- Page 1 XM-DTS8300 INSTALLATION MANUAL CAR AUDIO/VIDEO SYSTEM 7 Inch Million Multi-color Illumination TFT Touch Screen Detachable Control Panel Remote Control Digital Video Disc Player Control Panel USB Port and AUX Input Memory Card Slot AM/FM-RDS Digital PLL Tuning Radio BT Compatible...
- Page 2 To ensure safety while driving and to comply with laws, drivers should not watch video or operate the video device while driving.
-
Page 3: Table Of Contents
Content Precaution........Setting sheering wheel....Safety Information......Setting illumination color....Disc Note........Setting wallpaper......Installation ........Version about........Electric Connection ...... Audio setup........Remote Control ......Reset Factory Settings ....Basic Operation ......Control Panel ........ Main Menu Operation...... Unit keys ........ -
Page 4: Precaution
Precaution THANK YOU FOR PURCHASING A SOUNDSTORM MULTIMEDIA PLAYER . Before operating the unit, read this manual thoroughly and keep it handy for future reference . To avoid injury or accident , read the following precautions before installing and operating the unit . ON INSTALLATION DO NOT install any receiver in locations where;... -
Page 5: Safety Information
Safety Information CAUTION: THIS DIGITAL VIDEO PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS DIGITAL VIDEO PLAYER USES A VISIBLE/INVISIBLE LASER BEAM WHICH COULD CAUSE . HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE DIGITAL VIDEO PLAYER CORRECTLY AS INSTRUCTED. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.DO NOT OPEN COVERS AND DO NOT... -
Page 6: Disc Note
Disc Note Disc formats supported by this unusable) depending on your handle it player and conditions in the usage environment. Note these scratches are not an Digital Audio and Video Digital indication of any problem with the player. Disc size 12 cm Video Video Label side... -
Page 7: Installation
Installation NOTES: Choose the mounting location where the unit will not interfere with the normal driving function of the driver. Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. Use only the parts included with the unit to ensure proper installation. - Page 8 Installation Installating the unit DASH BOARD METAL MOUNTING HEX NUT STRAP SPRING WASHER PLAIN WASHER CONSOLE TAPPING SCREW SLIDE BRACKET HOUSING HEX BOLT SCREWDRIVER TABS KEY PLATE PLASTIC TRIM OUT KEY PLATE If you want to take CHASSIS out of the SLIDE BRACKET HOUSING, first remove the PLASTIC TRIM OUT of the both sides away, then insert the two KEY PLATE into left and right side of chassis as above illustration.
-
Page 9: Electric Connection
Electric Connection WIRING CONNECTION RADIO ANT JACK POWER CONNECTION Rear camera in Subwoofer 1 Front right rca output Subwoofer 2 Front left rca output AV IN video input AV IN left ch in Video output 1 AV IN right ch in Rear right rca output Video output 2 Rear left rca output... -
Page 10: Remote Control
Remote Control Function Ref # Button Press this button to Open/Close the operate monitor .Long press /OPEN it to adjust the angle of monitor Upward/Downward. Press this button to turn the unit ON , press and hold to turn the unit OFF. /MOD Press it briefly to select a desired work source . - Page 11 Remote Control Function Ref # Button Same operation as audio in video operation. AUDIO/5 In radio mode, press to select the store station 5. MENU/4 Press this button briefly to display the root level directory of a digital video disc. In radio mode, press to select the store station 4.
-
Page 12: Basic Operation
Basic Operation POWER ON/OFF Adjusting the viewing angle . When the monitor does not move, long Touch the “ ” ICON on screen press button on the panel to turn to turn the unit off . Press the“ ” the monitor upward or downward at onthe front panel to turn It on, fine steps to get a desired viewing press it again to turn off . -
Page 13: Main Menu Operation
Basic Operation Main Menu Operation In many modes, touch the icon Time to enter the main menu, the message Select o adjust the time like following as below. select the message will show as: 1.Display switch When the unit is power on, to adjust the brightness for the display . -
Page 14: Setting Panel Adjust
Basic Operation Panel adjust: Touch the arrow as show to calibration the display. Select the message will show as: Dual: Touch to select stereo or mono. Local: Touch to select local or distant. Area: Audio language: Touch to select radio area. Press to select audio language. -
Page 15: Setting Illumination Color
Basic Operation AUDIO SETUP Please make sure unit connect SWC wire first, and then press the wheel Touch the icon to turn to audio quality button, then press the corresponding adjustment. button on screen. To select as : Standard -> Classic ->... -
Page 16: Reset Factory Settings
Basic Operation Reset Factory Settings RESET button is placed on the housing and must be activated with either a ballpoint pen or thin metal object. The RESET button is to be activated for the following reasons: A. Initial installation of the unit when all wiring is completed. -
Page 17: Control Panel
Control Panel UNIT KEYS RESET 1. OPEN BUTTON To slide the monitor out and stand it up or into the monitor slot, press this button; 2. VOL KNOB & SEL BUTTON In normal mode, the VOL knob is used to increase or decrease the volume. Press the SEL to turn to EQ setting. - Page 18 Control Panel 6. MUTE BUTTON Press it button to switch of the loudspeakers for a short period. The word MUTE flashes in the display. Press it again to cancel the mute function. This function can also be cancelled by rotating the VOL multifunction button. 7.
-
Page 19: Radio Operation
Touch Screen Operation RADIO OPERATION Briefly touch “ ” to decrease frequency by one step of channel spacing. Listening to Radio Touch the RADIO ICON in home menu Automatic Search to enter the RADIO mode. In radio mode, During Radio mode, touch and hold icon to adjust the brightness for (for more than 2 seconds ) either “... -
Page 20: Automatic Memory Storing
Touch Screen Operation Automatic Memory Storing & ADJUSTABLE ITEMS: Program Scanning RDS REGION Touch to switch the region area as: EUROPE, USA, AMERICAN 1, AMERICAN 2 and OIRT . REG FUNCTION at certain times some stations divide up their programs into regional programs with varying content . - Page 21 Touch Screen Operation TA Traffic Announcement (Priority For Traffic Information) When the AF function has been switched When the TA function is activated, the on, the radio continuously tests the TA symbol appears in the display . signal strength of the AF frequency . During radio operation in one FM The test interval for each AF frequency frequency band the search for a traffic...
-
Page 22: Media Operation
Touch Screen Operation Media Operation Video Operation Audio Operation In audio play mode, the message will display as below : Function icons: For page turning. Function icons: Tap to turn to BT PHONE mode. Skipping Track or (after pairing and connecting a Rapid Forward/Rapid Reverse mobile phone with function). - Page 23 Touch Screen Operation Multi-Angle Function DISC Search (GOTO) (for Digital Video Only) During video playback, Touch this During Digital Video playback, button then will show a keyboard, touch icon on the touch screen. input the track you want then press Each time the button is pressed , to confirm.
- Page 24 Touch Screen Operation Notes: - The language number is different according to the disc. - Some discs only contain one subtitle language. - When no different subtitle language are recorded, “ INVALID KEY ” will be displayed at screen left top corner. Display Angle Adjust Tap this two icons to adjust the angle of monitor as Upward/...
-
Page 25: Bt Operation
, select it and input password “0000 t will pair and ” i connect with the BT device XOMAX of the car A/V system, then the frame of the BT logo will light all the time. When finishing pairing and... - Page 26 Connect your phone to the car audio as BT function,then tap the APP icon And turn on it, press “connect” at the top right corner, show a pass interface. Connect to” XOMAX” when first operation, then you can control the car audio by phone. -24-...
- Page 27 Touch Screen Operation 3 BT MUSIC 1 Touch BT MUSIC in home menu or pressing MODE button can pop up BT MUSIC interface as follows: Mute function To select the Equalizer mode USER SWF USER SWF Turning pre-switching for traffic MUSIC MUSIC announcements on and off...
-
Page 28: Aux Operation
Touch Screen Operation AUX Operation On the front panel of this unit, there is an AUX IN jack, follow the diagram below to connect analogue replay devices(only for the Audio connect, if you want to connect the Video, please plug the <Video input >... -
Page 29: Av Operation
Touch Screen Operation AV Operation Now you can watch the video from your Please plug the <Video input > External video equipment such as on the back of the unit . Digital Video players, computers, etc. Touch the AV IN icon to enter the AV IN The function of the icons as follow: mode. -
Page 30: Usb Operation
Touch Screen Operation Card OPERATION Card OPERATION USB OPERATION USB OPERATION Following the diagram below, connect The unit can support playback MP3/WMA/ JPEG/MP4 format which are stored on your USB device to the front panel SD memory cards . USB port . If it is properly connected, Please read the following instructions the device will be mounted and start before you start using a memory card . -
Page 31: Parental Control
Parental Control Parental Control Q: After inserting a Digital Video disc into the disc slot, if a dialogue box pops up and asks you to input a password, what should you do A: The playing disc is locked by a rating level of parental control. If the current rating level of parental control of the Digital Video player is lower than the one of current disc, you must input the correct password of parental control to unlock the parental control and enter a rating level... -
Page 32: Region Code
Region Code Region Code If you insert a disc into the disc slot and REGION ERROR is displayed, the car multi-media system can not play the disc. The reason is that the region codes of the car multi-media system and the used disc do not match each other. igital Video Appendix: Region code of D Motion Picture Association of America (MPAA) divided the world into 6 regions, and... -
Page 33: Specification
Specification General Power Supply Requirement..........DC 12V Current consumption............10A MAX. Audio Signal Output 2ch&4ch line out ............Frequency Response 20 Hz - 20 KHz ........... S/N Ratio 90 dB (JIS) ................Wow and Flutter Below measurable limits ..........TFT Monitor Monitor Screen Size Inch Wide ............7 Color System... -
Page 34: Troubleshooting
Troubleshooting Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. SYMPTOM CAUSE SOLUTION If the power supply is properly connected to the car accessory The car ignition switch is terminal,switch the ignition key not on... - Page 35 FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
