Bebob ML-120EPIC User Manual

Hot swap adapter
Hide thumbs
1
2
3

Advertisement

Table of Contents

Features

·
Automatic switching by empty batteries to allow continuous powering of the RED Epic for
120s
·
2 Step empty battery-alarm
·
20Wh built-in power-buffer
·
12V (unreg.) D-Tap Port with self-resetting 5A Fuse
·
Zero maintenance required
·
works only with V-Mount Lithium-Ion Battery ( nominal voltage between 14.4V and
14.8V)
·
Mounts only on the RED Epic

Charging

·
The ML-120EPIC charges itself from the V-Mount battery
·
At first charge or If completely empty, the ML-120EPIC will be ready to use after 60
minutes
·
While Charging the yellow "Charging" LED turns on
·
When fully charged the green „Ready" LED turns on
·
The ML-120EPIC charges itself automatically when needed.
·
During charging The ML-120EPIC keep monitoring the voltage of the battery and is ready
to switch if needed
bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: +49 89 27818282
ML-120EPIC Hot Swap Adapter
User Manual
WE STRONGLY RECOMMEND THAT YOU
READ THIS INSTRUCTION BEFORE USING
YOUR BEBOB ML-120EPIC HOT SWAP
ADAPTER! PLEASE KEEP THIS MANUAL
FOR FUTURE REFERENCE
www.bebob.de
April 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ML-120EPIC and is the answer not in the manual?

Questions and answers

Related Manuals for Bebob ML-120EPIC

Summary of Contents for Bebob ML-120EPIC

  • Page 1 Mounts only on the RED Epic Charging · The ML-120EPIC charges itself from the V-Mount battery · At first charge or If completely empty, the ML-120EPIC will be ready to use after 60 minutes · While Charging the yellow "Charging" LED turns on ·...
  • Page 2 14,5V), powering of the RED Epic instantly reverts to the V-Mount battery. · The ML-120EPIC switches up to 6 Times before running empty · If the empty battery is not replaced within 2 minutes the ML-120EPIC and the RED Epic will switch off. Alarm LED´s brightness ·...
  • Page 3 1(max 5.0A) Self-reset Fuse Charging Mode Automatic Charging Time Max 60 Minutes Display Charge/ready Dimensions (WXHXD) 140 x 76 x 45mm Weight 0,52 Kg bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: +49 89 27818282 www.bebob.de April 2016...
