Washing Machine / User Manual
LD7003

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LD7003 and is the answer not in the manual?

Questions and answers

Summary of Contents for SUNFEEL LD7003

  • Page 1 Washing Machine / User Manual LD7003...
  • Page 2 Thank you for choosing this product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference. Icon Type Meaning...

  • Page 3: Table Of Contents

    CONTENTS 1. SAFETY INSTRUCTIONS ....................1 1.1. General Safety Warnings ....................1 1.2. During Use ........................4 1.3. Packaging and Environment..................5 1.4. Savings Information .......................6 2. TECHNICAL SPECIFICATIONS ..................7 2.1. General Appearance......................7 2.2. Technical Specifications ....................7 3. INSTALLATION .........................8 3.1. Removing Transit Bolts....................8 3.2.

  • Page 4: Safety Instructions

    1. SAFETY INSTRUCTIONS Read this user manual carefully. Your machine is for domestic use only. Using it for commercial purposes will cause your warranty to be cancelled. 1.1. General Safety Warnings • The necessary ambient temperature for operation of your Washing Machine is 15-25 °C. • Where the temperature is below 0 °C, hoses may split or the electronic card may not operate correctly.
  • Page 5 packaging or small parts from the Washing Machine. • Keep the packaging materials in a place where children cannot reach them, or dispose of them appropriately. • Use pre-wash programs only for very dirty laundry. Never open the detergent drawer while the machine is running.
  • Page 6 RISK OF DEATH FROM ELECTRICAL CURRENT • Do not connect your Washing Machine to the mains electricity supply using an extension lead. • Do not insert a damaged plug into a socket. • Never remove the plug from the socket by pulling the cord.

  • Page 7: During Use

    Washing Machine are free from foreign objects such as nails, needles, lighters and coins. Risk of fire and explosion Risk of falling and injury • Do not climb on your Washing Machine. • Make sure hoses and cables do not cause a trip hazard.
  • Page 8 packaging has been opened. • Your machine must only be installed by an authorised service agent. Installation by anyone other than an authorised agent may cause your warranty to be void. • This appliance can be used by children aged 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given...

  • Page 9: Packaging And Environment

    1.3. Packaging and Environment Removal of packaging materials Packaging materials protect your machine from any damage that might occur during transportation. The packaging materials are environmentally friendly as they are recyclable. Use of recycled material reduces raw material consumption and decreases waste production.

  • Page 10: Technical Specifications

    2. TECHNICAL SPECIFICATIONS 2.2. Technical Specifications Operating voltage / (220-240) frequency V~/50Hz (V/Hz) Total current Maximum: Water 1 Mpa pressure Minimum : (Mpa) 0.1 Mpa Total power 2100 Maximum dry laundry capacity (kg) Spinning revolution 1000 (rev / min) Programme number 2.1.

  • Page 11: Installation

    3. INSTALLATION 3.2. Adjusting the Feet / Adjusting Adjustable Stays 3.1. Removing Transit Bolts 1. Do not install your machine on a surface (such as carpet) that would prevent ventilation at the base. • To ensure silent and vibration-free operation of your machine, install it on a firm surface.

  • Page 12: Water Inlet Hose Connection

    • The mains cord of your washing or double water inlet connection (hot machine is equipped with an earthed and cold) depending on the machine plug. This plug should always be specifications. The white capped hose inserted to an earthed socket of 10 should be connected to cold water inlet amps.

  • Page 13: Water Discharge Connection

    using the supplied new fill hose. Old hoses 4.1. Detergent Drawer must not be reused. 3.5. Water Discharge Connection • Connect the water drain hose to a standpipe or to the outlet elbow of a household sink, using additional equipment. • Never attempt to extend the water drain hose.

  • Page 14: Sections

    4.2. Sections 4.3. Program Dial Main wash detergent compartment: This compartment is for liquid or powder detergents or limescale remover. The fluid • To select the desired programme, turn detergent level plate will be supplied inside the programme dial either clockwise or your machine.

  • Page 15: Using Your Washing Machine

    The function LEDs show how much longer 3. Ensure that there are no metallic the programme has to run, the additional materials on your laundry or in the functions you have selected and the wash pockets; if so, remove them. stages of the selected programme ( pre wash / wash state, rinsing stage, spinning CAUTION: Any malfunctions which...

  • Page 16: Putting Laundry In The Machine

    5.2. Putting Laundry in the Machine • If your clothes are only slightly soiled, do not pre-wash. Put a small amount of detergent (as specified by the manufacturer) into compartment II of the detergent drawer. • If your clothes are excessively soiled, select a programme with pre-wash and put ¼...

  • Page 17: Selecting A Programme

    • Gently push the door until it clicks shut. 1. Temperature Selection 5.5. Selecting a Programme Use the programme tables to select the most appropriate programme for your Temp. laundry. 5.6. Half-Load Detection System Your machine features a half-load detection system.
  • Page 18 is displayed. selected washing programme. When the spin speed selection reaches To select this function, press the Easy the lowest speed setting, pressing the Spin ironing button when the symbol is button returns to the highest speed setting. displayed. If you miss the spin speed you want to set, keep pressing the Spin button until you 6.

  • Page 19: Child Lock

    5.8. Child Lock 9. Rapid Wash(*) Auxiliary function button 3 or 4 Rapid wash The child lock function prevents the You can wash your laundry in a shorter machine being operated unintentionally or time, using less energy and water by by unsupervised children.

  • Page 20: Programme End

    5.10. Programme End Your machine will stop by itself as soon as the programme you have selected finishes. • “END” will flash on the display panel • You can open the machine’s door and remove the laundry. • Leave the door of your machine open to allow the inner part of your machine to dry.

  • Page 21: Programme Table

    6. PROGRAMME TABLE Programme Laundry type / Descriptions Very dirty, cotton and flax textiles. (Underwear, linen, COTTON 90° 90° tablecloth, towel (maximum 3,5 kg), bedclothes, etc.) Dirty cotton and flax textiles. (Underwear, linen, Pre-Wash Cotton 60° 1&2 tablecloth, towel (maximum 3,5 kg), bedclothes, etc.) COTTON ECO Dirty cotton and flax textiles.

  • Page 22: Cleaning And Maintenance

    7. CLEANING AND 7.2. Water Inlet Filters Water inlet filters prevent dirt and foreign MAINTENANCE materials from entering your machine. It is recommended that these filters are cleaned when your machine is unable 7.1. Warning to receive sufficient water, although your water supply is on and the tap is open.

  • Page 23: Pump Filter

    7.3. Pump Filter meet the holes on the front panel side. 6. Close the filter cover. WARNING: The water in the pump may be hot, wait until it has cooled down before carrying out any cleaning or maintenance. (*) Specifications may vary depending on the machine purchased.

  • Page 24: Flush Stopper / Body / Drum

    8. FLUSH STOPPER / BODY / DRUM 1. Flush stopper Remove the detergent drawer and disassemble the flush stopper. Clean thoroughly to completely remove any softener residue. Refit the flush stopper after cleaning and check that it is seated properly. 2.

  • Page 25: Troubleshooting

    9. TROUBLESHOOTING Repair of your machine should be carried out by an authorised service company. If your machine requires repair or if you cannot solve an issue with the information provided below, then you should: • Unplug your machine from the mains power supply. • Turn off the water supply.

  • Page 26: Automatic Fault Warnings And What To Do

    FAULT POSSIBLE CAUSE TROUBLESHOOTING Increase the amount of detergent following the Hard water. manufacturer’s instructions. Unsatisfactory washing result. Your laundry is too tightly packed Check that your laundry is spread out. together in the drum. As soon as the machine is The end of water drain hose is too Check that the drain hose is at a suitable height.

  • Page 27: Describing The Energy Label And Saving Energy

    11. DESCRIBING THE ENERGY Use programmes of shorter duration for lightly soiled laundry and daily washes. LABEL AND SAVING ENERGY Carry out cleaning and maintenance at regular intervals. 1. Brand 2. Model 3. Energy Class 4. Energy Consumption 5. Noise Value While Washing 6.
  • Page 28 52224564...
