Reliable R0029B Technical Installation Instructions

RASCOFLEX Technical & Installation Instruction
RASCOFLEX Flexible Sprinkler Hose – 700mm to 1800mm Nominal Assembly Lengths
Flexible Sprinkler Hose System and Fittings
GENERAL DESCRIPTION
RASCOFLEX Flexible Sprinkler Hose and Fittings is an easy-to-install sprinkler drop assembly comprising of a branch-line
adapter nipple, stainless steel flexible hose with female thread hex nut end connectors, sprinkler outlet reducer that is
connected to the sprinkler head and ceiling bracket assembly that securely holds the sprinkler drop system to the ceiling grid.
There are many features and benefits to using RASCOFLEX Flexible Drops, including easy installation (which ultimately
saves you time and labour costs); this innovative design doesn't require any pipe threading, measuring or cutting. When
following the installation instructions enclosed the design prevents any installation mistakes. RASCOFLEX is easier to test
with water than other systems, as you can test the system with water before the ceiling grid is installed:
• Reduces labour costs and installation time; the rate of RASCOFLEX installation is two to three times faster than
traditional fitting methods of installing sprinkler drops.
• Quick Installation; RASCOFLEX eliminates the need for measuring and cutting. In case of crowded spaces, the user
can maneuverer the flexible sprinkler hose around ducts and trays.
• No need for heavy/special equipment; RASCOFLEX flexible sprinkler hose comes ready to install. No cutting, welding
or threading, giving you a head start with no waste.
• Easy-to-Install; RASCOFLEX flexible sprinkler drops are a fully assembled system that connects the branch-line to the
sprinkler head.
• Corrosion-resistant materials by applying stainless steel 304 grade on flexible drops.
NOTICE
RASCOFLEX flexible sprinkler hoses described herein must be installed and maintained
in compliance with this document and with the applicable standards recognized by the
approval agencies such as, LPCB, FM, VdS and UL guidelines as well as industry standards for
installation such as NFPA 13, NFPA 13D, NFPA 13R. In addition to the standards of any other
authorities having jurisdiction. Failure to do so may hinder the performance of these devices.
Reliable Automatic Sprinkler Co., Inc.
Manufacturer & Global Distributor of Fire Protection Products
R0029B
Page 1 of 11
