Philips 202F Electronic User's Manual
  1. Manuals
  2. Brands
  3. Philips Manuals
  4. Monitor
  5. 202F
  6. Electronic user's manual

Philips 202F Electronic User's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
electronic user's manual
file:///D|/EDFU/crt_19_5/edoc/english/202F/manual.html2005-04-21 ¤W¤È 09:40:29

Advertisement

Table of Contents
loading

Related Manuals for Philips 202F

Summary of Contents for Philips 202F

  • Page 1 ¤W¤È 09:40:29...

  • Page 2: Safety And Troubleshooting Information

    When positioning the monitor, make sure the power plug and outlet are easily accessible. Consult a service technician if the monitor does not operate normally when operating instructions of this manual are followed. RETURN TO TOP OF THE PAGE file:///D|/EDFU/crt_19_5/edoc/english/202F/SAFETY/SAFETY.HTM2005-04-21 ¤W¤È 09:40:33...
  • Page 3 Notational Descriptions About This Guide This electronic user's guide is intended for anyone who uses the Philips Color Monitor. It describes the monitor's features, setup, operation and all other information, which is the same exact information described in our printed version.

  • Page 4: Notational Descriptions

    Some warnings may appear in alternate formats and may be unaccompanied by an icon. In such cases, the specific presentation of the warning is mandated by regulatory authority. RETURN TO TOP OF THE PAGE file:///D|/EDFU/crt_19_5/edoc/english/202F/ABOUT/ABOUT.HTM (2 of 3)2005-04-21 ¤W¤È 09:40:33...
  • Page 5 About This Electronic User's Manual ©2005 Koninklijke Philips Electronics N.V. All rights reserved. Reproduction, copying, usage, modifying, hiring, renting, public performance, transmission and/or broadcasting in whole or in part is prohibited without written consent of Philips Electronics N.V. file:///D|/EDFU/crt_19_5/edoc/english/202F/ABOUT/ABOUT.HTM (3 of 3)2005-04-21 ¤W¤È 09:40:33...

  • Page 6: Product Information

    Aperture grille, flat, high contrast, anti-glare, anti-static, anti • Tube type reflection • Phosphor • Recommended display area 15.4" x 11.6" / 392 x 294 mm • Maximum display area 16.0" x 12.0" / 406 x 305 mm file:///D|/EDFU/crt_19_5/edoc/english/202F/PRODUCT/PRODUCT.HTM (1 of 5)2005-04-21 ¤W¤È 09:40:34...
  • Page 7 Using a standard unified color space, sRGB will help represent pictures taken by an sRGB compatible device correctly on your sRGB enabled Philips monitors. In that way, the colors are calibrated and you can rely on the correctness of the colors shown on your screen.
  • Page 8 < 1W 99 % Yellow ® ® PHILIPS This monitor is NERGY compliant. s an NERGY artner, ® determined that this product meets the NERGY guidelines for energy efficiency. RETURN TO TOP OF THE PAGE file:///D|/EDFU/crt_19_5/edoc/english/202F/PRODUCT/PRODUCT.HTM (3 of 5)2005-04-21 ¤W¤È 09:40:34...
  • Page 9 , full white pattern. * These information are subject to change without notice. RETURN TO TOP OF THE PAGE Pin Assignment The 15-pin D-sub connector (male) of the signal cable (IBM systems): Assignment Assignment file:///D|/EDFU/crt_19_5/edoc/english/202F/PRODUCT/PRODUCT.HTM (4 of 5)2005-04-21 ¤W¤È 09:40:34...
  • Page 10 Data clock line (SCL) Blue video ground RETURN TO TOP OF THE PAGE Views Follow the links to see various views of the monitor and its components. Front View Rear View RETURN TO TOP OF THE PAGE file:///D|/EDFU/crt_19_5/edoc/english/202F/PRODUCT/PRODUCT.HTM (5 of 5)2005-04-21 ¤W¤È 09:40:34...

  • Page 11: Installing Your Monitor

    Installing your Monitor Installing your Monitor Front View • Rear View Front View Power button switches your monitor on. OK button which when pressed will take you to the OSD controls file:///D|/EDFU/crt_19_5/edoc/english/INSTALL_4/INSTALL.HTM (1 of 4)2005-04-21 ¤W¤È 09:40:35...

  • Page 12: Rear View

    Installing your Monitor Contrast hotkey. When the UP arrow is pressed, the adjustment controls for the CONTRAST will show up. UP and DOWN buttons are used when adjusting the OSD of your monitor Brightness hotkey. When the RIGHT arrow is pressed ,the adjustment controls for BRIGHTNESS will show up.
  • Page 13 Installing your Monitor D-Sub Port - Attach the D-Sub connector that comes with your monitor here. Other end connects to your PC. Power in - Attach power cable here. file:///D|/EDFU/crt_19_5/edoc/english/INSTALL_4/INSTALL.HTM (3 of 4)2005-04-21 ¤W¤È 09:40:35...
  • Page 14 Installing your Monitor BNC Connectors - Attach the connectors here to get the best video performance from your monitor. RETURN TO TOP OF THE PAGE file:///D|/EDFU/crt_19_5/edoc/english/INSTALL_4/INSTALL.HTM (4 of 4)2005-04-21 ¤W¤È 09:40:35...

  • Page 15: Description Of The On-Screen Display

    Description of the On Screen Display What is the On-Screen Display? This is a feature in all Philips monitors which allows an end-user to adjust screen performance of monitors directly though an on-screen instruction window. The user interface provides user- friendliness and ease-of-use when operating the monitor.
  • Page 16 On-Screen Display RETURN TO TOP OF THE PAGE The OSD Tree Below is an overall view of the structure of the On-Screen Display. You can use this as reference when you want to later on work your way around the different adjustments. Your monitor may not include all the items in the OSD tree shown below.
  • Page 17 On-Screen Display file:///D|/EDFU/crt_19_5/edoc/english/OSD/OSDDESC.HTM (3 of 4)2005-04-21 ¤W¤È 09:40:35...
  • Page 18 On-Screen Display RETURN TO TOP OF THE PAGE file:///D|/EDFU/crt_19_5/edoc/english/OSD/OSDDESC.HTM (4 of 4)2005-04-21 ¤W¤È 09:40:35...

  • Page 19: Customer Care And Warranty

    Customer Care and Warranty Customer Care & Warranty PLEASE SELECT YOUR COUNTRY/AREA TO READ THE WARRANTY COVERED: WESTERN EUROPE: Austria • Belgium • Cyprus • Denmark • France • Germany • Greece • Finland • Ireland • Italy • Luxembourg • the Netherlands • Norway • Portugal • Sweden • Switzerland •...

  • Page 20: Frequently Asked Questions

    Increasingly, monitors include USB hub functionality. But not all users need or want a USB hub. To give users freedom of choice, Philips provides an optional USB hub (type number PCUH411). The USB hub consists of two parts that are normally connected: one is functional, the other aesthetic. The aesthetic element is a removable cover.
  • Page 21 Frequently Asked Questions What models are Mac compatible? All listed Philips monitors are Mac compatible. BUT, you may need an adapter to connect the monitor to your Mac system. Please contact your dealer/reseller for details. What is TCO? TCO is a Swedish abbreviation for the Swedish Confederation of Professional Employees.
  • Page 22 Go to 'My Computer' and select 'Control Panel' followed by 'Monitor Control.' Select "All default selection' and choose your Philips monitor model from the default driver list. Plug and Play will automatically enable the EPA tick box for you. In DOS or Windows 3.1, you must first make sure your PC supports power saving.
  • Page 23 Frequently Asked Questions "Refresh rate" describes the number of times an entire screen is vertically scanned each second. In other words: If a monitor's refresh rate is 85 Hz, its screen is refreshed - or vertically scanned - 85 times per second.
  • Page 24 Simply press OK button then select "Reset to factory settings" to restore all settings. 16. What is LightFrame ? LightFrame is a Philips technology breakthrough which offers a unique and revolutionary solution for boosting a monitor 's brightness and sharpness. With LightFrame...
  • Page 25 Frequently Asked Questions 19. Will anyone else have this? LightFrame was invented, developed and patented by Philips. It is a unique feature that you will find exclusively in Philips monitors. 20. Will LightFrame shorten the life of a monitor? No. Extensive testing has confirmed LightFrame does not adversely affect monitor life. Today's state- of-the-art Philips monitors employ improved phosphors and are designed for high light output.
  • Page 26 25. What is Philips monitors' solution for audio? Not all users need multimedia capabilities. To give users freedom of choice, Philips provides an optional Multimedia Base (type number: 6G3B10). The Multimedia Base replaces the easily removable standard pedestal of the monitor.
  • Page 27 Only the monitor's height is increased by only 3 centimeters. 29. Where can I buy a multimedia base to incorporate with my Philips monitor? Please contact your dealer/reseller for details.
  • Page 28 Calibration should be performed after the monitor is warmed up. Auto Calibration takes place when a monitor receives a signal indicating an imminent switch to its sleep mode/stand-by mode. 34. Which models of Philips monitors are equipped with Auto Calibrate feature? file:///D|/EDFU/crt_19_5/edoc/english/FAQ.HTM (9 of 14)2005-04-21 ¤W¤È 09:40:37...
  • Page 29 Frequently Asked Questions Auto Calibrate is currently available in the new 201P, 201B and 109P. 35. The Main Menu displays OSD MAIN MENU LOCKED . Pressing the front control panels hasno effect. How can I unlock this function? Press and hold the OSD menu key for about 10 seconds until picture displays "OSD MAIN MENU UNLOCKED"...
  • Page 30 This is an intentional design and is an industry standard, not just for Philips monitors. Please be aware that not all models in the Philips range has this manual degauss function. Some models are built with an auto degauss feature which automatically degausses the monitor when it is switched on.
  • Page 31 Frequently Asked Questions 42. How do I adjust the picture on the screen? Please perform the following to correct the picture image: Reset your monitor via the OSD menu Adjust the Horz (width) and/or Vert size (height) in the OSD Change monitor timing to work at the recommended resolution 43.
  • Page 32 Frequently Asked Questions 45. I have noticed two thin horizontal lines on the screen of my Philips monitor. Is this normal? This phenomenon can occur with Philips 107P, 109P and 201P monitors and is normal. Your monitor is using an Aperture Grille, which consists of fine vertical wires to align the electron beams with the phosphors on the screen.
  • Page 33 50. Why does the picture disappear after I press the on/off button quickly? This is a unique Philips feature designed to preserve the life of your monitor. Please allow 5 seconds between powering off and on your monitor, your picture will then be restored.
  • Page 34 W X Y Z Autoscan A microprocessor-based feature of Philips Brilliance monitors is able to detect automatically horizontal and vertical frequencies of input signals with those of the installed video card. An autoscan monitor can thus operate with a wide range of video cards. MultiSync, a registered trademark of NEC, provides a similar function.

  • Page 35: Color Temperature

    A way of describing the color of a radiating source in terms of the temperature (in degrees Kelvin) of a black body radiating with the same dominant frequency as the source. Most Philips monitors offer the possibility of setting the color temperature to any desired value. Contrast The ratio between the brightness of the brightest and darkest parts of a picture.
  • Page 36 Glossary a picture is set by the brightness of the unexcited phosphor, which is governed by the degree with which ambient light is reflected. Contrast is therefore reduced in conditions of high ambient light levels. Black Matrix tubes reflect less ambient light so exhibit higher contrast than other tubes. Convergence error Bean misalignment causing one or more of the three beams passing through the wrong aperture in the shadow mask and striking a phosphor dot in the wrong triad.
  • Page 37 Glossary Cathode-ray tube - the general term for all tubes in which one or more electron beams emitted by a cathode are periodically scanned across a phosphor screen by means of deflection circuitry. A special form of the cathode-ray tube is the TV and monitor picture tube. RETURN TO TOP OF THE PAGE DDC (Display Data Channel) DDC is a communication channel for displays and computers.

  • Page 38: Digital Control

    This is a very advanced feature that allows the user to switch to any required mode at any instant without having to spend time readjusting the picture. It is currently available in most Philips monitors. Dot pitch The shortest distance between two phosphor dots of the same color on the screen.
  • Page 39 Glossary Dot rate Frequency in MHz of the dot clock. It is a measure of the speed with which data is transferred between the video card and subsequent processing circuitry. Also known as video dot rate. RETURN TO TOP OF THE PAGE Electromagnetic radiation standards International standards set to limit electromagnetic emissions from monitors.
  • Page 40 Glossary two important standards both derived from regulations originally laid down by Swedish authorities. MPR-II The standard originally proposed by the Swedish National Board of Measurement and Testing. It set maximum levels of electromagnetic radiation emitted by monitors, and has now been adopted as a world standard.
  • Page 41 Glossary problem can, however, be eliminated by increasing the refresh rate (number of frames/second) of the monitor to a value above around 70 Hz. Sensitivity to flicker appears to diminish with increasing age. RETURN TO TOP OF THE PAGE Hertz The unit of frequency named after the physicist Heinrich Hertz (1857-1894).
  • Page 42 Glossary INF file (Information File) Information (INF) files store information in a specific format. The set-up functions retrieve information from the INF file to use when performing installation operations. Examples of the type of information stored in an INF file include INI and registry changes, file names, and locations of the source files on source media.

  • Page 43: Line Frequency

    Glossary Linearity The degree to measure the actual location of a pixel on the screen corresponds with its intended location. ( see figure ) Line frequency See Horizontal scanning frequency. Low-emission monitor A monitor that complies with international standards on radiation. See Electromagnetic radiation standards.
  • Page 44 Glossary Alternating fields generated by the deflection yoke. These are subject to increasing attention, notably by governing authorities, the trade and the press. Although there is no scientific evidence that monitor emissions are harmful, much effort has gone into reducing emissions on the principle of better safe than sorry.
  • Page 45 Glossary Non-interlaced See Interlaced/non-interlaced. RETURN TO TOP OF THE PAGE OSD (On Screen Display) The feature that allows an end user to adjust screen performance and parameters of monitors directly through an on-screen instruction window. See CustoMax in CrystalClear section. Overscan The practice in which areas without useful video information are scanned outside the visible screen area in order to make maximum use of the screen for display of active video information.
  • Page 46 Glossary Parallelogram Distortion See Geometric distortion. Phosphor Generic name for the class of substances that exhibit luminescence. To produce a picture on screen, phosphors are deposited on the inner surface of the picture-tube screen and excited into luminescence by the electron beam. Typical examples of phosphors are P22 medium short- persistence phosphor and EBU high-color-saturation phosphor.
  • Page 47 Glossary Plug-and-Play See DDC. See USB section. RETURN TO TOP OF THE PAGE Raster The area on screen that electron beam can reach. Refresh rate See Vertical scanning frequency. Resolution The number of pixels that can be displayed on the screen. The resolution is specified as the number of pixels in a line multiplied by the number of horizontal lines.
  • Page 48 Glossary Screen coatings Anti-Static coatings Due to bombardment by beam electrons, monitor screens become electrically charged when in use. Electrically charged screens surfaces can attract dust particles. An Anti-Static coating is a conductive coating deposited on the screen (or on a glass panel immediately in front of the screen) that conducts away the charge and prevents screen dust build-up.

  • Page 49: Self-Test Function

    Glossary ARAS is one of the most effective anti-reflection/anti-static screen treatments currently available. It is composed of a multi-layer structure of transparent dielectric material that suppresses specular reflections by broadband interference effects at the screen surface. Anti-static properties are provided by a single conductive layer within the multi-layer structure. With ARAS, the intensity of reflected light is reduced from around 4.5% of the incident light (the reflectivity of uncoated screens) to less than 0.5%.
  • Page 50 Glossary common: SOG (Synchronization On Green) A properly functioning color monitor requires five kinds of signals: horizontal sync pulse, vertical sync pulse, red color signal, green color signal and blue color signal. Signals from a PC are transmitted to a monitor using one of three methods: 1.

  • Page 51: Tilt Function

    Glossary See Electromagnetic radiation standards. Tilt function See rotation function. Trapezoid distortion See Geometrical distortion. TTL signal A TTL (Transistor-transistor-logic) signal is a digital signal level for controlling the screen colors. With TTL driving, the red, green and blue signals can only be switched on or off or provided with an intensity signal.
  • Page 52 Glossary USB eliminates "case angst" -- the fear of removing the computer case to install add-on peripherals. And USB also eliminates adjustment of complicated IRQ settings when installing new peripherals. USB does away with "port gridlock." Without USB, PCs are normally limited to one printer, two Com port devices (usually a mouse and modem), one Enhanced Parallel Port add-on (scanner or video camera, for example) and a joystick.
  • Page 53 Glossary for example, a data/FAX modem device. Devices may be physical, electrical, addressable, and logical. Downstream The direction of data flow from the host or away from the host. A downstream port is the port on a hub electrically farthest from the host that generates downstream data traffic from the hub. Downstream ports receive upstream data traffic.
  • Page 54 Glossary Vertical dot pitch See Dot pitch. Vertical scanning frequency Expressed in Hz, this is the number of fields written to the screen every second in interlaced mode. In non-interlaced mode vertical scanning frequency is the number of frames (complete pictures) written to the screen every second (also known as refresh rate).
  • Page 55 Glossary A card equipped with a character or graphic generator and video memory, which maps to the screen. A microprocessor scans video memory and translates bit information from the computer into displayable video signals for the monitor. These cards comply with various standards that determine the nature and quality of the display.

  • Page 56: Download And Print

    Download and Print Download and Print This page provides an option to read the manual in .pdf format. PDF files can be downloaded into your hard disk, then viewed and printed with Acrobat Reader or through your browser. If you do not have Adobe¨ Acrobat Reader installed, click on the link to install the application. Adobe®...
  • Page 57 Download and Print 202F.pdf 202P.pdf file:///D|/EDFU/crt_19_5/edoc/english/DOWNLOAD/DOWNLOAD.HTM (2 of 2)2005-04-21 ¤W¤È 09:40:39...

  • Page 58: Troubleshooting

    Make sure the monitor cable is properly connected to your computer. (Also refer to the Quick Start Guide). Check to see if the monitor cable has bent pins. when you turn on the Make sure the computer is turned on. monitor file:///D|/EDFU/crt_19_5/edoc/english/202F/SAFETY/saf_troub.htm (1 of 3)2005-04-21 ¤W¤È 09:40:47...
  • Page 59 Check to make sure Moiré is switched off. Adjust Sync Input. Picture is not sharp. Increase your refresh rate. Unstable Picture Problem with On Refer to the instructions and troubleshooting information in Screen Display that chapter. file:///D|/EDFU/crt_19_5/edoc/english/202F/SAFETY/saf_troub.htm (2 of 3)2005-04-21 ¤W¤È 09:40:47...
  • Page 60 Troubleshooting For further assistance, refer to the Consumer Information Centers list to contact your local Philips distributor. RETURN TO TOP OF THE PAGE file:///D|/EDFU/crt_19_5/edoc/english/202F/SAFETY/saf_troub.htm (3 of 3)2005-04-21 ¤W¤È 09:40:47...

  • Page 61: Regulatory Information

    Important parameters are luminance, contrast, resolution, reflectance, colour rendition and image stability. Energy Energy-saving mode after a certain time-beneficial both for the user and the environment Electrical safety file:///D|/EDFU/crt_19_5/edoc/english/202F/SAFETY/regs/regulat.htm (1 of 3)2005-04-21 ¤W¤È 09:40:47...
  • Page 62 Philips establishes technically and economically viable objectives to optimize the environmental performance of the organization's product, service and activities. From the planning, design and production stages, Philips emphasizes the important of making products that can easily be recycled. At Philips, end-of-life management primarily entails participation in national take-back initiatives and recycling programs whenever possible, preferably in cooperation with competitors.
  • Page 63 Consumers Information Center F1rst Choice Contact Information Center in each country or the following team of Environmental specialist can help. Mr. Job Chiu - Environment manager Philips Electronics Industries (Taiwan) Ltd, Monitor Business Unit E-mail: job.chiu@philips.com Tel: +886 (0) 3 454 9839 Mr.

  • Page 64: Other Related Information

    Use a Cord Set rated minimum 5 A, 250 V ( for units set at 230V ) or 10A, 125V (for units set at 115V). The Cord Set should have the appropriate safety approvals for the country in which the equipment will be installed. RETURN TO TOP OF THE PAGE file:///D|/EDFU/crt_19_5/edoc/english/202F/SAFETY/saf_other.htm2005-04-21 ¤W¤È 09:40:47...
  • Page 65 The OSD Controls The OSD Controls Description of the On-Screen Display • The OSD Tree The OSD Controls : Brightness (HotKey) • Contrast (HotKey) • Language • Input Signal Selection • Zoom • Adjust Horizontal • Adjust Vertical • Adjust Shape •...
  • Page 66 The OSD Controls RETURN TO TOP OF THE PAGE CONTRAST To adjust your screen's contrast, follow the steps bellow. Contrast is the difference between the light and dark areas on the screen. A 100% contrast is recommended. 1) Press the button on the monitor.
  • Page 67 The OSD Controls LANGUAGE The ON SCREEN DISPLAY shows its settings in one of five languages. The default is English, but you can select French, Spanish, German, or Italian. 1) Press the button on the monitor. The MAIN CONTROLS window appears. LANGUAGE should be highlighted.
  • Page 68 The OSD Controls 4) Press the button to confirm your selection and return to MAIN CONTROLS window. CLOSE MAIN CONTROLS will be highlighted... After returning to MAIN CONTROLS . . . Smart . . . to continue to INPUT SIGNAL SELECTION, press the button until INPUT SIGNAL SELECTION is highlighted.
  • Page 69 The OSD Controls 3) Press the button. The INPUT SIGNAL SELECTION window appears. 4) Press the button to highlight INPUT B or INPUT A. 5) Press the button to confirm your selection and return to the MAIN CONTROLS window. CLOSE MAIN CONTROLS will be highlighted. After returning to MAIN CONTROLS .
  • Page 70 The OSD Controls RETURN TO TOP OF THE PAGE ZOOM ZOOM increases or decreases the size of the images on your screen. To adjust the ZOOM follow the steps below. 1) Press the button on the monitor. The MAIN CONTROLS window appears. 2) Press the button until ZOOM is highlighted.
  • Page 71 The OSD Controls 4) Press the button to adjust ZOOM. 5) Press the button to confirm your selection and return to the MAIN CONTROLS window. CLOSE MAIN CONTROLS will be highlighted. After returning to MAIN CONTROLS . . . Smart .
  • Page 72 The OSD Controls 3) Press the button. The ADJUST HORIZONTAL window appears. POSITION should be highlighted. 4) Press the button to move the image to the left or right. 5) When the position is adjusted, press the button to return to MAIN CONTROLS window, or press the to highlight SIZE.
  • Page 73 The OSD Controls 6) To adjust the horizontal size, press the button. 7) When the size is adjusted, press the button to return to MAIN CONTROLS window. CLOSE MAIN CONTROLS will be highlighted. After returning to MAIN CONTROLS . . . Smart .
  • Page 74 The OSD Controls 1) Press the button on the monitor. The MAIN CONTROLS window appears. 2) Press the button until ADJUST VERTICAL is highlighted. 3) Press the button. The ADJUST VERTICAL window appears. POSITION should be highlighted. 4) Press the button to move the image up or down.
  • Page 75 The OSD Controls 5) When the position is adjusted, press the button to return to MAIN CONTROLS window, or press the to highlight SIZE. 6) To adjust the vertical size, press the button. 7) When the size is adjusted, press the button to return to MAIN CONTROLS window.
  • Page 76 The OSD Controls ADJUST SIDE CURVE under ADJUST SHAPE allows you to adjust two of the five preset options. These two options are PINCUSHION and BALANCED pincushion. Note: use these features only when the picture is not square. 1) Press the button on the monitor.
  • Page 77 The OSD Controls 4) Press the button. The SIDE CURVE window appears. PINCUSHION should be highlighted. 5) To adjust the pincushion, press the button. 6) When the pincushion is adjusted, press the button to highlight BALANCED or press the button to return to the ADJUST SHAPE window. 7) To adjust the balanced pincushion, press the button.
  • Page 78 The OSD Controls ADJUST SIDE ANGLES is highlighted. After returning to MAIN CONTROLS ..to continue to ADJUST SIDE ANGLES, start with step 5 under ADJUST SIDE Smart ANGLES and follow the directions. Help ...to exit completely, press the button twice.
  • Page 79 The OSD Controls 3) Press the button. The ADJUST SHAPE window appears. ADJUST SIDE CURVE should be highlighted. 4) Press the button to highlight ADJUST SIDE ANGLES. 5) Press the button. The SIDE ANGLES window appears. TRAPEZOID should be highlighted. 6) To adjust the trapezoid, press the button.
  • Page 80 The OSD Controls 8) To adjust the parallelogram, press the button. 9) When the parallelogram is adjusted, press the button to return to the ADJUST SHAPE window. BACK TO MAIN WINDOWS will be highlighted. 10) Press the button to return to the MAIN CONTROLS window, or press the button until ROTATE IMAGE is highlighted.
  • Page 81 The OSD Controls 1) Press the button on the monitor. The MAIN CONTROLS window appears. 2) Press the button until ADJUST SHAPE is highlighted. 3) Press the button. The ADJUST SHAPE window appears. ADJUST SIDE CURVE should be highlighted. 4) Press the arrow until ROTATE IMAGE is highlighted.
  • Page 82 The OSD Controls 6) To adjust the rotation, press the button. 7) When the rotation is adjusted, press the button to return to the ADJUST SHAPE window. BACK TO MAIN CONTROLS should be highlighted. 8) Press the button to return to MAIN CONTROLS. After returning to MAIN CONTROLS .
  • Page 83 The OSD Controls 1) Press the button on the monitor. The MAIN CONTROLS window appears. 2) Press the button until ADJUST COLOR is highlighted. 3) Press the button. The ADJUST COLOR window appears. file:///D|/EDFU/crt_19_5/edoc/english/OSD/osd_cont.htm (19 of 27)2005-04-21 ¤W¤È 09:40:55...
  • Page 84 The OSD Controls 4) Press the button to highlight 9300K for GENERAL USE, 6500K for IMAGE MANAGEMENT, 5500K for PHOTO RETOUCH, or USER PRESET. 5) Once you have highlighted GENERAL USE, IMAGE MANAGEMENT, or PHOTO RETOUCH, press the button to confirm you selection and return to the MAIN CONTROLS window. CLOSE MAIN CONTROLS will be highlighted.
  • Page 85 The OSD Controls After returning to MAIN CONTROLS. . . Smart . . . to continue to RESET TO FACTORY SETTINGS, press the button until Help RESET TO FACTORY SETTINGS is highlighted. Next, start with step 3 under RESET TO FACTORY SETTINGS. .
  • Page 86 The OSD Controls 3) Press the button. The RESET TO FACTORY SETTINGS window appears. 4) Press the button to select YES or NO. NO is the default. YES returns all settings to their original factory adjustments. 5) Press the button to confirm your selection and return to the MAIN CONTROLS window. CLOSE MAIN CONTROLS will be highlighted.
  • Page 87 The OSD Controls . . . to exit completely, press the button. RETURN TO TOP OF THE PAGE EXTRA CONTROLS DEGAUSS EXTRA CONTROLS is a set of three features, including DEGAUSS. Degaussing removes electromagnetic build up that may distort the color on your screen. 1) Press the button on the monitor.
  • Page 88 The OSD Controls 4) Press the button to highlight DEGAUSS. 5) To degauss your screen, press the button. Your screen will be degaussed, then the MAIN CONTROLS window will reappear. CLOSE MAIN CONTROLS will be highlighted. After returning to MAIN CONTROLS . . . Smart .
  • Page 89 The OSD Controls 3) Press the button. The EXTRA CONTROLS window appears. ADJUST MOIRE will be highlighted. 4) Press the button. The ADJUST MOIRE window appears. HORIZONTAL will be highlighted. file:///D|/EDFU/crt_19_5/edoc/english/OSD/osd_cont.htm (25 of 27)2005-04-21 ¤W¤È 09:40:55...
  • Page 90 The OSD Controls 5) To adjust the horizontal moire, press the button. 6) When the horizontal moire is adjusted, press the button to highlight VERTICAL. 7) To adjust the vertical moire, press the button. 8) When the vertical moire is adjusted, press the button to return to the EXTRA CONTROLS window.
  • Page 91 The OSD Controls CLOSE MAIN CONTROLS RETURN TO TOP OF THE PAGE file:///D|/EDFU/crt_19_5/edoc/english/OSD/osd_cont.htm (27 of 27)2005-04-21 ¤W¤È 09:40:55...
  • Page 92 Philips helpdesk directly to benefit from your Philips F1rst Choice Warranty. This three-year service warranty entitles you to a swap model on-site if your monitor turns out to be faulty or defective.Philips aims at a swap within 48 hours of your call being received.
  • Page 93 Note that products that are not originally designed, manufactured, approved and/or authorized for usage within the Philips F1rst Choice countries, do not apply to the Philips F1rst Choice Warranty. In these cases the Philips global warranty terms are valid.
  • Page 94 The full address to which the faulty monitor has to be collected and the swap model should be delivered. Philips' customer help desks are located worldwide. Click here to access the F1rst Choice Contact Information. Or you can reach us via: Website: http://www.philips.com/support...
  • Page 95 Your Guarantee in Central and Eastern Europe Dear Customer, Thank you for purchasing this Philips product, which has been designed and manufactured to the highest quality standards. If, unfortunately, something should go wrong with this product Philips guarantees free of charge labor and replacement parts during a period of 36 months from date of purchase.
  • Page 96 In order to avoid unnecessary inconvenience, we advise you to read the operating instructions carefully before contacting our dealers or Information Centers In case your Philips product is not working correctly or is defective, please contact your Philips dealer or directly the Philips Service and Consumer Information Centers.

  • Page 97: Your International Guarantee

    In the event you require service whilst in another country a dealer address can be given to you by the Philips Consumer Help Desk in that country, the telephone and fax number of which can be found in the relevant part of this booklet.
  • Page 98 International Guarantee http://www.philips.com Website: file:///D|/EDFU/crt_19_5/edoc/english/WARRANTY/WAR_INTL.HTM (2 of 2)2005-04-21 ¤W¤È 09:40:59...
  • Page 99 Should you encounter any difficulties while installing or using this product, please contact Philips directly to benefit from your Philips F1rst Choice Warranty. This three-year service warranty entitles you to a swap model on-site within 48 hours of your call being received within the first year of purchase.
  • Page 100 Where IS SERVICE AVAILABLE? Warranty service is available in all countries where the product is officially distributed by Philips Consumer Electronics. In countries where Philips Consumer Electronics does not distribute the product, the local Philips service organization will attempt to provide service (although there may be a delay if the appropriate spare parts and technical manual(s) are not readily available).
  • Page 101 Please contact Philips at: (800) 479-6696 Three years free parts and three years free labor will be provided at Philips Canada depot or any one of its authorized service centers. (In Canada, this warranty is given in lieu of all other warranties. No other warranties are expressed or implied, including any implied warranties of merchantability or fitness for a particular purpose.
  • Page 102 United States Guarantee This warranty gives you specific legal rights. You may have other rights which vary from state/ province to state/province. Before contacting Philips, please prepare the following details so we can solve your problem quickly. Philips type number...

  • Page 103: F1Rst Choice Contact Information

    F1rst Choice Contact Information F1rst Choice Contact Information Country Telephone number Tariff Austria 0820 901115 0.20 Belgium 070 253 010 0.17 Cyprus 800 92256 Free of Charge Denmark 3525 8761 Local call tariff Finland 09 2290 1908 Local call tariff France 08 9165 0006 0.23...

  • Page 104: Consumer Information Centers

    Consumer Information Centers Consumer Information Centers Antilles • Argentina • Australia • Bangladesh • Belarus • Brasil • Bulgaria • Canada • Chile • China • Colombia • Croatia • Czech Republic • Dubai • Estonia • Hong Kong • Hungary •...
  • Page 105 Consumer Information Centers CROATIA Renoprom d.o.o. Mlinska 5, Strmec HR - 41430 Samobor +385 1 333 0974 ESTONIA FUJITSU SERVICES OU Akadeemia tee 21G EE-12618 Tallinn Tel: +372 6519900 www.ee.invia.fujitsu.com HUNGARY Serware Szerviz Vizimolnár u. 2-4 HU - 1031 Budapest Tel: +36 1 2426331 Email: inbox@serware.hu www.serware.hu...
  • Page 106 Consumer Information Centers ROMANIA Blue Ridge Int'l Computers SRL 115, Mihai Eminescu St., Sector 2 RO - 020074 Bucharest Tel.:+40 21 2101969 SERBIA&MONTENEGRO Tehnicom Service d.o.o. Bulevar Vojvode Misica 37B YU – 11000 Belgrade Tel: +381 11 3060 886 SLOVAKIA Datalan Servisne Stredisko Puchovska 8 SK - 831 06 Bratislava...
  • Page 107 Comel Shevchenko street 32 UA - 49030 Dnepropetrovsk Tel: +380 562320045 www.csp-comel.com Latin America ANTILLES Philips Antillana N.V.Kaminda A.J.E. Kusters 4 Zeelandia, P.O. box 3523-3051 Willemstad, Curacao Phone: (09)-4612799 Fax : (09)-4612772 ARGENTINA Vedia 3892 Capital Federal CP:1430 Buenos Aires Phone/Fax: (011)-4544 2047 file:///D|/EDFU/crt_19_5/edoc/english/WARRANTY/WARCIC.HTM (4 of 12)2005-04-21 ¤W¤È...
  • Page 108 Consumer Information Centers BRASIL Philips da Amazonia Ind. Elet.Ltda. Rua Verbo Divino, 1400 -Sao Paulo-SP CEP-04719-002 -São Paulo & 0800-701-0203 - Other Regions without São Paulo City. Phone: 11 2121 0203 CHILE Philips Chilena S.A. Avenida Santa Maria 0760 P.O. box 2687Santiago de Chile...
  • Page 109 Rambla O'Higgins 5303 Montevideo Uruguay Phone: (598)-619 66 66 Fax : (598)-619 77 77 Customer Desk: Phone: 0004054176 VENEZUELA Industrias Venezolanas Philips S.A. Apartado Postal 1167 Caracas 1010-A Phone: (02) 2377575 Fax : (02) 2376420 Canada CANADA Philips Electronics Ltd.
  • Page 110 Level 1, 65 Epping Rd North Ryde NSW 2113 Phone: 1300 363 391 Fax:+61 2 9947 0063 NEW ZEALAND Philips New Zealand Ltd. Consumer Help Desk 2 Wagener Place, Mt.Albert P.O. box 1041 Auckland Phone: 0800 477 999 (Toll Free)
  • Page 111 Consumer Information Centers HONG KONG Philips Electronics Hong Kong Limited Consumer Service Unit A, 10/F. Park Sun Building 103-107 Wo Yi Hop Road Kwai Chung, N.T. Hong Kong Phone: (852) 2619-9663 Fax: (852) 2481 5847 INDIA Phone: (020)-712 2048 ext 2765...
  • Page 112 Consumer Information Centers INDONESIA Philips Group of Companies in Indonesia Consumer Information Centre Jl.Buncit Raya Kav. 99-100 12510 Jakarta Phone: (021)-7940040 Ext 2100 Fax : (021)-7947511 / 7947539 KOREA Philips Korea Ltd. Philips House C.P.O. box 3680 260-199, Itaewon-Dong. Yongsan-Ku, Seoul 140-202...
  • Page 113 Consumer Electronics 48F PBCOM Tower 6795 Ayala Avenue cor VA Rufino St. Salcedo Village 1227 Makati City, PHILS Phone: (02)-888 0572 , Domestic Toll Free:1-800-10-PHILIPS or 1-800-10-744 5477 Fax:(02)-888 0571 SINGAPORE Accord Customer Care Solutions Ltd Authorized Philips Service Center...
  • Page 114 Consumer Information Centers THAILAND Philips Electronics Thailand Ltd. 26-28th floor, Thai Summit Tower 1768 New Petchburi Road Khwaeng Bangkapi, Khet Huaykhwang Bangkok 10320 Thailand Phone : (66) 2-652 8652 email:cic Thai@philips.com Africa MOROCCO Philips Electronique Maroc 304,BD Mohamed V Casablanca...
  • Page 115 Consumer Information Centers file:///D|/EDFU/crt_19_5/edoc/english/WARRANTY/WARCIC.HTM (12 of 12)2005-04-21 ¤W¤È 09:41:23...

  • Page 116: Protect Your Investment

    IMPORTANT - RETURN WITHIN TEN DAYS Month Year Mail This Card Today To Get The Most From Your Purchase! ❏ No, I do not want to receive personalized offers about Philips products or other information from Philips in the future. 3135 015 07803 rev. 7/02...

  • Page 117: Warranty Registration Card

    PHILIPS Warranty Card 8/16/02 12:38 PM Page 2 IMPORTANT Warranty Registration Card RETURN THE ATTACHED CARD WITHIN TEN DAYS TO ENSURE YOUR: ✓ Warranty Verification ✓ Owner Confirmation See Inside For ✓ Model Registration Valuable Benefits!
