GL Technologies GL-MT300N-V2 User Manual

GL-MT300N-V2 User manual
Introduction
Congratulations on receiving your GL-MT300N-V2. As part of our Green Initiative, we do not include printed
user documentation with our product packaging. This policy saves paper, lowers shipping costs, reduces carbon
emissions and results in a cleaner environment.
Documentation
All product and accessory documentation can be found at the GLI Support Centre: http://www.gl-inet.com/docsOn
this site you will gain access to GLI technical resources and information about GLI products. To use your new GLI
Mini Router you will need to follow the simple steps which you can see from
http://www.gl-inet.com/docs/wiki/#!mini/index.md
Default System Settings
Product
GL-MT300N-V2
Initial Set-up
Interfaces described as followed:
Power to the GLI Mini Router is provided by connect the power lead (supplied) to the power adaptor (buy
separately) and then to the power interface on the GLI Mini Router.
Once power is provided to the GLI Mini Router the LED's will provide status on its operation based on the
following:
LED
LED 1 (Power)
LED 2 (Customized)
LED 3 (WiFi connection)
Button Definition
LAN Default IP Address
DHCP
Indicator
Green solid
Customized
Red
LAN Fall-back IP Address
192.168.8.1
Description
Power is applied
This is customized LED.
Indicates WiFi signal (solid) and
data transfer (flashing).
