Summary of Contents for Glastender CS-42
- Page 1 Cocktail Station Assembly Instructions CS-72-CCW Server Side CS-42 CS-72-CCW Bartender Side F-750-045 Rev A 01/24/07...
- Page 2 Assembly Illustration Back side shown with pre-mounted clips View is of Cocktail Station Server Side Cocktail Station Components A Sink, ice, and tubing chase section B GT-30 Rotary Glasswasher C End Panel D End Panel E Trim Rail for Glasswasher F Kick Rail G Tray Shelf H Tubing Chase...
- Page 3 Cocktail Station Assembly Instructions Install 4 legs on A Sink, ice and tubing chase section and 4 legs on B GT-30 Rotary Glasswasher using 1/4-20 leg bolts provided. Attach E Trim Rail for Glasswasher to A Sink, ice and tubing chase section, using 8-32S/S hex nut and affixed 8-32x1/2 phillips pan head machine screw into the end of trim rail.
- Page 4 Promote Team Work, Increase Efficiency Glastender manufactures a large variety of pass-thru cocktail stations. Many of the typical features are detailed in the example below. Reference our product directory for additional information. Overshelves (Optional) • Single (shown) and double available...
