- Page 1 USE + INSTALLATION MANUAL Range Hoods FH3011 FH3611 FH3018 FH3618 FH4818 FH3624 FH4824...
- Page 2 Welcome to the Forza family! Congratulations on your recent Forza purchase! Before you begin using your new Forza product, please take a moment to review the Use + Installation Manual. You will find the answers to all of your questions as well as some very important safety...
-
Page 3: Table Of Contents
Table of Contents 04 Dimensions and Specifications 10 Preparation for Installation 12 Installation 15 Installation Under Wall Cabinet with Cabling 16 Wall-Mounted Horizontal Vent 20 Cleaning and Maintenance 22 Technical Specifications 24 Warranty... -
Page 4: Dimensions And Specifications
Dimensions and Specifications Model Number Voltage Frequency Power Weight FH3011 120 V 60 Hz 233 W 35 lb / 15.90 kg 12" 30" 24" Tools Required... - Page 5 Model Number Voltage Frequency Power Weight FH3611 120 V 60 Hz 353 W 41.8 lb / 19 kg 12" 36" 24" Tools Required...
- Page 6 Model Number Voltage Frequency Power Weight FH3018 120 V 60 Hz 353 W 43.6 lb / 19.80 kg 12" 30" 24" Tools Required...
- Page 7 Model Number Voltage Frequency Power Weight FH3618 120 V 60 Hz 353 W 52.8 lb / 24 kg 12" 24" 36" Tools Required...
- Page 8 Model Number Voltage Frequency Power Weight FH3624 120 V 60 Hz 706 W 68 lb / 30.95 kg *(Dual blower) 12" 24" 36" Tools Required...
- Page 9 Model Number Voltage Frequency Power Weight FH4818 120 V 60 Hz 706 W *(Dual blower) 12" 24" 48" Tools Required...
- Page 10 Model Number Voltage Frequency Power Weight FH4824 120 V 60 Hz 706 W *(Dual blower) 12" 24" 48" Tools Required...
- Page 11 FH3018 - FH3618 FH3624 FH3011 - FH3611 FH4818 - FH4824 Check the contents of the box before installing the product. If any items are missing or damaged contact the manufacturer. Remove the bag of component accessories from inside the body of the hood.
-
Page 12: Preparation For Installation
These parts must be removed even if they are not used during installation. The screws provided are required during the installation of the component. Remove the filters. Remove the accessories. FH3011 FH3611 FH3624 FH3018 - FH3618 FH4818 - FH4824... - Page 13 IMPORTANT: The minimum hood installation height requirements indicated in the cooktop / range instructions take precedence over the requirements outlined in this manual. If missing from the cooktop manual, refer to the measures shown in figure (1). Figure 1...
-
Page 14: Installation
Installation Horizontal Vent Option (PRE-CUT) FH3011 FH3611 - FH3018 - FH3618 (Positioning of motor for horizontal vent) FH3011... - Page 15 FH3611 - FH3018 - FH3618...
- Page 16 Closing...
-
Page 17: Installation Under Wall Cabinet With Cabling
Installation Under Wall Cabinet with Cabling Vent Option (PRE-CUT) FH3011 FH3611 - FH3018 - FH3618 Ø155 6" 7/64" FH3624 - FH4818 - FH4824 *(Only with reinforcing Wooden blocks) 5" 1"3/8 REAR Power Cable Channel 10"7/16 WALL CABINET INTERIOR SEEN FROM ABOVE... -
Page 18: Wall-Mounted Horizontal Vent
Wall-Mounted Horizontal Vent FH3011 FH3624 - FH4818 - FH4824 No. 4 SCREWS M4x10mm. - Page 19 FH3011 Wall Installation Measurements Installation Measurements - FH4818 -FH4824 501,5 FH3624 - FH4818- FH4824 19"3/4" FH3011 - FH3611- FH3018 - FH3618 15"29/32" FH3011 - FH3611- FH3018 - FH3618 15"29/32" FH3624 - FH4818- FH4824 29"59/64" Reinforcement for Bottom of Wall Cabinet (not included)
- Page 20 Installation Under Wall Cabinet - FH4818 - FH4824 Wooden Blocks...
- Page 21 Drywall Reinforcement FH3624- FH4818 - FH4824 Wall Installation...
-
Page 22: Cleaning And Maintenance
Cleaning and Maintenance Read and follow these instructions. This instruction booklet must be kept together with the appliance for future reference. If the appliance is sold or consigned to other parties, check that the booklet is supplied with it to ensure that the new user has the correct information on the operation of the range hood and is aware of the warnings. - Page 23 • Exhaust air must not be discharged into a flue which is used for exhausting fumes from appliances, burning gas or other fuels. • Ensure that all regulations concerning the discharge of exhaust air have been met before you use the appliance. Before performing any cleaning or maintenance operations, disconnect the appliance by unplugging it or using the main switch.
-
Page 24: Technical Specifications
Technical Specifications The technical specifications of the appliance are shown on the rating plates located inside the range hood. Electrical Connection Before carrying out any work inside the hood, disconnect the appliance from the mains. Check that the wires inside the hood are not disconnected or cut;... - Page 25 Electronic Control Of Buttons Hood light on/off (the button light is on when the hood light is on). Hood extractor on/off (the button light is on when the extractor is on). (- Symbol) Reduces extractor speed (the button light is on when the function is activated). (+ Symbol) Increases extractor speed (the button light is on when the function is activated).
- Page 26 Duration of warranty: For twenty-four (24) months from the original date of purchase, the Forza warranty covers all parts and labor to repair or replace, under normal residential use, any part of the product proving to be defective in material or workmanship as a result of the original manufacturing process.
- Page 27 20) Defects and damage arising from external forces beyond the control of Forza such as fire, flood, earthquakes and other acts of God. 21) Forza cannot guarantee the availability of service in areas more than 30 miles from an authorized retailer. In such cases where travel charges are levied, those will be borne by the consumer.
- Page 28 FULL NINETY DAY TOTAL PRODUCT WARRANTY For ninety days from the original date of purchase, the FORZA product warranty covers all parts and labor to repair or replace, under normal residential use, any part of the product proving to be defective in material or workmanship as a result of the original manufacturing process.
- Page 29 20) Defects and damage arising from external forces beyond the control of Forza such as fire, flood, earthquakes and other acts of God. 21) Forza cannot guarantee the availability of service in areas more than 30 miles from an authorized retailer. In such cases where travel charges are levied, those will be borne by the consumer.
- Page 32 Forza is a brand of Glem Gas S.P.A - Via Modenese 4266, 41018 San Cesario S.P. (Modena), Italy Web: www.forzacucina.com – Email: service@forzacucina.com...
