Drawing WAND/WALL 1 Profil/Profile Datum/Date 1.9x11.4 02.12.2016...
- Page 6 Giebelsegment Giebeldeckleiste 58x18 Gable diamond Gable cover strip Giebelbrett 90x18 Gable board Wand/Wall 2 6019 1960 1861 2000 Name Irina 200x155/19 Zeichnung/Drawing WAND/WALL 2 Profil/Profile Datum/Date 1.9x11.4 02.12.2016...
- Page 7 Stck. Profil Teileliste/Specification Profile Length Pcs. Irina 200x155/19 (mm) (mm) 1842 19x114 2000 1842 19x114 2000 1842 19x57 2000 1392 19x114 1750 1392 19x114 1550 19x114 1391 19x57 19x114 19x57 DACHBALKE - ROOF BEAM 1392 40x120 1750 DACHBRETTER - ROOF BOARDS...
