- Page 1 MA300 MARINE AUDIO SYSTEM Installation and Operation Manual iPhone, iPod, iPod Classic, iPod Nano, iPod Shuffle, and iPod Touch are trademarks of Apple Inc., registered in the U.S. and other countries.
-
Page 2: Table Of Contents
MA300 CONTENTS Warnings and Compliance ......................1 Copyrights and Trademarks Introduction ..........................2 iPhone, iPod, iPod classic, iPod nano, iPod shuffle, and iPod touch are trademarks of Apple Inc., Installation ..........................3 registered in the U.S. and other countries. Wiring ............................4 “Made for iPod”... -
Page 3: Warnings And Compliance
MA300 WARNINGS AND COMPLIANCE Important Safety Instructions NOTE: Keep the volume level low enough to be aware of your surroundings. NOTE: USE THE PROPER POWER SUPPLY! This product is designed to operate with a 12 volt DC negative ground battery system. FCC Notes WARNING! Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. -
Page 4: Introduction
MA300 INTRODUCTION System Features Features of the Marine Audio MA300 include: White LED Backlit LCD iPx6 Waterproof Low Battery Alarm AM/FM US/EURO Tuner with 30 Presets (12 AM, 18 FM) Weatherband with Weather Alert ... -
Page 5: Installation
MA300 INSTALLATION achieved, turn the accessory switch off and proceed with final mounting of the chassis. Carefully slide the radio into the opening, making sure it is right-side-up. Before you Begin Secure the radio to the dashboard using #6 stainless steel pan head screws (not provided). -
Page 6: Wiring
MA300 WIRING WIRE COLOR DESCRIPTION BLUE AMP REMOTE (+12VDC 500MA) +12V SWITCHED GRAY FRONT RIGHT SPEAKER (+) WHITE FRONT LEFT SPEAKER (+) PURPLE REAR RIGHT SPEAKER (+) GREEN REAR LEFT SPEAKER (+) BLACK GROUND PURPLE/BLACK REAR RIGHT SPEAKER (-) WHITE/BLACK FRONT LEFT SPEAKER (-) GRAY/BLACK FRONT RIGHT SPEAKER (-) -
Page 7: Basic Operation
MA300 BASIC OPERATION should the unit display an error code. You can recover factory default settings using the RESET function located in the system menu. With “Reset to Defaults?” flashing, press the INFO/ENTER button (18) to activate. Audio Menu Press the AUDIO/MENU button (3) on the control panel to access the audio menu. You can navigate through the audio menu items by pressing the AUDIO/MENU button repeatedly. - Page 8 MA300 Bluetooth Pair (On/Off): Choose “INFO/ENTER” to automatically pair a device. Liquid Crystal Display (LCD) Bluetooth (On/Off): Choose “Bluetooth On” or “Bluetooth Off”. Volume Preset (1/40 – 40/40): Select an automatic turn-on volume. The current frequency and activated functions are shown on the LCD panel (20). ...
-
Page 9: Tuner Operation
MA300 TUNER OPERATION Automatically Store / Preset Scan (AS/PS Automatically Store Select an AM or FM band. Press and hold the AS/PS button (15) for more than two seconds to automatically select strong stations and store them in all bands. The new stations replace any stations already stored in that band. -
Page 10: Weather Band Operation
MA300 WEATHER BAND OPERATION alert is issued, the radio will turn on and play the announcement, then turn back off and revert to weather alert monitor mode. Accessing the Weather Band The radio will not respond to any weather alerts when it is off and will not automatically switch to Press the MODE button (4) to access the weather band mode. -
Page 11: Mp3/Usb Operation
MA300 MP3/USB OPERATION NOTE: After loading a USB device, files and folders are accessed in the order in which they were written to the device. Therefore, the playing order may not be the same as the order in which they are expected to be played. Controlling Playback Pause/Play Press the 1 || button (5) to suspend playback. -
Page 12: Ipod ® Operation
MA300 iPod OPERATION ® Turning the iPod On/Off The iPod power turns on automatically when an iPod is connected to the USB connector, as This unit is equipped with an iPod ready function that will allow you to control your iPod (if long as the vehicle ignition is turned on. -
Page 13: Bluetooth Operation
MA300 BLUETOOTH OPERATION Use ◄◄ / ►► The MA300 includes built-in Bluetooth technology that allows you to wirelessly connect to Navigate Bluetooth devices to this head unit for streaming audio playback. Press Press the List About Bluetooth Technology INFO/ENTER INFO/ENTER BT Device Device 1 Bluetooth is a short-range wireless radio technology. -
Page 14: App Operation
While in BT mode , the BT Audio icon ( ) illuminates on the LCD. primary functions of your MARINE AUDIO stereo right from your phone or tablet by transforming Selecting Tracks your mobile device into a functional stereo remote control! During playback, press the ◄◄... -
Page 15: Care And Maintenance
MA300 CARE AND MAINTENANCE TROUBLESHOOTING Keep the product dry. If it does get wet, wipe it dry immediately. Liquids might contain Symptom Cause Solution minerals that can corrode the electronic circuits. No power The vessel’s accessory If the power supply is properly ... -
Page 16: Specifications
MA300 SPECIFICATIONS FM Radio Frequency Coverage (USA) ......... 87.5 to 107.9 MHz Frequency Coverage (Europe) . - Page 17 www.asaelectronics.com v.300615...
