Deliberant DLB2300 User Manual

Wlan outdoor bridge

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Wireless LAN Device Series

WLAN Outdoor Bridge

DLB2300/DLB2310/DLB2319

User Manual

Version. 1.0.0 (06.01.2006)

Table of Contents

Need help?

Do you have a question about the DLB2300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Deliberant DLB2300

Page 1 Wireless LAN Device Series WLAN Outdoor Bridge DLB2300/DLB2310/DLB2319 User Manual Version. 1.0.0 (06.01.2006)
Page 2: Table Of Contents
TABLE OF CONTENTS PREFACE............................3 FCC Information........................3 Installation Requirements ......................4 CH 1. DEVICE INSTALLATION....................5 ..........................5 ACKING CH 2. FIRST TIME CONFIGURATION ..................5 ......................5 EFORE TART TO ONFIGURE ...................6 NOWING THE ETWORK PPLICATION ........................29 DVANCED ETTINGS ....................32 ONFIGURING IRELESS ECURITY WLAN C ...................
Page 3 VPN P ........................62 THROUGH CLI M ......................... 62 SING ......................64 YSTEM ANAGEMENT SNMP A ..........................65 GENT ........................67 IRMWARE PGRADE & R .................. 68 ONFIGURATION ACKUP ESTORE ....................... 69 ISCOVERY...
Page 4: Preface
Preface FCC Information Electronic Emission Notices This device complies with CFR 47 Part 15 of the FCC rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation.
Page 5: Installation Requirements
Installation Requirements This guide is for the networking professional who installs and manages the Deliberant DLB-2300/DLB2310/DLB2319 outdoor product hereafter referred to as the “device”. To use this guide, you should have experience working with the TCP/IP configuration and be familiar with the concepts and terminology of wireless local area networks.
Page 6: 1. Device Installation
Ch 1. Device Installation Packing List Before you start to install the ODU, make sure the package contains the following items Wireless Outdoor Bridge unit * 1 ● Mounting Kit * 1 ● Power Over Ethernet Kit * 1 ● Ch 2.
Page 7: Knowing The Network Application
PC is not in the same subnet as the device is. Knowing the Network Application DLB2300/DLB2310/DLB2319 can act as the following roles, and it supports WDS (Wireless Distribution System) function. Access Point WDS (Wireless Repeater) Bridge/Router WISP AP Client The device provides 3 different operation modes and the wireless radio of device can act as AP/Client/WDS.
Page 8 AP Client This mode provides the capability to connect with the other AP using infrastructure/Ad-hoc networking types. With bridge operation mode, you can directly connect the wired Ethernet port to your PC and the device becomes a wireless adapter. And with WISP operation mode, you can connect the wired Ethernet port to a hub/switch and all the PCs connecting with hub/switch can share the same public IP address from your ISP.
Page 9 Internet Broadband Modem Router Mode With WDS + AP Bridge Mode Bridge Mode WISP Mode With With WDS + AP Bridge Mode...
Page 10 Examples of Configuration This example demonstrates how to set up a network with different device configurations. There are 2 DHCP servers (DEV1/DEV4) in the network to control the IP configuration of 2 domains (192.168.2.x/192.168.3.x). Once the setting is done, all the PCs can visit Internet through DEV1. We assume all the devices keep the factory default setting.
Page 11 Press “Next>>” button then set the “Operation Mode” to “Router” mode. Press “Next>>” button then disable “Time Zone” function. Press “Next>>” button then set the IP address of LAN interface. Press “Next>>” button then select the “PPPoE” for “WAN Access Type” and fill in the “User Name”...
Page 12 Press “Next>>” button then select the “AP+WDS” for “mode” and change the SSID to “DEV1”. Press “Next>>” button then select “None” for “Encryption” then press “Finished” button. 10. Wait for refreshing web page. 11. Use “WDS Settings” page to configure WDS.
Page 13 12. Enable WDS function and add the BSSID of DEV2 to “Current WDS AP List”. 13. Since we access the device by wireless connection, it may temporarily disconnect when applying the WDS setting. After re-connecting to the device, use the “Status” page to check the settings.
Page 14 Configure DEV2: Access the web server (http://192.168.2.254) of device from the Ethernet port. Caution If you configure multiple devices in the same PC, since the devices have the same default IP address but different MAC addresses, it may cause you not able to access the web server of device. If the situation happens, please try to clean the ARP table of your PC by DOS command “arp –d”...
Page 15 Press “Next>>” button then set the IP address of LAN interface. Press “Next>>” button then select the “AP+WDS” for “mode” and change the SSID to “DEV2”. Press “Next>>” button then select “None” for “Encryption” then press “Finished” button. Wait for refreshing web page.
Page 16 Access the web server by new IP address “192.168.2.202” then use “LAN Interface” page to disable DHCP Server. 10. Wait for refreshing web page. 11. Use “WDS Settings” page to configure WDS.
Page 17 12. Enable WDS function and add the BSSID of DEV1 to “Current WDS AP List”. 13. Use the “Status” page to check the settings.
Page 18 Configure DEV3: Access the web server (http://192.168.2.254) of device from the Ethernet port. Caution If you configure multiple devices in the same PC, since the devices have the same default IP address but different MAC addresses, it may cause you not able to access the web server of device.
Page 19 Access the web server by new IP address “192.168.2.203” then use “Basic Settings” page to change SSID and CHANNEL. Use the “Status” page to check the settings.
Page 20 Configure DEV4: Access the web server (http://192.168.2.254) of device from the Ethernet port. Caution If you configure multiple devices in the same PC, since the devices have the same default IP address but different MAC addresses, it may cause you unable to access the web server of device.
Page 21 Press “Next>>” button then select the “DHCP Client” for “WAN Access Type”. Press “Next>>” button then select the “Client” for “mode” and change the SSID to “DEV4”. Press “Next>>” button then select “None” for “Encryption” then press “Finished” button. Wait for refreshing web page.
Page 22 10. Change the IP address of your PC to 192.168.3.x then access the web server by the new IP address “192.168.3.1” and use “Status” page check the setting. 11. If the “State” of “Wireless Configuration” is not “Connected” or you want to refresh the “RSSI “, please use “Site Survey”...
Page 23 Configure DEV5: Access the web server (http://192.168.2.254) of device from the Ethernet port. Caution If you configure multiple devices in the same PC, since the devices have the same default IP address but different MAC addresses, it may cause you unable to access the web server of device.
Page 24 Press “Next>>” button then select the “Client” for “mode” and change the SSID to “DEV5”. Press “Next>>” button then select “None” for “Encryption” then press “Finished” button. Wait for refreshing web page. Access the web server by the new IP address “192.168.2.205” and use “LAN Interface”...
Page 25 10. Wait for refreshing webpage. 11. Use “State” page to check setting. 12. If the “State” of “Wireless Configuration” is not “Connected” or you want to...
Page 26 refresh the “RSSI “, please use “Site Survey” page to re-connect a AP.
Page 27 Basic Settings Disable Wireless LAN Interface Disable the wireless interface of device Band: The device supports 2.4GHz(B), 2.4GHz(G) and 2.4GHz(B+G) mixed modes. Mode: The radio of device supports different modes as following: 1. AP The radio of device acts as an Access Point to serves all wireless clients to join a wireless local network.
Page 28 Infrastructure: This type requires the presence of 802.11b/g Access Point. All communication is done via the Access Point. Ethernet AP Client #1 AP Client #2 Ad Hoc: This type provides a peer-to-peer communication between wireless stations. All the communication is done from Client to Client without any Access Point involved.
Page 29 2412 Americas, EMEA, Japan, and China 2417 Americas, EMEA, Japan, and China 2422 Americas, EMEA, Japan, Israel, and China 2427 Americas, EMEA, Japan, Israel, and China 2432 Americas, EMEA, Japan, Israel, and China 2437 Americas, EMEA, Japan, Israel, and China 2442 Americas, EMEA, Japan, Israel, and China 2447...
Page 30: Advanced Settings
Advanced Settings These settings are only for more technically advanced users who have sufficient knowledge about wireless LAN. These settings should not be changed unless you know what effect the changes will have on your device. The default setting is optimized for the normal operation.
Page 31 can be useful in areas where many client devices are associating with the device, or in areas where the clients are far apart and can detect only the device and not each other. You can enter a setting ranging from 0 to 2347 bytes. Data Rate The standard IEEE 802.11b/11g supports 1, 2, 5.5, 11 / 6, 9, 12, 18, 24, 36, 48 and 54 Mbps data rates.
Page 32 Network, enable this function can provide better security. The device will block packets between wireless clients (relay). All the wireless clients connected to the device can’t see each other. Transmit Power The device supports four transmission output power levels 250, 200, 150 and 100mW for CCK (802.11b) mode and two transmission output power levels 100 and 50mW for OFDM (802.11g) mode.
Page 33: Configuring Wireless Security
Configuring Wireless Security This device provides complete wireless security function include WEP, 802.1x, WPA-TKIP, WPA2-AES and WPA2-Mixed in different mode (see the Security Support Table). The default security setting of the encryption function is disabled. Choose your preferred security setting depending on what security function you need. WEP Encryption Setting Wired Equivalent Privacy (WEP) is implemented in this device to prevent unauthorized access to your wireless network.
Page 34 When you decide to use the WEP encryption to secure your WLAN, please refer to the following setting of the WEP encryption: 64-bit WEP Encryption 64-bit WEP keys are as same as the encryption method of 40-bit WEP. You can input 10 hexadecimal digits (0~9, a~f or A~F) or 5 ACSII chars.
Page 35 WPA Encryption Setting WPA feature provides a high level of assurance for end-users and administrators that their data will remain private and access to their network restricted to authorized users. You can choose the WPA encryption and select the Authentication Mode. WPA Authentication Mode This device supports two WPA modes.
Page 36: Configuring As Wlan Client Adapter
Configuring as WLAN Client Adapter This device can be configured as a wireless Ethernet adapter. In this mode, the device can connect to the other wireless stations (Ad-Hoc network type) or Access Point (Infrastructure network type) and you don’t need to install any driver.
Page 37 The alternative way to configure as following: Step 1. In “Wireless Site Survey” page, select one of the SSIDs you want to connect and then press “Connect” button to establish the link. Step 2. If the linking is established successfully. It will show the message “Connect successfully”.
Page 38 Note If the available network requires authentication and data encryption, you need to setup the authentication and encryption before step1 and all the settings must be as same as the Access Point or Station. About the detail authentication and data encryption settings, please refer the security section. Authentication Type In client mode, the device also supports two Authentication Types “Open system”...
Page 39: Configuring Universal Repeater
Configuring Universal Repeater This device can be configured as a Repeater. In this mode, the device can extend available wireless range of other AP let user can link the network that they want, Also the device working as AP and Repeater same time. Following two ways describe how to make Universal Repeater effective.
Page 40 Changes button to take effective.
Page 41: 3. Configuring Wds
Ch 3. Configuring WDS Wireless Distribution System (WDS) uses wireless media to communicate with the other devices, like the Ethernet does. This function allows one or more remote LANs connect with the local LAN. To do this, you must set these devices in the same channel and set MAC address of other devices you want to communicate with in the WDS AP List and then enable the WDS.
Page 42 Star topology: Spanning Tree Device Entries of WDS AP List Protocol Required WDS1 The MAC Addresses of WDS2, WDS3, WDS4 and WDS5 WDS2 The MAC Address of WDS1 WDS3 The MAC Address of WDS1 WDS4 The MAC Address of WDS1 WDS5 The MAC Address of WDS1 Ring topology:...
Page 43: Wds Application
Mesh topology Device Entries of WDS AP List Spanning Tree Protocol Required WDS1 The MAC Addresses of WDS2, WDS3, WDS4 and WDS5 WDS2 The MAC Addresses of WDS1, WDS3, WDS4 and WDS5 WDS3 The MAC Addresses of WDS1, WDS2, WDS4 and WDS5 WDS4 The MAC Addresses of WDS1, WDS2, WDS3 and WDS5 WDS5...
Page 44 Ethernet Wireless station Repeater Spanning Tree Description Entries of WDS AP List Protocol Required Access Point The MAC Address of Repeater Repeater The MAC Address of Access Point Wireless Bridge Wireless Bridge can establish a wireless connection between two or more Wired LANs.
Page 45: 4. Advanced Configurations
Ch 4. Advanced Configurations Configuring LAN to WAN Firewall Filtering function is used to block packets from LAN to WAN. The device supports three kinds of filter Port Filtering, IP Filtering and MAC Filtering. All the entries in current filter table are used to restrict certain types of packets from your local network to through the device.
Page 46: Mac Filtering
MAC Filtering When you enable the MAC Filtering function, you can specify the MAC Addresses in current filter table. Once the source MAC Address of outgoing packets match the MAC Addresses in the table, the firewall will block this packet from LAN to WAN. Configuring Port Forwarding (Virtual Server) This function allows you to automatically redirect common network services to...
Page 47: Configuring Dmz
SMTP (Simple Mail Transfer Protocol) DNS (Domain Name System) Finger HTTP (Hyper Text Transfer Protocol) POP3 (Post Protocol) NNTP (Network News Transport Protocol) SNMP (Simple Network Management Protocol) SNMP trap SIP (Session Initiation Protocol) 5060 PPTP (Point-to-Point Tunneling Protocol) 1723 Configuring DMZ A Demilitarized Zone is used to provide Internet services without sacrificing unauthorized access to its local private network.
Page 49: Static Ip
Static IP You can get the IP configuration data of Static-IP from your ISP. And you will need to fill the fields of IP address, subnet mask, gateway address, and one of the DNS addresses. The Internet Protocol (IP) address of WAN interface provided by your ISP IP Address: or MIS.
Page 50: Dhcp Client (Dynamic Ip)
DHCP Client (Dynamic IP) All IP configuration data besides DNS will obtain from the DHCP server when DHCP-Client WAN Access Type is selected. The IP addresses of DNS provided by your ISP. DNS1~3: (Domain Name Server) is used to map domain names to IP addresses.
Page 51: Pptp
The account provided by your ISP User Name: The password for your account. Password: “Continuous “ : connect to ISP permanently Connect Type: “Manual” : Manual connect/disconnect to ISP “On-Demand” : Automatically connect to ISP when user need to access the Internet. The number of inactivity minutes to disconnect from ISP.
Page 52: Configuring Clone Mac Address
The Internet Protocol (IP) address of WAN interface provided by IP Address: your ISP or MIS. The address will be your network identifier besides your local network. The number used to identify the IP subnet network, indicating Subnet Mask: whether the IP address can be recognized on the LAN or if it must be reached through a gateway.
Page 53 Clone MAC address for DHCP Client WAN access type Clone MAC address for Static IP WAN access type Clone MAC address for PPPoE WAN access type...
Page 54: Configuring Dhcp Server
Clone MAC address for PPTP WAN access type Physical LAN interface MAC address clone Configuring DHCP Server To use the DHCP server inside the device, please make sure there is no other DHCP server existed in the same network as the device. Enable the DHCP Server option and assign the client range of IP addresses as following page.
Page 55: Bandwidth Control
When the DHCP server is enabled and also the device router mode is enabled then the default gateway for all the DHCP client hosts will set to the IP address of device. Bandwidth Control This functionality can control Bandwidth of Up/Downstream 1.
Page 56 Label Description Upstream Data Rate Speed of transmit data that from Ethernet interface to Wireless interface. Upstream Latency Similar a waiting time the data queuing- time. Upstream Burst Packet Similar a buffer the data will into the buffer while the data is transmit or receive. Downstream Data Rate Speed of transmit data that from Wireless interface to Ethernet interface.
Page 57: Qos (Quality Of Service)
QoS (Quality of Service) QoS allows you to specify some rules, to ensure the quality of service in your network. Such as use Bandwidth Priority concept to allocate bandwidth. This function can be helpful in shaping and queuing traffic from LAN (WLAN) to WAN or LAN to WLAN, but not WLAN to WLAN.
Page 58 The following table describes the labels in this part. Label Description QoS Enabled Select this check box to enable quality of service. Bandwidth Borrowed Select this check box to allow a rule to borrow unused bandwidth. Bandwidth borrowing is decided by priority of the rules.
Page 59 The following table describes the labels in this part. Label Description IP Address Enter source/destination IP Address in dotted decimal notation. Netmask Once the source/destination IP Address is entered, the subnet mask address must be filled in this field. MAC Address Enter source/destination MAC Address.
Page 60 Reset Click this button to begin re-input the parameters. Current QoS setting table In this part, you can see how many rules have been specified. And you can see the detail about the rules and manage the rules. This table can input 50 rules at most. An example for usage User C VoIP...
Page 61: Static Route Setup
Static Route Setup User can set the routing information let the Router knows what routing is correct also it can not learn automatically through other means. For example, if user wants to link the Network 3 and Network 4 separately from Network 1 that Routing Table configuration as below: 1.
Page 62: Dynamic Route Setup
Dynamic Route Setup The Dynamic Route utilizes RIP1/2 to transmit and receive the route information with other Routers. 1. Enable Dynamic Route and then select RIP 1 RIP2 or Both to transmit/receive packets final click Apply Change button. 2. Click Show Route Table button to show Dynamic Route Table. 3.
Page 63: Vpn Pass-Through
VPN Pass-through This functionality let the device can Pass-through the VPN packets including PPTP/ L2TP/IPsec VPN Connection. 1. Check the VPN Pass-through in WAN Interface of TCP/IP Page that you want and then click Apply Changes button. Using CLI Menu Start a SSH(Secure Shell) client session to login the device The SSH server daemon inside device uses well-known TCP port 22.
Page 65: The System Management
The System Management Password Protection Both Web-Browser and SSH configuration interfaces have password protection. To disable the Web-Browser password protection just leave the “User Name” field to blank then click “Apply Changes” button. To change the password of user “root” for SSH session, please use the CLI menu item G.
Page 66: Snmp Agent
SNMP Agent This device is compatible with SNMP v1/v2c and provide standard MIB II. Currently only the “public” community string is available and the modified settings by SNMP SET request will be lost after rebooting the device. 1. Enable SNMP and then enter IP Address of SNMP Manager in Trap Receiver IP Address field and Community String in System Community String field.
Page 67 3. SNMP Traps Traps Description coldStart(0) The trap from device after reboot the device linkDown(2) The trap is sent when any of the links are down. See the following table. linkup(3) The trap is sent when any of the links are UP.
Page 68: Firmware Upgrade
1.3.6.1.4.1.99.3 - Channel 1.3.6.1.4.1.99.4 - Band 1.3.6.1.4.1.99.5 - RSSI 1.3.6.1.4.1.99.6 - Active_Clients 1.3.6.1.4.1.99.7 - Active_Clients_List 1.3.6.1.4.1.99.8 - Encryption Firmware Upgrade Firmware Types The firmware for this device is divided into 2 parts, one is web pages firmware the other is application firmware, and the naming usually are g120webpage.bin and g120linux.bin.
Page 69: Configuration Data Backup & Restore
for user, it will check the firmware checksum and signature, and the wrong firmware won’t be accepted. After upgrading, the device will reboot and please note that depends on the version of firmware, the upgrading may cause the device configuration to be restored to the factory default setting, and the original configuration data will be lost! To upgrade firmware, just assign the file name with full path then click “Upload”...
Page 70: Auto Discovery Tool
configuration data to local host or restore configuration data to the device. Auto Discovery Tool User can use this tool to find out how many devices in your local area network The name of tool is WirelessConf.exe it in the packing CD. 1.
Page 71 window. In this window, you could see client’s information, such as: 6. Connect to Web Server If you want connect to device’s web server, you could press this button, or double-click on the device. 7. Close You could press this button to leave this tool.
