Mystery MY8A Manual

High power systems for RC model can be very dangerous and we strongly suggest that you read this manual carefully. ZTW
Model have no control over the use, installation, application, or maintenance of these products, thus no liability shall be
assumed nor accepted for any damages, losses of costs resulting from the use of this item. Any claims arising from the
operating, failure or malfunctioning etc. will be denied. We assume no liability for personal injury, property damage or
consequential damages resulting from our product or our workmanship. As far as is legally permitted, the obligation for
compensation is limited to the invoice amount of the product in question.
The Mystery ESC's high power BEC has been specifically designed for extreme aerobatics and therefore has the capability to
support the higher momentary peak demand loads to eliminate the possibility of unwanted shutdowns, and is also capable of
supporting continuous simultaneous multiple servo operations typically found in CCPM equipped hardcore 3D E-helicopters.

Wires Connection:

The speed controller can be connected to the motor by soldering directly or with high quality connectors. Always use new
connectors, which should be soldered carefully to the cables and insulated with heat shrink tube. The maximum length of the
battery pack wires shall be within 6 inches.
 Solder controller to the motor wires.
 Solder appropriate connectors to the battery wires.
 Insulate all solder connectors with heat shrink tubes.
Plug the "JR" connector into the receiver throttle channel.

 Controller Red and Black wires connects to battery pack Red and Black wires respectively.

Specification:

Type
MY8A
MY12A
MY20A
MY30A
MY40A BEC
MY40A SBEC
MY50A BEC
MY50A SBEC
MY50A OPTO
MY60A SBEC
MY70A SBEC
MY85A BEC
MY85A SBEC
MY85A OPTO
MY110A OPTO LV
MY100A OPTO HV
Thank you for purchasing
Cont. Burst
Current (A)
Current(A)
10 sec.
8A 10A
12A 16A
20A 30A
30A 40A
40A 60A
40A 60A
50A 70A
50A 70A
50A 70A
60A 80A
70A 90A
85A 100A
85A 100A
85A 100A
110A 120A
100A 120A
Mystery Brushless Electronic Speed Controller(ESC).
Battery cell Weight
NiXX/Lipo (g)
5-12 NC \ 2-4 Lipo 10
5-12 NC \ 2-4 Lipo 10
5-12 NC \ 2-4 Lipo 20
5-12 NC \ 2-4 Lipo 25
5-12 NC \ 2-4 Lipo 25
5-18NC \ 2-6 Lipo 30
5-12NC \ 2-4 Lipo 30
5-18NC \ 2-6 Lipo 30
5-18 NC \ 2-6 Lipo 30
5-18NC \ 2-6 Lipo 35
5-18NC \ 2-6 Lipo 35
5-12 NC \ 2-4 Lipo 47
5-18NC \ 2-6 Lipo 47
5-18 NC \ 2-6 Lipo 47
5-18 NC \ 2-6 Lipo 75
16-32NC\5-10Lipo 75
1
BEC Size (mm)
Output W*L*H
5V / 1A 21 x 22 x 4
5V / 1A 21 x 22 x 4
5V / 2A 23 x 33 x 6
5V / 2A 23 x 43 x 6
5V/ 3A 23 x 43 x 6
5.5V / 4A 23 x 52x 7
5V / 3A 23 x 52x 6
5.5V / 4A 23 x 52x 7
23 x 52x 6
5.5V / 4A 23 x 52x 14
5.5V/4A 23 x 52x 14
5V /3A 34 x 52x 14
5.5V /4A 34 x 52x 14
34 x 52x 14
34 x52 x 20
34 x52 x 20
User
Program
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
