Summary of Contents for Chauvet Satellite TV System
-
Page 1: User Manual
Snapshot Use on Dimmer Outdoor Use Sound Activated Master/Slave Auto-ranging Power Supply Replaceable Fuse User Serviceable Duty Cycle User Manual 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
ECHNICAL PECIFICATIONS CHAUVET®, 2009, All Rights Reserved Information and specifications in this User Manual are subject to change without notice. CHAUVET® assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual..10 PTIONS... -
Page 3: Before You Begin
Manual Conventions CHAUVET® manuals use the following conventions to differentiate certain types of information from the regular text. ONVENTION [10] <Menu>... -
Page 4: Safety Instructions
Safety Instructions Please read these instructions carefully. It includes important information about the installation, usage and maintenance of this product. Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Always make sure that you are connecting to the proper voltage, and that the line voltage you are connecting to is not higher than that stated on the decal or rear panel of the fixture. -
Page 5: Introduction
2. I NTRODUCTION Features Cordless battery pack works with all Satellite™-ready fixtures Built-in wireless DMX receiver works with D-Fi system 3-pin and 5-pin DMX connections LED indicators display battery life Easy-access door to connect and change battery Removable antenna Product Dimensions 2. -
Page 6: Product Overview
Product Overview Battery Door Screw Carrying Handle (removable) Fixture Mounting Location (13 mm) Safety Attachment Point Power On/Off Switch 12 VDC Charger In 4-pin Power Out to Light Mounting Brackets (removable) 2. Introduction LCD Control Panel Battery Life Meter DMX Out (5-pin) DMX In (5-pin) DMX Out (3-pin) DMX In (3-pin) -
Page 7: Setup
3. S ETUP Charging the battery The battery charger runs on 100~240 VAC, 50/60 Hz. On the supplied battery charger, the LED will light green to indicate that the battery is fully charged. The LED on the battery charger will light red to indicate that the battery is charging. Please see the following instructions for charging the battery. -
Page 8: Battery Replacement
Battery Replacement As with any battery, the battery in this product will not last forever. Eventually, it must be replaced. Please see the following instructions for this procedure. Disconnect the battery charger. Turn the power switch OFF. Remove the external battery door screw with a #2 screwdriver Remove the internal battery latch screw with a #2 screwdriver. -
Page 9: Mounting
Mounting Orientation The Satellite™ D-Fi may be mounted in an upright, safe position, provided there is adequate room for ventilation. Rigging Be sure that the structure can support the weight of the fixture. Please see the “Technical Specifications” section of this manual for a detailed weight listing. Mount the fixture securely. This may be done with a screw, nut and bolt, or a hanging clamp. -
Page 10: D-Fi™ Plus/Satellite™ D-Fi Configuration Options
D-Fi™ PLUS/Satellite™ D-Fi Configuration Options The Satellite™ D-Fi is fully compatible with the standalone D-Fi™ PLUS wireless DMX products. DMX connection for the Satellite™ D-Fi There are both 3-pin and 5-pin DMX connection on the product. However, only one input and one output must be used at any time. -
Page 11: Operating Instructions
4. O PERATING Using the control panel Press <MODE> to switch between transmit and receive mode; this will also enable the frequency assignment. Press <DOWN/UP> to scroll through the operating frequencies. Press <ENTER> to save the settings. Menu Option Description Receive mode: Sets the Satellite™... -
Page 12: Appendix
5. A PPENDIX DMX Primer There are 512 channels in a DMX connection. Channels may be assigned in any manner. A fixture capable of receiving DMX will require one or a number of sequential channels. The user must assign a starting address on the fixture that indicates the first channel reserved in the controller. There are many different types of DMX controllable fixtures and they all may vary in the total number of channels required. -
Page 13: Data Cabling
Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET® certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 14: Setting Up A Dmx Serial Data Link
Package must be clearly labeled with a Return Merchandize Authorization Number (RMA #). Products returned without the RMA # will be refused. Call CHAUVET® and request an RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 15: General Troubleshooting
Long cable / Low level signal Loss of signal Too many fixtures Interference from AC wires If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support. Contact Us W o r l d W i d e... -
Page 16: Technical Specifications
Technical Specifications WEIGHT & DIMENSIONS Length ... 9.5 in (241 mm) Width... 8.5 in (216 mm) Height ... 5.5 in (140 mm) Weight... 10.1 lbs (4.6 kg) POWER Supplied battery charger ... 12 VDC 2,000 mA, 24 VA output (100~240 VAC, 50/60 Hz, 1.5 A input) COOLING ...
