Page 3
Validity These instructions for use are valid for the following device: Device Order no. LDLF30x120-B470/UDC 1-13-866 Product Identification Designation Description LDLF LED bar light, diffuse illumination 30x120 Dimensions light-emitting surface: 30 mm x 120 mm B470 Wavelength: Blue - 470 nm...
LDLF30x120-B470/UDC Table of Contents TABLE OF CONTENTS 1 Information about the Instructions of Use..........7 1.1 Intended Use....................7 1.2 Improper Use....................8 1.3 Qualified Personnel..................8 1.4 Warranty and Liability...................9 2 Safety......................10 2.1 Presentation of Safety Instructions.............10 2.2 Safe Handling of the Device..............11 3 Scope of Delivery and Accessories............
LDLF30x120-B470/UDC Information about the Instructions of Use 1 INFORMATION ABOUT THE INSTRUCTIONS OF This document contains technical information, important instructions for correct installation, commissioning and use, as well as product information which were up-to-date at the time of going to press.
LDLF30x120-B470/UDC Information about the Instructions of Use 1.2 Improper Use All unintended use and all device-related activities not described in these instructions of use is to be deemed as unauthorised misuse outside the legal limits of indemnity of the manufacturer.
LDLF30x120-B470/UDC Information about the Instructions of Use 1.4 Warranty and Liability The contents of this document have been checked carefully and correspond to current legislation and best practise at the time of going to press. However, the manufacturer shall not be liable for any damage arising from the use of this edition of the manual, and rejects any warranty derived therefrom.
LDLF30x120-B470/UDC Safety 2 SAFETY 2.1 Presentation of Safety Instructions Each safety instruction is introduced by a key word and colour highlighted. The key word indicates the degree of danger. The danger and its cause are described, and then the measures to prevent conceivable consequences of the danger.
LDLF30x120-B470/UDC Safety 2.2 Safe Handling of the Device Read the following applicable safety instructions carefully and completely. Follow the instructions for your own safety, the safety of other people, and to avoid damage to the device and the connected technical equipment. Hazards going beyond the general safety instructions are referred to separately at the relevant points in this manual.
Scope of Delivery and Accessories 3 SCOPE OF DELIVERY AND ACCESSORIES 3.1 Scope of Delivery Designation Quantity Device LDLF30x120-B470/UDC Instructions for Use LDLF30x120-B470/UDC 3.2 Accessories Connection cable M8, 4-pin, open cable end Designation Description Order no. Cable with M8 socket,...
Page 13
LDLF30x120-B470/UDC Scope of Delivery and Accessories vicolux smart light Beleuchtungscontroller Designation Description Order no. DLC-3005 Digital lighting controller, rail mounting, 1-30-202 continuous operation 4.8 A, flash operation 9.3 A DLC-3005-R Digital lighting controller, rail mounting, 1-30-209 continuous operation 4.8 A, flash operation 9.3 A...
LDLF30x120-B470/UDC Device Description 4 DEVICE DESCRIPTION 4.1 Device Views Image 1: Device view Light-emitting surface 3 x M3 mounting hole, depth 10.5 mm (on both sides) 4 x M3 mounting hole, depth 4.5 mm (on both sides) Casing Connection cable with 4-pin M8 connector 999.995.430.10-en-2.2...
LDLF30x120-B470/UDC Technical Data 5 TECHNICAL DATA 5.1 General Parameters Parameter Characteristic Housing material Aluminium, black anodised Optical material PMMA Housing dimensions 35 mm x 142 mm x 22 mm (without connector) Dimensions light-emitting surface 30 mm x 120 mm Weight...
Page 17
LDLF30x120-B470/UDC Technical Data Connecting cable Parameter Characteristic Length 150 mm Cable diameter 5.0 mm Core cross-section 4 x 0.5 mm² Material cable coating Drag chain suitable Bending radius cable fixed at least 5 x cable diameter Bending radius cable moved...
LDLF30x120-B470/UDC Technical Data 5.2 Electrical Parameters NOTICE Verify that temperature, current and pulse time are kept inside specified limits! Please refer to the diagram: "Pulse load ". There is no automatic limitation of the electrical parameters. The temperature of the device is not monitored automatically.
Page 19
LDLF30x120-B470/UDC Technical Data Pulse load 0.05 0.02 12.0 10.0 1.0 E-4 1.0 E-3 1.0 E-2 1.0 E-1 1.0 E+0 1.0 E+1 1.0 E+2 Duty Cycle Power-on time Power-off time Image 3: Pulse load ADVICE To take advantages of the vicolux smart-light technology, enter the following Light-Code in the user interface of your smart-light-controller (available from firmware-version 1.3 or higher):...
LDLF30x120-B470/UDC Technical Data 5.4 Conditions for Operation, Storage and Transport Store and transport the device in shock-proof box, if possible in the original packaging. For accessories, connected devices and components observe the specific information in the associated instructions for use.
LDLF30x120-B470/UDC Commissioning 6 COMMISSIONING 6.1 Unpacking 1. Lift the cardboard, together with the device, out of the carton. 2. Fold out the tucked in sides on the bottom of the cardboard. Loosening the film and forming an insertion pocket. 3. Remove the device out of the insertion pocket.
LDLF30x120-B470/UDC Commissioning 6.2 Mounting the Device NOTICE Installation and connection operations may only be performed in the off and de-energised state. To mount the device, tapped holes are located at the sides. 8 x M3 tapped hole at the bottom Maximum screw-in depth: 5.5 mm...
LDLF30x120-B470/UDC Commissioning 6.3 Connecting NOTICE Installation and connection operations may only be performed in the off and de-energised state. NOTICE Cable damage • Comply with the specified minimum bending radius. • Cables must generally be mounted with a strain relief clamp.
LDLF30x120-B470/UDC Commissioning 6.3.2 Pin assignment Use the M8 connector to connect the device according to the pin assignment. Pin assignment Connection diagram +ILED Image 6: M8 male plug, 4-pin -ILED Core colour Signal Description BN (brown) +ILED LED anode, positive current input...
LDLF30x120-B470/UDC Commissioning 6.4 Configuration Configuration with vicolux smart light lighting controllers When using a vicolux smart light lighting controller, the light is configured via the user interface DLC Server Control Center. Refer to the Instructions of Use DLC Server Control Center for more information.
LDLF30x120-B470/UDC Operation 7 OPERATION CAUTION Physiological effects by flashing lights • Working under flashing lights can cause effects such as headache, nausea, or epileptic seizures. • Avoid exposure to certain kinds of flashing lights or stroboscopes. • Wear protective goggles.
LDLF30x120-B470/UDC Operation 7.1 Making Operational Readiness NOTICE This device is intended for use with suitable controllers only. All technical data and permissible conditions must be complied with. The lighting is switched on by turning on the LED current I The lighting is switched off by turning off the LED current I 7.2 Operation with vicolux smart light lighting controller...
LDLF30x120-B470/UDC Operation 7.3 Operating Modes Continuous operation For continuous operation, apply a constant current I to the lighting. Flash operation For pulse or flash operation, apply current pulses I to the lighting. Observe the specified parameters. see "Electrical Parameters", page 18 999.995.430.10-en-2.2...
LDLF30x120-B470/UDC Maintenance and Service 8 MAINTENANCE AND SERVICE 8.1 Maintenance The device is maintenance-free. Depending on the operating environment, it may have to be cleaned. The housing can be cleaned according to the conditions applicable to the given protection class.
LDLF30x120-B470/UDC Maintenance and Service 8.2 Service Technical Support Please contact our technical support if you have any technical questions concerning our products. We will be glad to be of service: Monday to Thursday 8:00 to 17:00, and Friday 8:00 to 15:00.
LDLF30x120-B470/UDC Disposal 9 DISPOSAL The device and its accessories and packaging must be sent to environmentally compatible recycling. Do not throw electrical devices or tools into the household waste! According to European Directive 2012/19/EU on waste electrical and electronic equipment and its implementation in national law, unusable electric tools must be collected separately, and sent to environmentally compatible recycling.
D-98527 Suhl, Germany Representative: Dr. Jürgen Geffe, Managing director We, Vision & Control GmbH Suhl, declare that the product described below – Designation: LDLF30x120-B470/UDC – Order no.: 1-13-866 has been manufactured in accordance with the following standards and normative documents: •...
