MICROWAVE OVEN MW1266WC (SILVER) SERVICE Manual MICROWAVE OVEN CONTENTS 1. Precaution 2. Specifications 3. Operating Instructions 4. Disassembly and Reassembly 5. Alignment and Adjustments 6. Troubleshooting 7. Exploded Views and Parts List 8. PCB Diagrams 9. Schematic Diagrams... - Page 2 PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not operate or allow the oven to be (c) Before turning on microwave power operated with the door open. for any service test or inspection within (b) Make the following safety checks on the microwave generating all ovens to be serviced before activating...
-
Page 3: Precaution
1. Precaution Follow these special safety precautions. Although the microwave oven is completely safe during ordinary use, repair work can be extremely hazardous due to possible exposure to microwave radiation, as well as potentially lethal high voltages and currents. 1-1 Safety precautions ( 1. - Page 4 1-2 Special Servicing Precautions (Continued) 17. When checking the continuity of the witches or transformer, always make sure that the power is OFF, and one of the lead wires is disconnected. 18. Components that are critical for safety are indicated in the circuit diagram by shading, 19.
-
Page 5: Specifications
2. Specifications 2-1 Table of Specifications TIMER 99 MINUTES 99SECONDS POWER SOURCE 120V CA 60HZ POWER CONSUMPTION MICROWAVE : 1,550W OUTPUT POWER 1100W ( 10 LEVEL POWER ) OPERATING FREQUENCY 2,450MHz MAGNETRON OM75PH(31)ESS COOLING METHOD COOLING FAN MOTOR 19/32 45/64 OUTSIDE DIMENSIONS (W) x 11 (H) x 16... -
Page 6: Operating Instructions
3. Operating Instructions 3-1 Control Panel 3-2 Features & External Views Light Safety Interlock Holes Ventilation Holes Door Control Pane Door Latches CE1D33 Guide Roller Glass Tray Open Door Push Button 377mm 249mm 523mm 413mm - 4 -... -
Page 7: Disassembly And Reassembly
4. Disassembly and Reassembly 4-1 Replacement of Magnetron, Motor Assembly and Lamp Remove the magnetron including the shield case, permanent magnet, choke coils and capacitors (all of which are contained in one assembly). 1. Disconnect all lead wires from the magnetron and lamp. 2. - Page 8 4-3 Replacement of Door Assembly 4-3-1 Removal of Door "C" Insert flat screw driver into the gap between Door Door "A" "A" and Door "C" to remove Door "C". Be careful when handling Door "C" because it is fragile. Then remove the door assembly. Door "C"...
- Page 9 4-3-4 Reassembly Test After replacement of the defective component parts of the door, reassemble it and follow the instructions below for proper installation and adjustment so as to prevent an excessive microwave leakage. 1. When mounting the door to the oven, be sure to adjust the door parallel to the bottom line of the oven face plate by moving the upper hinge and lower hinge in the direction necessary for proper alignment.
- Page 10 4-6 Replacement of Control Circuit Board 4-6-1 Removal of Control Box 1. Be sure to ground any static electric charge in your body and never touch the control circuit. 2. Disconnect the connectors from the control circuit board. 3. Remove screws securing the control box assembly.
-
Page 11: Alignment And Adjustments
5. Alignment and Adjustments PRECAUTION 1. High voltage is present at the high voltage terminals during any cook cycle. 2. It is neither necessary nor advisable to attempt measurement of the high voltage. 3. Before touching any oven components or wiring, always unplug the oven from its power source and discharge the high voltage capacitor. - Page 12 5-4 High Voltage Capacitor 1. Check continuity of the capacitor with the meter set at the highest resistance scale. 2. Once the capacitor is charged, a normal capacitor shows continuity for a short time, and then indicates 9M Ω 3. A shorted capacitor will show continuous continuity. Ω...
- Page 13 5-8 Output Power of Magnetron CAUTION MICROWAVE RADIATION PERSONNEL SHOULD NOT ALLOW EXPOSURE TO MICROWAVE RADIATION FROM MICROWAVE GENERATOR OR OTHER PARTS CONDUCTING MICROWAVE ENERGY. The output power of the magnetron can be measured by performing a water temperature rise test. Equipment needed : * Two 1-liter cylindrical borosilicate glass vessel (Outside diameter 190 mm) * One glass thermometer with mercury column...
- Page 14 5-9 Procedure for Measurement of Microwave Energy Leakage 1) Pour 275±15cc of 20±5° C(68±9° F) water in a beaker which is graduated to 600cc, and place the beaker in the center of the oven. 2) Start to operate the oven and measure the leakage by using a microwave energy survey meter.
-
Page 15: Troubleshooting
6. Troubleshooting PRECAUTION 1. CHECK GROUNDING BEFORE CHECKING FOR TROUBLE. 2. BE CAREFUL OF THE HIGH VOLTAGE CIRCUIT. 3. DISCHARGE THE HIGH VOLTAGE CAPACITOR. 4. WHEN CHECKING THE CONTINUITY OF THE SWITCHES OR TRANSFORMER, DISCONNECT ONE LEAD WIRE FROM THESE PARTS AND THEN CHECK CONTINUITY WITHOUT THE POWER SOURCE ON. - Page 16 6-1 Electrical Malfunction(continued) SYMPTOM CAUSE CORRECTIONS Oven lamp and fan motor turn on 1. Misadjustment or loose wiring Adjust door and latch switches. of secondary latch switch 2. Defective Secondary latch switch Oven can program but timer 1. Open or loose wiring of Adjust door and interlock does not start.
-
Page 17: Exploded Views And Parts List
7. Exploded Views and Parts List 7-1 Exploded Views D006 D005 D015 D004 M001 D003 D002 M002 M015 M019 M018 M029 M031 M020 D007 W002 D011 D049 C082 M036 C005 M099 B018 M051 B001 C009 M035 M049 C003 B006 M056 M037 C001 B002... - Page 18 7-2 Main Parts List Code No. Description Specification Q'ty Remark B001 3405-001055 SWITCH-MICRO 125/250VAC,16A,200GF,SPST-N PRI-S/W B002 3405-001033 SWITCH-MICRO 125/250VAC,16A,200GF,SPST-N MONITOR B004 3405-001034 SWITCH-MICRO 125/250VAC,16A,200GF,SPST-N DOOR-S/W B006 DE72-00138A BODY-LATCH NC2000(0.6/0.8/1.2),PP,-,-,-, B009 DE66-00088A LEVER-SWITCH NC2000(0.6/0.8/1.2),PP,-,-, B018 DE96-00115D ASSY BODY LATCH MW1255WA,NC2000(BUTTON) M001 DE70-00185C PANEL-OUTER MW1255WA(1.2CUFT),SECC,T0.6,...
- Page 19 Code No. Description Specification Q'ty Remark C001 DE94-00096B ASSY CONTROL-PANEL 230V50HZ,M1933/CE2933 C003 RA-N2LED1-47 ASSY PCB PARTS MW1236WC/XAX,120V60HZ C004 DE34-00125H SWITCH MEMBRANE MW1266WC/XAX,SPANISH,WHT C005 DE72-70209B CONTROL-PANEL M1933,ABS(HR0370U),T2.0,-, C006 DE61-70076A SPRING-BUTTON -,HSWR,PI0.6,-,OD19,L23,5T C007 DE66-20281A BUTTON-PUSH 3RD-W B DESIGN,-,T2x37x86,-, C009 DE67-40175A WINDOW-DISPLAY 5G,SAN,-,-,-,-,SMG,-...
- Page 20 7-4 Standard Parts List Code No. Description Specification Q'ty Remark DE60-10012A SCREW-TAP TITE -,SWR10,M4,L10,TH,+,-,3,ZPC2,- DE60-10059A SCREW-TAP TH -,-,SUS410,CR,TH,M4,-,L8,-,- C/CEILING DE60-10080B SCREW-WASHER -,2S,SWRCH18A,ZP2,PH,PI5,-,L10,-,- DE60-10080B SCREW-WASHER -,2S,SWRCH18A,ZP2,PH,PI5,-,L10,-,- TNS-HV DE60-10082H SCREW-A -,-,-,-,2S-4X12,TOOTHED,-,-,-,- B-PLTE DE60-10082H SCREW-A -,-,-,-,2S-4X12,TOOTHED,-,-,-,- BD-LAT DE60-10082H SCREW-A -,-,-,-,2S-4X12,TOOTHED,-,-,-,- CN-BOX DE60-10082H SCREW-A -,-,-,-,2S-4X12,TOOTHED,-,-,-,- CV/AIR DE60-10082H...
- Page 21 8. P.C.B Diagrams 8-1 P.C.B Diagrams - 1 9 -...
- Page 22 8-2 P.C.B Parts List Code No. Description Specification Q'ty Remark 3501-001155 RELAY-MINIATURE 24VDC,200MW,3000MA,1FORMA,10MS,10MS RY01,03 3501-001188 RELAY-POWER 24V DC,0.53W,-,1FormA,9.3ms,10mS RY02 3708-001510 CONNECTOR-FPC/FC/PIC 14P,1.25mm,STRAIGHT,SN CN04 DE07-00021K LED DISPLAY CSQ-4246G-10,NC2000-CMO,-,40SEG,5DIGIT,- LED1 DE09-00214A IC MICOM TMP87CH47U-3DC0,SM-200102-CN,-,-,-,MW850W,-,- IC01 DE26-00037A TRANS-L.V SLV-4290U,120V,60Hz,AC17V/7V,-,35*10,PIN,- LVT1 DE30-20016A BUZZER CBE2220BA,STICK,-,-,-,-,-,-,- BUZ1 DE92-00784A ASSY PCB AUTO...
-
Page 23: Schematic Diagrams
9. Schematic Diagrams 9-1 Schematic Diagrams NOTE: CIRCUIT SHOWN WITH DOOR IS OPENED POSITION. WARNING NOTE: FOR SERVICE REPLACEMENT USE 16 GA 105° C POWER MUST BE DISCONNECTED THERMOPLASTIC COVERED WIRE EXCEPT BEFORE SERVICING THIS APPLIANCE FOR HIGH VOLTAGE LEADS OR AS NOTED ON SPECIAL LEADS. MAGNETRON HIGH VOLTAGE DIODE... - Page 24 ELECTRONICS © Samsung Electronics Co., Ltd. May 2003 Printed in Korea Code No. : DE68-03137A...
