Multimedia LCD Projector
About User manual
Projector Feature
The content of this manual is subject to change without period notice.
All rights reserved.
Issue of edition 0102.25_04
Thank you for purchasing the LCD projector.
Please read this user's manual thoroughly to
ensure correct usage of the projector and its
features. After reading, store this instruction
manual in a safe place for future reference.
1. Business/ Home theater projector.
2. Support P-scan / 3:2 pull down
3. Intelligent controlling fan system.
4.Two way keystone function, horizontal & vertical.
5.Auto ceiling function.
6.Still function, digital zoom
7.Silm type remote controller.
Multimedia LCD Projector
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EX 27020 and is the answer not in the manual?

Questions and answers

Related Manuals for Everest EX 27020

Summary of Contents for Everest EX 27020

  • Page 1 Multimedia LCD Projector Multimedia LCD Projector About User manual Thank you for purchasing the LCD projector. Please read this user’s manual thoroughly to ensure correct usage of the projector and its features. After reading, store this instruction manual in a safe place for future reference. Projector Feature 1.

  • Page 2: Table Of Contents

    Multimedia LCD Projector Table of Contents ‧ Safety Instructions..........04 ‧ Checking the Package Content......10 ‧ Before Use Names and Function of Each Part Main Unit........... ..12 Keypad Control ..........14 Rear View / IO Board ........16 ..18 Bottom View..........
  • Page 3 Multimedia LCD Projector Basic Operation Turning on the Projector........35 Adjusting the screen image......37 Turning off the power........38 Function of Menu(OSD) Keypad operating.......... 39 Computer mode..........40 Video Mode..........47 Maintenance and Troubleshooting Cleaning the Projector........

  • Page 4: Safety Instructions

    Multimedia LCD Projector About the symbols Various symbols are used in this instruction manual and on the product itself to ensure correct usage, to prevent danger to the users and others, and to prevent property damage. The meanings of these symbols are described below. It is important that you read these descriptions thoroughly and fully understand the contents.
  • Page 5 Multimedia LCD Projector Warning ! If a problem should occur. • If smoke or a strange odors arise, continued use could result in fire or electrical shock. In such case, immediately turn off the power switch and then disconnect the power plug from the power outlet.
  • Page 6 Multimedia LCD Projector Warnning Do not look through the lens when the lamp is on. Never look through the lens when the lamp is on. The powerful light could adversely affect vision. Use special caution in households where children are present. Avoid shock or impact on the projector.
  • Page 7 Multimedia LCD Projector Caution Placing heavy objects on top of this projector could result in loss of balance or falling and cause personal injury or damage the projector. Do not block the ventilation openings. • Do not block the ventilation openings of this projector. Blocking ventilation could lead to internal overheating which could result in fire.
  • Page 8 Multimedia LCD Projector Caution Avoid installation in humid or dusty locations. • Do not install this projector in a humid or dusty location. This could result in fire or electrical shock. Do not handle the power cord roughly. ! Keep the power cord away from heaters; the heat could melt the power cord and cause fire or electrical shock.
  • Page 9 Multimedia LCD Projector Location of product safety labels *Safety labels are used on or within the projector to alert you to items or areas requiring your attention. Never look into the lens w hile the pr ojector is on. Name card...

  • Page 10: Checking The Package Content

    Multimedia LCD Projector Checking the Package Contents Projector with Lens cover Remote Control ( included battery) Power Cord S-Video Audio/Video Cable Computer cable Speaker Cable Filter Sponge User's Manual (included CD)
  • Page 11 Multimedia LCD Projector Optional Contents Remote control (Type 2, with remote mouse and Laser point function) 2. USB Mouse ( support type 2 remote control) 3. DVI Cable 4. RGB -DVI Adapter 5. YPbPr-RGB Cable 6. Carring Bag Filter Sponge...

  • Page 12: Main Unit

    Multimedia LCD Projector Part Names and Function: Main Unit 8. Control panel Speaker Outlet ventilation 1.Zoom ring 4.Filter cover( Bottom) 2. Focus ring 3 Front IR receiver 6 Foot adjuster button 7. Lens cover 5. Front/ Rear adjustable foot 1. Zoom Ring Use the Zoom Ring to adjust the size of the projected image.
  • Page 13 Multimedia LCD Projector 3. Front IR receiver When using the remote control,point the remote control at this sensor.. 4.Filter cover Prevents dust and other foreign particles from being drawn into projector. Remove the Filter cover to clean the air filter. 5.Front / Rear adjustable foot Extend and retract to adjust the projection angle 6.Foot adjuster button...

  • Page 14: Keypad Control

    Multimedia LCD Projector Keypad control 9. Lamp indicator 8. Power indicator 7. Key stone 6. Menu-left/right, Menu- up/down 3. Blank 10.ESC 1.Power E nt er 4. Auto 2.Input source 5. Menu 1.Power button Power on / operation mode, Standby mode, Cooling-down mode 2.
  • Page 15 Multimedia LCD Projector 4. Auto Automatically adjusts the setting to match the current input. 5. Menu Display or hides the OSD main menu page. 6.Menu-up /down,Menu-right / left Selecting OSD menu item up or down / Selecting and adjusting the function of OSD menu item 7.

  • Page 16: Rear View / Io Board

    Multimedia LCD Projector Rear View / IO Board 12.Rear IR receiver Security lock Inle t Ventilation 10. Power socket 9.USB mouse connector 11. Power switch 8.Audio in C ontrol(R S -232C ) C om put er 2/ Y PbPr C om put er 1/ D V I M oni tor O ut A udio U SB...
  • Page 17 Multimedia LCD Projector 4. Control (RS-232C) Serial data port for controlling the projector with a computer or other RS-232 control device. 5. S-Video connector S-Video signal from a video source. 6. Component Video connector ( Y,Cb,Cr) Component video (Y,Cb,Cr) signal from a video source. 7.

  • Page 18: Bottom View

    Multimedia LCD Projector Bottom View 1.Suspension bracket fixing points (3) 2.Air filter cover Front adjustable foot Front adjustable foot EMI Label Name card 3.Remote control 1. Suspension bracket fixing points(3 points) Install the optional ceiling mount here when suspending the projector from the ceiling. 2.

  • Page 19: Remote Control

    Multimedia LCD Projector Remote Control (Type 1) Power Auto Power on / operation Refresh the current image. INPUT mode, Standby mode, Cooling-down mode Menu down/Menu up, Menu left/ Menu right Selecting and adjusting Enters into last the function of OSD status at OSD menu menu item or hides the OSD menu.

  • Page 20: Inserting The Batteries

    Multimedia LCD Projector Remote Control Batteries Installation 1. Remove the battery cover. 2. Loading the batteries. Make sure the plus and minus poles are correctly oriented. 3. Close the battery cover. Caution Avoid excessive heat and humidity. • • Do not drop the remote control. •...
  • Page 21 Multimedia LCD Projector Remote Control-Type 2 (optional) Power Computer source Power on / operation Selects between RGB mode, Standby mode, input source —computer1, Cooling-down mode computer2 /RGB, 2. Laser Pointer computer2/Y, Pb, Pr, DVI Use laser pointer 11. Video source from remote control.
  • Page 22 Multimedia LCD Projector Remote Control Batteries Installation Loading AAA batteries into the remote control. 1. Remove the battery cover. Push the knob while lifting up the battery cover. 2. Loading the batteries. Make sure the plus and minus poles are correctly oriented. 3.

  • Page 23: Installation

    Multimedia LCD Projector Installation Setting Up the Projector The projector supports the following four different projection methods * Front projection * Rear...
  • Page 24 Multimedia LCD Projector * Rear ceiling projection * Front ceiling projection A special method of installion is required in order to suspend the projector from the ceiling.Please ask your dealer for details.
  • Page 25 Multimedia LCD Projector Screen Size and Projection Distance The distance between the projector and screen determines the actual image size.Refer to the table below to determine the image size at a given distance.. 1. XGA F: # 1.75 Image Size(inch) Distance(M) 1.17 1.40...

  • Page 26: Screen Size And Projection Distance

    Multimedia LCD Projector Screen Size and Projection Distance The distance between the projector and screen determines the actual image size. Refer to the table below to determine the image size at a given distance.. 1.SVGA F:# 2.0 Image Size(inch) Distance(M) 0.93 1.11 1.23...

  • Page 27: Adjusting The Image Position

    Multimedia LCD Projector Adjusting the Image Position Use the adjustable feet at the front of the projector to set the image height. Rotate the adjustable feet at the rear of the projector to fine-tune the image position. *When the feet are adjusted, it may cause the shape of the projected images to become distorted.

  • Page 28: Moving The Projector

    Multimedia LCD Projector Moving the projector 1.Use the carrying bag when moving the projector.(option) 2.Replace the lens cover and retract the front adjustable foot when moving the projector to prevent damage to the projector. Caution The optional carry bag is intended to protect the projector from dust and scratches on the surface of the cabinet.

  • Page 29: How To Connect Desktop Pc

    Multimedia LCD Projector How to Connect Desktop PC Before starting, make sure that the projector and computer are both turned off. 1. Connect the computer cable. 1.1 Connect either end of the computer cable to the projector’s computer 2 / Y Pb Pr input port. 1.2 Disconnect the monitor cable from the computer and connect the other end of the terminal where the monitor cable is disconnected from the computer.

  • Page 30: Laptop Pc

    Multimedia LCD Projector Laptop PC PC laptop computer Before beginning, make sure that the projector and laptop are both turned off. 1. Connect the computer cable. 1.1 Connect either end of the computer cable to the projector’s computer 2 / Y Pb Pr input port. 1.2 Connect the other end of the project cable to the monitor out connection on the laptop.

  • Page 31: Dvi-I Port

    Multimedia LCD Projector PC desktop computer (DVI-I port) before beginning, make sure that the projector and computer are both turned off. 1. Connect the computer DVI cable.(optional) 1.1Connect either end of the DVIcable to the projector’s computer 1 input port. 1.2 Disconnect the monitor cable from the computer and connect the other end of the terminal where the monitor cable is discon- nected from the computer.

  • Page 32: Usb Mouse

    Multimedia LCD Projector USB Mouse USB mouse compatible MS-Window98/2000/NT/XP/Me, Macintosh :OS8.6~10.1, and a Microsoft Mouse driver installed. 1.Insert the end of the USB Cable (B-Type) to the projector’s USB port. 2.Connect the end of the USB Cable (A-type) to the computer’s USB port.

  • Page 33: Video

    Multimedia LCD Projector V ideo A. Connect to a video source The Projector can receive composite Video/stereo-audio, S-Video or Component video(YCbCr) signals. 1. The composite video and stereo-audio inputs are yellow, white and red RCA connect on the projector. Connect the yellow RCA plug at one end of the video/stereo- audio cable to the yellow video jack.
  • Page 34 Multimedia LCD Projector 4. For the Component video(Y,Cb,Cr) input uses the green, red, and blue RCA connections on the back of the projector. Connect the green RCA plug at one end of the component video cable to the projector’s Y Jack( green color). Connect the blue RCA plug at one end of the component video cable to the projector’s Cb jack (blue color).

  • Page 35: Basic Operation Turning On The Projector

    Multimedia LCD Projector Basic Operation Turning on the projector Procedure 1. Check the power is turned off for the projector and all components connected to the projector. 2. Remove the lens cover. 3. Connect the power cord to the projector. 4.
  • Page 36 Multimedia LCD Projector 6.The power indicator will flash green . 7.Press the [ VIDEO]/[PC] button on the control panel or the Computer/ Video buttons on the remote controller to select the appropriate source. 8.Using the zoom ring to adjust the screen size. 9.Using the focus ring to adjust the focus.

  • Page 37: Adjusting The Screen Image

    Multimedia LCD Projector Adjust the Screen Image 1.Adjusting the image size Turn the zoom ring on the projector to adjustor to adjust the image 2.Adjusting the image height. Extend or retract the front adjustable foot to adjust the height of the image.

  • Page 38: Turning Off The Power

    Multimedia LCD Projector Turning off the projector 1. Press the button on the projector or remote control. The power off confirmation message appears. If you do not want to power off the projector, ignore the message and it will disappear. 2.

  • Page 39: Keypad Operating

    Multimedia LCD Projector Functions of Menu(OSD) Keypad Operating: Enter : Turn on and turn off the projector 2. BLANK : Blanks the projected image. If the projector is left in Blank mode for more than 15 minutes, the projector will automatically shut off the lamp and enter cool-down mode.
  • Page 40 Multimedia LCD Projector PC Mode brightness -123- contrast -123- color temp 6500 7300 9300 user user red -123- user green -123- user blue -123- 1 . PIC TU R E Brightness - 6 4/+ 63 A d justs the overall image b rightness C o ntrast - 6 4/+ 63 A d justs the difference b etw een light and d ark...
  • Page 41 Multimedia LCD Projector Volume -12- base -12- treble -12- mute 2 . A U D IO Vo lum e 0 /+ 3 1 A d justs the vo lum e B a se - 8 /+ 7 A d justs the b a se to ne Tre b le - 8 /+ 7 A d justs the tre b le to ne...
  • Page 42 Multimedia LCD Projector h position -123- v position -123- phase -123- frequency -123- keystone V -123- keystone H -123- auto sync exectue auto search 3. SETTING H position -128/+127 Move the image position horizontally V position -128/+127 Move the image position vertically Phase -128/+127 Set the synchronization polarity...

  • Page 43: Computer Mode

    Multimedia LCD Projector zoom/pan execute still blank reset all execute resize language English select source execute Computer 2 Mode select source computer 1 computer 2(RGB) computer2(Y,Pb,Pr) video s-video Y Pb Pr...
  • Page 44 Multimedia LCD Projector 4.AD VAN CE Zoom/ pan Execute Enlarge or reduce the size of the image, pan an image to view images that are larger than the display area S till O n/off F reezes the current image on the screen Blank O n/off Hides the image, displays a blank, black screen*(see...
  • Page 45 Multimedia LCD Projector PIP size PIP Source brightness -123- contrast -123- sharpness -123- color -123- tint -123- 5. PIP PIP size O ff 123 Sets the PIP image size PIP Position 9- position M oves the PIP image position PIP source AV,S,YPbPr Selects the PIP input source PIP brightness -64/+63...
  • Page 46 Multimedia LCD Projector auto ceiling front ceiling rear ceiling and rear lamp mode normal economic lamp timer 1:55 Reset lamp timer execute 6 . PR ES EN TATIO N A uto ceiling O n/off A uto matically inverts the image when the p ro jecto r is A utomatically turned upsid e d ow n i.e.
  • Page 47 Multimedia LCD Projector Reset lamp timer  After you select [reset all] on the OSD menu, the following confirmation message will appear on the screen. Press the Menu-right button on the remote control or the button on the keypad to reset the OSD Menu values. Press the ESC button or ignore the message to exit the Reset All function without changing any settings.

  • Page 48: Video Mode

    Multimedia LCD Projector Video Mode brightness -123- contrast -123- sharpness -123- color -123- tint -123- color tem p 6500 7300 9300 user user red -123- user green -123- user blue -123- 1. PICTURE Brightness -64/+63 Adjusts the overall image brightness Contrast -64/+63 Adjusts the difference between light and dark areas...
  • Page 49 Multimedia LCD Projector Volume -12- base -12- treble -12- mute 2. AUD IO Volume 0/+31 Adjusts the volume Base -8/+7 Adjusts the base tone Treble -8/+7 Adjusts the treble tone Mute O n/O ff Mutes the volume on/off...
  • Page 50 Multimedia LCD Projector h position -123- v position -123- phase -123- frequency -123- keystone V -123- keystone H -123- auto sync exectue auto search 3. SETTING H position -128/+127 Move the image position horizontally V position -128/+127 Move the image position vertically Phase -128/+127 Set the synchronization polarity...
  • Page 51 Multimedia LCD Projector zoom/pan execute still blank reset all execute resize language English select source execute Computer 2 Mode select source computer 1 computer 2(RGB) computer2(Y,Pb,Pr) video s-video Y Pb Pr...
  • Page 52 Multimedia LCD Projector 4 .A D VA N C E Zo o m/ p an Execute Temp o rarily enlarge a p o rtio n o f the ima ge and view p o rtio ns o f the image that are no t visib le in the d isp lay a re a.
  • Page 53 Multimedia LCD Projector auto ceiling front ceiling rear ceiling and rear lamp mode normal economic lamp timer 1:55 Reset lamp timer execute 6. PR ES EN TATIO N Auto ceiling O n/off A utomatically inverts the image w hen the p rojector is A utomatically turned upside dow n i.e.
  • Page 54 Multimedia LCD Projector Reset lamp timer  After you select [reset all] on the OSD menu, the following confirmation message will appear on the screen. Press the Menu-right button on the remote control or the button on the keypad to reset the OSD Menu values. Press the ESC button or ignore the message to exit the Reset All function without changing any settings.

  • Page 55: Maintenance And Troubleshooting

    Multimedia LCD Projector Maintenance and Troubleshooting Cleaning the projector Warning: Always unplug the projector before performing any maintenance. Clean the projector case by wiping it gently with a soft cloth. If necessary, the case can be cleaned using a neutral detergent and a soft cloth ensoure the case is complete dry before turning the projector back Cleaning the lens Use a commercially-available air blower, or use a lens cleaning paper...

  • Page 56: Cleaning The Air Filter

    Multimedia LCD Projector Cleaning the Air Filter A.When the air filter becomes clogged with dust, etc., the projector power may overheat and turn itself off to prevent internal damage. When cleaning the filter, stand the projector up on its side to prevent dust from entering the projector.

  • Page 57: Lamp Replacement

    Multimedia LCD Projector Lamp Replacement When the life of the projector lamp of this projector draws to an end, the projector would give a signal to remind you to replace the lamp with a new one promptly.In order to maintain the lamp work efficiently Caution: Need to cool- down the projector at lease 15 minutes before you open the lamp cover.

  • Page 58: Indicator

    Multimedia LCD Projector Indicators The Power and lamp indicators show the status of the projector. Before requesting repair, check the projector status using the chart below. If the problem cannot be resolved contact your dealer Power (Green) SignalNotes Lamp(Red) Conditions Slow flashing * Projector is ready to be turned on (normal) Stand by mode...

  • Page 59: List Of Monitor Displays Modes

    Multimedia LCD Projector List of Supported Monitor Displays Signal Refresh Rate Resolution (Hz) 640X350 640X480 VGACGA 640X400 VGA text 720X400 VESA 720X350 VESA 60/72/75/85 640X480 SVGA 56/60/72/75/85 800X600 60/70/75/85 1024X768 SXGA 60/70/75 1280X1024 TV(480i),NTSC TV(575i),PAL SDTV(480p) HDTV(720p) 1280X720 HDTV(1080i) 1920x1080 Mac13 640X480 Mac16...

  • Page 60: Specification

    Multimedia LCD Projector Specification Epson0.7” Poly Silicon TFT LCDx3 Projection Display True XGA, 1024x768 / SVGA,800x600 Resolution Manual,F#1.75~2.10,f=26.7~32.0mm / Projection Lens Manual,F#2.0~2.38,f=21.2~25.4mm 30”~260” Image Size 1.25~8.8m(4.1~28.9’) Projection distance Typical 85% image center-to-corner Uniformity 6400 K~ 6800K Color Temperature Horizontat 15~100kHz, V-syns.43~120Hz Scanning Frequency NTSC,PAL,SECAM,HDTV 1080i/720P/480P Video Compatibility...
