Products for VoIP SIP LAN networking Communications, Paging Amplifiers Systems and

Audio Applications. Zone Announcements, Night Ringer, Multicast general call,

Background music, Standard SIP call or Emergency call, SD memory with pre-recorded

messages, Relays for LAN drives.

Revision

Date

20/03/2017

TEMA TELECOMUNICAZIONI

"IP COMMUNICATION AND SECURITY COMPANY"

WWW.TEMATLC.IT

AD630

VoIP SIP 25W PoE Horn Speaker

IP65 grade of protection

Audio Over IP Network Series

PRODUCT MANUAL

Version HW 1.0 - Version SW 1.08m

Revision reason

Update

Prepared

MM, DP

Checked/Approved

DP, FL

Table of Contents

Need help?

Do you have a question about the AD630 and is the answer not in the manual?

Questions and answers

Summary of Contents for tema AD630

Page 1 TEMA TELECOMUNICAZIONI “IP COMMUNICATION AND SECURITY COMPANY” WWW.TEMATLC.IT AD630 VoIP SIP 25W PoE Horn Speaker IP65 grade of protection Audio Over IP Network Series Products for VoIP SIP LAN networking Communications, Paging Amplifiers Systems and Audio Applications. Zone Announcements, Night Ringer, Multicast general call, Background music, Standard SIP call or Emergency call, SD memory with pre-recorded messages, Relays for LAN drives.
Page 2 AD630VoIP SIP 25W / PoE Horn TEMA TELECOMUNICAZIONI DICHIARAZIONE DI CONFORMITÀ CE DECLARATION OF CONFORMITY CE TEMA TELECOMUNICAZIONI SRL Via C. Girardengo, 1/4 - 20161 MILANO declare under our sole responsibility that the product: Diffusore a Tromba VoIP SIP 25W PoE IP65 Product name...
Page 3 It is expressly not recommended maintenance inside the device which must be carried out by Tema Telecomunicazioni, the removal of the closures will invalidate the warranty and makes accessible internal parts with risk of electric shock.
Page 4: Table Of Contents
HORN 8.2. O ..........12 PENING OF THE COVER AND ACCESS TO INTERNAL PARTS PASSAGE OF CABLES 8.3. C AD630 ....................13 ONNECTING THE INTERNAL MODULE OF 8.4. C ................15 ORRECT CONNECTION OF AN ADDITIONAL PASSIVE SPEAKER 8.5. 100V AD630 IP H ............
Page 5: Presentation
LAN that originated the call to the AD630 horn, eg. to report the event to any auxiliary devices connected downstream.
Page 6 LEDs. Ideal to be or as 2nd speaker to the AD63x series IP-SIP controlled by the relay of the IP-SIP speakers. speakers of the AD630 series or by the AD335/06TP Passive 8 Ohm 6W speaker IP-SIP amplifier AD610, AD611, AD612 modules, with a call in progress add a with 100V audio line transformer.
Page 7: Features
• Free APP developed for smartphones/tablets with iOS and Android operating systems • AA-Videoconsole software for Windows XP/7/10 PC for management of TEMA IP terminals included • Programming via dedicated Web Interface with password protection • Possibility of software / firmware update via LAN •...
Page 8: Technical Specifications
Active call Led, call tone, Ding-dong ads Installation Ceiling mount, wall mount Housing Material Aluminium and ABS Grade of protection IP65, weather resistant (AD630) Storage temperature From -20° to +65°C Operating temperature From -20° to +55°C Relative humidity Up to 100%...
Page 9: Operation
Encoder that will redistribute on the LAN. The announcement from a AD630 SIP call to a specific AD630 device will stop the music that will be automatically restored at the end. IP PBX Access Point...
Page 10: Operating Modes
(normally closed) connected to the input. AD630 continuously monitors the status of the contact in the event of the condition of the activation stored on non- volatile memory card. As soon as possible it will begin to call the person who will manage the situation found at the telephone number programmed reproducing the message associated with the event.
Page 11: Multicast Audio Streaming
IP terminals of the Ethernet network. For Multicast are used class D IP addresses and they range from 224.x.x.x to 239.x.x.x. In our case the AD630 system is able to receive audio in Multicast into the specific IP channel and play it amplified.
Page 12: Installation Of The Device
We remind that the angle of sound diffusion of AD630 is a cone of about 100°. The wall mounting bar of AD630 has three holes. A hole is located in the center and two others are adjacent to 62mm distance from the central one.
Page 13: Connecting The Internal Module Of Ad630
Connecting the internal module of AD630 Inside of AD630 there is an electronic module for the management of communication functions on the VoIP network, and for amplification of the audio signal. The connection of the signal cables from the field must be carried out by qualified technical personnel, operate verifying that no cable is under voltage, also strictly comply with the instructions of the voltage and current values for the power supplies and other parts of the system.
Page 14 RJ45 LAN port (present on the electronic module) AD630 requires a LAN cable to connect to the network. If the port cable has also PoE, it will not be necessary to supply the module with other power sources (up to max 10W powers). For higher powers will be necessary to supply the module with other power source of 24 Vdc 2A or max 18Vac 2.5A.
Page 15: Correct Connection Of An Additional Passive Speaker
AD630VoIP SIP 25W / PoE Horn TEMA TELECOMUNICAZIONI 8.4. Correct connection of an additional passive speaker The power amplified SP1 is an output where it is possible to connect an external additional speaker passive paying attention to its polarity but especially to the load impedance which cannot be lower than 8 Ohm.
Page 16: 100V Audio Line For Additional Speakers Away From Ad630 Ip Horn
100V audio line for additional speakers away from AD630 IP Horn For special applications it is possible to generate from AD630 an audio line at a constant voltage of 100V of max 20W power using a Tema AD320/30 transformer to connect on the SP1 power output. In this way it is possible to install several other additional speakers (with internal transformer suitable for 100V line and selectable power) even at distances up to 200 meters from AD630.
Page 17: Programming
The default IP address of AD630 is "192.168.0.10". Remember that in order to successfully connect to the web interface of AD630, it is necessary that, in the IP addresses configuration of your PC, is present the subnet 192.168.0.x, where "x" is any number between 1 and 254 and different from 10.
Page 18 PC to its original state if necessary. Once the IP address of your PC is successfully configured, it is possible to reach the Web interface to configure AD630 at the address 192.168.0.10 . MAS-AD630-REV01EN...
Page 19: Access To Programming
AD630VoIP SIP 25W / PoE Horn TEMA TELECOMUNICAZIONI 9.2. Access to programming To program the device, it is sufficient to use a standard browser such as Explorer, Firefox, Chrome or others. The default address of the device is 192.168.0.10 with a mask of 255.255.255.0, and the user/password with which to connect are master/master.
Page 20: Network Parameters
Subnet mask: indicate the subnet mask to be assigned to AD630. • Default gateway: indicate the gateway that can enable AD630 to access to internet. • Primary and secondary DNS server: indicate the addresses of two DNS servers you want to use to resolve IP addresses.
Page 21: Sip Parameters
SIP server address: specify the IP address of the SIP PBX to which AD630 should connect. • Port: is the port number of the SIP PBX with which AD630 must operate. Generally it is the 5060, but some stations use a different port.
Page 22: General Parameters
Any mail sent as an attachment will have the image of someone who has pressed the call button. • Save a snapshot of the caller: (valid only for Tema Doorphones with camera). • Calling speaker volume: sets the volume of the audio to the external user. Possible values range from 0 (very low) to 9 (very strong).
Page 23: Set Of The Operating Mode
AD630VoIP SIP 25W / PoE Horn TEMA TELECOMUNICAZIONI • Microphone volume: Sets the microphone sensitivity and consequently the volume of the audio to the user within the company. Possible values range from 0 (very low) to 9 (very strong). •...
Page 24: Relay And Alarm Input Settings
AD630VoIP SIP 25W / PoE Horn TEMA TELECOMUNICAZIONI 9.7. Relay and alarm input settings On this page it is possible to choose the operating mode of the internal relays and the operating mode for external inputs: • Mode: sets the function to be associated to the relay. It is possible to choose between: Electric lock: is activated only upon receiving the activation code.
Page 25: Camera
TEMA TELECOMUNICAZIONI 9.8. Camera This page has no effect on the programming of the AD630 IP horn because there is no camera, the mask is provided only for intercom video applications of internal electronic module. • Brightness, contrast and color: can be adjusted to fit the image to your needs, but generally the default...
Page 26: Call Buttons
Call buttons AD630 has the possibility to make SIP calls, it is possible to connect 1 or 2 external keys that can be programmed to make calls to different numbers. The 4-pole terminal block allows to connect external buttons-keys in the points P1 and P2 and the window below allows the programming of any two keys.
Page 27: Messages Management
AD630VoIP SIP 25W / PoE Horn TEMA TELECOMUNICAZIONI 9.10. Messages management In this window it is possible to change/listen to the messages for “Calling”, “Alarms”, “Announcement” and “Ringer”. Memory contains a default message for each position, the user can change any of them and the messages format must be WAV PCM 8 kHz, 16 bit, mono.
Page 28 Audio Multicast Streaming By enabling this feature, AD630 will listen to the specified address/port, and can reproduce on its speaker any received audio streaming. This function has a lower priority than the normal telephone operation of the system (outgoing or incoming calls will block or prevent the reproduction of the audio stream).
Page 29: Calls Report
TEMA TELECOMUNICAZIONI 9.11. Calls Report When to the AD630 horn are connected one or two call buttons is kept a report of all dialed calls. The list is presented starting from the most recent call: The list can contain up to 250 entries, after which the older are deleted.
Page 30: Maintenance
Firmware version: displays the currently installed version of the program. It is possible to upload a different version (possibly provided by the technical support of TEMA) using the Browse/Update. Once you've uploaded the new version, the device must be restarted.
Page 31: Login Credentials
AD630VoIP SIP 25W / PoE Horn TEMA TELECOMUNICAZIONI 10.2. Login credentials By default, the user name and password for access to the configuration are master/master (lowercase). It is not possible to have more than one user (there are not hierarchical levels of programming), but it is possible to change the login credentials.
Page 32: Presentation And Use Of The "Aa Video Console" Software
11.1. Presentation This is the main program window. In the case of IP AD630 speakers that are not equipped with the camera, the program shows to the operator the IP speakers available to make announcements from PC. Into the network it is possible to have more than one PC running AA-Video Console program.
Page 33: Software Configuration For Sip Server Mode
11.2. Software configuration for SIP Server mode It is possible that the company owns or installs between the various IP AD630 audio devices also one or more IP Video Intercoms Tema AA-500 and AA-600 series. These can have the camera that checks and shows in window live images from the framing area.
Page 34: Software Configuration For Peer-To-Peer Mode
PC, it is necessary to of course set the IP address of the PC in the terminal parameters (AD630 or AA-500/600). Doing so, after pressing the button, the terminal will forward the call to the IP address of the PC where the "AA Video Console"...
Page 35: Introduction To Aa-Video Console App Version For Operating Systems Ios
The program allows to see the area captured by the built-in camera in all the IP VoIP SIP TEMA Audio and Intercoms, to operate the device relays and to speak directly with the visitor. The application can be downloaded from the Apple AppStore, can be easily found typing AAVIDECONSOLE in the search box.
Page 36 (each router / firewall has its own programming that it is not possible to generalize in this manual). Configuring Tema IP SIP terminals It is possible to control with the application up to 4 systems simultaneously. Also in the settings page is the menu to configure them:...
Page 37: Using The Application
The program allows to see the area captured by the built-in camera in all the IP VoIP SIP TEMA Doorphones, to operate the device relays and to speak directly with the visitor. The application is on the supplied CD ...
Page 38 AD630VoIP SIP 25W / PoE Horn TEMA TELECOMUNICAZIONI You must select the "Settings" button and allow installation: Method 2: copy aavideconsole.apk directly on the device connected to a computer via the USB cable normally supplied with the phone (from "My Computer" the phone is seen like a normal pen drive).
Page 39: Using The Application
AD630VoIP SIP 25W / PoE Horn TEMA TELECOMUNICAZIONI Adding Tema IP SIP Terminals It is possible to add in configuration as many terminals you want. Into the main screen of course it is always presented one at a time. To switch from one system to the other just slide your finger horizontally on the application display.
Page 40 AD630VoIP SIP 25W / PoE Horn TEMA TELECOMUNICAZIONI In normal operation, it is displayed the image of the first Doorphone (as mentioned above to switch from one to another simply scroll the screen). The keys below the displayed image will have impact on the selected Doorphone: The first button activates the door relay (number 1).
Page 41: Appendixes
Multicast in the specific IP channel (up to 5 channels) and play it on your speaker. Audio can be generated by a PC software application (for example the free VLC application), from a SIP IP phone or from a TEMA intercom of AA-500 IP series.
Page 42 (Zones) configured so that each function button can send a multicast announcement on associated group. It is also possible to use the Tema AA-500 Intercom to generate calls on Multicast channels by appropriately programming the system keys: holding a key the microphone audio is sent to the programmed Multicast IP address.
Page 43: Appendix 2: Use Of The Vlc Media Player Software As A Multicast Encoder For Audio Files
AD630VoIP SIP 25W / PoE Horn TEMA TELECOMUNICAZIONI 14.2. Appendix 2: Use of the VLC Media Player software as a Multicast Encoder for audio files With the free VLC sofware downloadable from http://www.videolan.org/vlc/index.it.html it is possible to turn your Windows PC into an Encoder generator on a multicast IP address that can play a recorded audio file In WAV format 8KHz-16 Bit mono.
Page 44: Appendix 3: Use Of The Audacity Software For Audio Files Recording
DTMF tones or tones, noise reduction, etc. For optimal use please refer to the product manual. NOTE: TEMA provides you with its own internal recording studio for the creation of professional prompts with multilingual speakers from texts on customer specifications.
Page 45: Appendix 4: Cabling Of Autp Rj45 Network Cable According To The Standard Eia568B
AD630VoIP SIP 25W / PoE Horn TEMA TELECOMUNICAZIONI 14.4. Appendix 4: Cabling of a UTP RJ45 network cable according to the standard EIA568B Signal Connector 1 Connector 2 White/Orange White/Orange Orange Orange White/Green Bianco/Green PoE- Blue Blue PoE- White/Blue White/Blue...
Page 46 AD630VoIP SIP 25W / PoE Horn TEMA TELECOMUNICAZIONI Notes MAS-AD630-REV01EN Page 46 of 46...
