Summary of Contents for Chauvet Marine Lighting

  • Page 1 User Manual...
  • Page 2: Table Of Contents

    CONTACT US ... 16 CHAUVET®, 2010, All Rights Reserved Information and specifications in this User Manual are subject to change without notice. CHAUVET® assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. Author: Anthony Chiappone...
  • Page 3: Before You Begin

    In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Manual Conventions CHAUVET® manuals use the following conventions to differentiate certain types of information from the regular text. ONVENTION [10] <Menu>...
  • Page 4: Safety Instructions

    Safety Instructions Please read these instructions carefully. It includes important information about the installation, usage and maintenance of this product. • Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •...
  • Page 5: Introduction

    2. I NTRODUCTION Product Overview Mounting Bracket DMX In DIP Switches Safety Power Out Bracket Adjustment Knob Bracket Adjustment Knob Power In DMX Out Fuseholder 2. Introduction 11/10/2010 3:19 PM...
  • Page 6: Setup

    Additional power link out The power linking shown in this document is for the Chauvet® North American version ONLY! Therefore, it is the customer’s responsibility to check with the Dealer/Distributor regarding power linking on the local version of the product. Connections and availability may change, depending on the power requirements and/or regulations of each country/region.
  • Page 7: Mounting

    Mounting Orientation The Abyss™ LED 2.0 may be mounted in any position, provided there is adequate room for ventilation. Rigging Be sure that the structure can support the weight of the fixture. Please see the “Technical Specifications” section of this manual for a detailed weight listing. Mount the fixture securely. This may be done with a screw, nut and bolt, or a hanging clamp.
  • Page 8: Operating Instructions

    4. O PERATING NSTRUCTIONS Configuring the Starting Address The Abyss™ LED 2.0 fixture uses two DMX channels. The highest channel that the fixture may be set to in order to function properly is 511. Any address higher than this will prevent access to all of the channels.
  • Page 9: Standalone

    Standalone This fixture has preprogrammed operating modes. These are accessed via the DIP switches on the back of the fixture. DIP switch [10] must be OFF in this mode. Please see the chart below for further explanation. Mode Water effect rotating, color rotating Water effect static, color rotating Water effect rotating, color static Water effect static, color static...
  • Page 10: Appendix

    Device does not power up Fixture is not responding to DMX Loss of signal If you still have a problem after trying the above solutions, please contact CHAUVET® Technical Support. 5. Appendix OSSIBLE AUSE • Check total load placed on the •...
  • Page 11: Dmx Primer

    Maximum recommended number of fixtures on a daisy chain: 32 Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET® certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference.
  • Page 12: Cable Connectors

    Cable Connectors Cabling must have a male XLR connector on one end and a female XLR connector on the other end. DMX connector configuration INPUT Terminator Do not allow contact between the common and the fixture’s chassis ground. Grounding the common can cause a ground loop, and your fixture may perform erratically. Test cables with an ohm meter to verify correct polarity and to make sure the pins are not grounded or shorted to the shield or each other.
  • Page 13: 3-Pin To 5-Pin Conversion Chart

    3-Pin to 5-Pin Conversion Chart If you use a controller with a 5-pin DMX output connector, you will need to use a 5-pin to 3-pin adapter. The chart below details a proper cable conversion: Conductor Ground/Shield Data ( - ) signal Data ( + ) signal Not used Not used...
  • Page 14: General Maintenance

    Package must be clearly labeled with a Return Merchandize Authorization Number (RMA #). Products returned without the RMA # will be refused. Call CHAUVET® and request an RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return.
  • Page 15: Technical Specifications

    ECHNICAL PECIFICATIONS WEIGHT & DIMENSIONS Length ... 9.6 in (243 mm) Width ... 10.2 in (260 mm) Height ... 7.4 in (188 mm) Weight ... 6 lbs (2.7 kg) POWER Auto-ranging power supply ... 100~240 VAC, 50/60 Hz Power consumption @ 120 V ... 16 W (0.2 A) max, 0.2 A inrush Power consumption @ 230 V ...
  • Page 16: Contact Us

    ONTACT W o r l d W i d e General Information CHAUVET® 5200 NW 108 Sunrise, FL 33351 voice: 954.929.1115 fax: 954.929.5560 toll free: 800.762.1084 Technical Support CHAUVET® 5200 NW 108 Sunrise, FL 33351 voice: 954.929.1115 (Press 4) fax: 954.929.5560 (Attention: Service)
