INDUCTION COOKTOP INSTALLATION INSTRUCTIONS INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER. IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE. READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
Page 2
INDUCTION COOKTOP INSTALLATION INSTRUCTIONS Overhead Cabinet Should Not Exceed a Maximum Depth of 13" (33 cm) Min. Min. Recommended 30" (76.2 cm) Min. Clearance Distance Between Rear Between the Top of the Edge of Cutout and Cooking Platform and the Nearest Combustible Bottom of an Unprotected 10"...
INDUCTION COOKTOP INSTALLATION INSTRUCTIONS Important Notes to the Installer An extension cord must not be used WARNING 1. Read all instructions contained in these installation with this appliance. Such use may result in a fire, instructions before installing the cooktop. electrical shock, or other personal injury.
Page 4
INDUCTION COOKTOP INSTALLATION INSTRUCTIONS If the cable from appliance is equipped with 3 wires: Where local codes permit connecting the If cooktop is used in a new branch circuit appliance-grounding conductor to the neutral installation (1996 NEC), mobile home, recreational (white) wire (see figure 3): vehicle, or where local codes DO NOT permit 1.
Page 5
INDUCTION COOKTOP INSTALLATION INSTRUCTIONS If the cable from appliance is equipped with 4 wires: Where local codes permit connecting the If cooktop is used in a new branch circuit appliance-grounding conductor (wire) to the installation (1996 NEC), mobile home, recreational neutral (white) wire (see figure 5): vehicle, or where local codes DO NOT permit grounding through the neutral (white) wire (see...
INDUCTION COOKTOP INSTALLATION INSTRUCTIONS Cooktop Installation Do not remove the spring spacers on WARNING 1. Visually inspect the cooktop for damage. Also make the edges of the cooktop. These spacers center the sure all cooktop screws are tight (see Figure 7). cooktop in the space provided.
Page 7
INDUCTION COOKTOP INSTALLATION INSTRUCTIONS For typical under counter installation of an electric built-in oven see Figure below. Only certain cooktop models may be installed Note 1: 4” x 4” (10.2 X 10.2 cm) opening to over certain built-in electric oven models. route armoured cable from cooktop to junction box.
