- Page 1 CA80 Series Vari-Angle IR Illuminator Installation Guide Rev. 1.0 QIG Part no.: L625000100G Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 2: Revision History
Revision History: * Rev. 1.0: Initial Release Package Contents 100% On/Off Status Dimming Zoom The 1/4" screws and washers are used to secure the illuminator to an external camera housing. NOTE: • The wall-mount (CMA-B04), corner-mount (AM-412), pole- mount adaptor (AM-311/312), and other brackets are separately purchased. - Page 3 • Please avoid using chemical or aerosol cleaning fluids to clean the product. Use a clean cloth slightly moistened with water. • This product contains no parts repairable by the users. Contact CaMate for services. • Power off the Illuminator as soon as smoke or unusual odors are detected. • Do not place the Illuminator on unsteady surfaces.
-
Page 4: Mechanical Drawings
Mechanical Drawings 32mm(1.3") 134.6mm(5.3") 61.5mm(2.4") 73mm(2.9") 160mm(6.3") 103.8mm(4.1") Standard Small U bracket 29.3 Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 5: Hardware Overview
Hardware Overview Reserved mounting holes for external camera housing U bracket Mounting holes Optional mounting points for U bracket Dehumidifier membrane Reserved Light sensor Combo cable Unit Weight: 2.1KG. Max. Project Area: 34684.7mm 160mm(6.3") Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... -
Page 6: Using The Remote Controller
Using the Remote Controller Beam angle selectors These buttons provide quadruple proportions of adjustable angles from the narrowest, 33%, 66%, to the widest. These angles vary with different models. When a beam angle is selected, you can use the fine-tune buttons below to tune for a desired effect. LED on/off 100% On/Off... -
Page 7: Installation
Installation IMPORTANT: It is highly recommended that the illuminator should be installed at a position higher than 3 meters from the ground. U Bracket Positions & Orientation Use the included allen wrench to attach and adjust the U bracket to your needs at the installation site. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com... - Page 8 You must first survey the installation site and determine the illumination distance. Use the remote controller to adjust the beam angle. The factory default for the beam angle selector is always at the Widest angle. Refer to the tables below for the configurable IR light beam angles and the definitions of the remote controller buttons. Each button changes to a preset beam angle. Width Example: Angle Distance 40° 33° 27° 100% On/Off Status Dimming Zoom CA8018-1040 Button Beam angle Single mount Double mount Triple mount Distance(m) Width(m) Distance(m)
- Page 9 Select a position at the installation site. e.g., under a hanging roof. You can use the alignment sticker and start drilling a hole on the roof. Apply the included grip sticker to the U bracket. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 10 Hammer the anchor in (user supplied, M6 anchors are recommended). Secure the U bracket to it, such as securing it using the bolt on a threaded pole. M6 anchor Secure the illuminator to bracket using the hex socket screws. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 11 You will need to turn on both the partner camera and illuminator to precisely match the illuminated area with the camera's field of view. If necessary, adjust the beam angle again. Turn the illuminator toward the FOV of the partner camera, shift the tilt angle, and then tighten the screw and the rear cover to secure the illuminator. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
-
Page 12: Cable Pinouts
Cable Pinouts Name Color Gauge Description (20AWG) Power input (AC/DC 24V ±10% current controlled) Black (20AWG) Green (26AWG) LED ON/OFF control * Dry contact Logic level 1(Open) = LED off Logic level 0(Close to GND) = LED on * Wet contact Logic level 1: 4V~40 V = LED off Logic level 0: 0.8V MAX = LED on Yellow (26AWG) Ground Purple (26AWG) Light sensor status output 1. Open = Day 2. Short = Night (300 lux for IR ON) Blue (26AWG) Ground RS485+ Orange (26AWG) - Page 13 +3.3V +3.3V Switch +3.3V Fuse/50mA External power source Relay Camera DI pins IR LED ON/OFF control (Green & Yellow wires) This mode means that CaMate illuminator On/Off control is triggered by camera or other alarm system. Users can decide using the appropriate dry/wet contacts depending on wiring condition. DI+: Green = TTL + voltage DI-: Yellow = TTL – voltage (GND) * Dry contact Logic level 1 (Open) = LED off Logic level 0 (Close to GND) = LED on * Wet contact Logic level 1: 4V~40 V = LED off Logic level 0: 0.8V MAX = LED on Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 14 Light sensor status output (Purple & Blue wires) This mode means that camera Day/Night mode switching is coordinated with and is triggered by the illuminator's light sensor via the DO(Digital output) connection (connected to the camera's DI pins). Users can configure the camera configuration to control the corresponding illuminator On/Off status. DO+: Purple= Open drain output, 45V Max. (current must be under 100mA) DO-: Bule = GND Light sensor status output 1. Open = Day 2. Short = Night (lower than 300 lux for IR to turn ON) Stand-alone illuminator mode This mode means that the illuminator's On/Off control is triggered by its light sensor, in the case, the default wiring is connecting the green wire with purple wire. Some cameras have related settings that need the inter-connection with the illuminator. For example, some cameras come with an IR cut filter that need to be turned off when entering night mode; or, automatically turn on the adjacent illuminator when entering night mode. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 15 This page is intentionally left blank. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
- Page 16 This page is intentionally left blank. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
