Sven STANDARD PRO 3G-5 User Manual

STANDARD
PRO 3G
Power Strip
USER'S MANUAL
Congratulations on the purchase of TM SVEN power strip !
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may
occur. The information in this Manual is given on "as is" terms. The author and the publisher
do not bear any liability to a person or an organization for loss or damage, which has
arisen from the information contained in this Manual.

PURPOSE

SVEN STANDARD PRO 3G power strip is designed for connection of electrical
appliances computer equipment to the electric mains.

FEATURES

• Double-pole switch with light indication of the turn on condition
• Easy-to-use and safe connection
• Case made of high-impact non-flammable plastic material
• Four CEE 7/4 sockets with grounding
• Conductor material – pure copper 3 × 0.75 mm

SAFETY PRECAUTIONS

• Do not connect the power strip to power mains with overrating voltage.
• Do not connect simultaneously the load to the power strip with total power more than
2200 W.
• Do not use in places with possible ingress of liquid, moisture, dust and high tempe-
rature exposure.
• Do not open and do not make any repairs by yourself.
• It is recommended to connect the power strip to the grounded power mains.

TECHNICAL SPECIFICATIONS

Rated voltage, V
Operating frequency, Hz
Total connected load power, kW
Maximum current, А
Input plug
Output sockets
Cable length, m
Dimensions (W × H × D), mm
Note. Technical specifications given in this table are supplemental information
and cannot give occasion to claims. ТМ SVEN production is improved constantly,
therefore Technical Specifications are subject to change without prior notice.
2
220
50
≤ 2.2
10
CEE 7/7
4 × CEE 7/4
2; 3; 5
35 × 45 × 232
Warranty Period: 12 months
Service Life: 2 years
