Summary of Contents for Klipsch KMC1SU
- Page 1 KMC1SU Installation and Operation Manual...
-
Page 2: Table Of Contents
KMC1SU CONTENTS Warnings and Compliance ..................1 Introduction ......................3 Safety Information ....................4 Wiring ........................5 Basic Operation ..................... 6 Tuner Operation ..................... 8 Weather Band Operation ..................10 USB MP3 Operation .................... 11 Bluetooth Operation ..................... 13 Specifications ....................... 15 Troubleshooting .................... -
Page 3: Warnings And Compliance
KMC1SU WARNINGS AND COMPLIANCE apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. Important Safety Instructions Read these instructions. WARNING! To reduce the risk of fire of electric shock, do not expose this Keep these instructions. - Page 4 KMC1SU FCC Notes WARNING! Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
-
Page 5: Introduction
KMC1SU INTRODUCTION System Features Features of the Klipsch KMC1SU marine audio system include: • Full Dot Matrix LCD • AM/FM US/EURO Tuner with 30 Presents (12 AM, 18 FM) • USB Playback of MP3 and WMA files • Bluetooth (Supports A2DP & AVRCP) •... -
Page 6: Safety Information
KMC1SU SAFETY INFORMATION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK AND INTERFERENCE, When Boating USE ONLY THE RECOMMENDED ACCESSORIES. Keep the volume level low enough to be aware of your surroundings. Protect from Water Do not submerge the product in water, as this can cause electric shorts, fire or other damage. -
Page 7: Wiring
KMC1SU WIRING TUNER/AMP MODULE COMMANDER... -
Page 8: Basic Operation
KMC1SU BASIC OPERATION Audio Menu Press the MENU button (8) on the control panel to access the audio menu. You can navigate through the audio menu items by rotation the Encoder Knob and pressing the Encoder Knob to make selection. Rotate the Encoder Knob clockwise to increase and counter-clockwise to decrease. - Page 9 KMC1SU flashing on the LCD display. System Menu Press and hold the MENU button (8) for more than 3 seconds to enter the NOTE: “OFF” is the default setting for Battery Alarm. If the audio is muted or system menu. “SYSTEM MENU” will appear on the display, followed by the the volume is set to 0, the audible beep will not be heard.
-
Page 10: Tuner Operation
KMC1SU TUNER OPERATION in the preset list for the selected Band. The new stations replace any stations already stored in that band. Press the PS soft button to scan stations stored in the current band list. The unit will pause for ten seconds at each preset station. Press PS again to stop scanning when the desired station is reached. - Page 11 KMC1SU Press the PTY soft button (6) access search for stations in your area broadcasting RBDS information. NOTE: Radio stations broadcasting RBDS may not be available in your listening area. In FM radio mode, press the PTY soft button to list the following Program Type...
-
Page 12: Weather Band Operation
KMC1SU WEATHER BAND OPERATION LIST Press the LIST soft button to display the preset list. What is the NOAA Weather Radio/ Weatheradio Canada? NOAA (National Oceanic and Atmospheric Administration) is a nationwide system Recall a Station that broadcasts local weather emergency information 24 hours a day via the Rotate the Encoder Knob (9) to navigate the preset list and highlight the desired National Weather Service (NWS) network. -
Page 13: Usb Mp3 Operation
KMC1SU USB MP3 OPERATION Removing a USB Device Press the MODE button (7) to select another mode and then remove the USB device from the USB connector. NOTE: After loading a USB device, files and folders are accessed in the order in which they were written to the device. - Page 14 KMC1SU Repeat Play Press the RPT soft button during song play to repeat the current file. Press the RPT soft button again to stop repeat play. Random Play Press the RND soft button to play all files in the current folder in random, shuffled...
-
Page 15: Bluetooth Operation
Before you begin, consult the owner’s manual for the Bluetooth device you want to pair with the KMC1SU. Make sure the device is on and ready to receive a signal from the KMC1SU. There are two methods to pair a device; through the user menu or press and hold the Encoder Knob while unit is in BT mode. - Page 16 When connected, a Bluetooth enabled device is able to stream audio to the KMC1SU. To access Bluetooth mode and play songs stored on your phone, press the MODE button (7). While in BT mode, the BT AUDIO icon illuminates on the LCD.
-
Page 17: Specifications
www.asaelectronics.com v.260417...
