GigaFast EE 410-R Broadband
Router
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Gigafast EE410-R

Summary of Contents for Gigafast EE410-R

  • Page 1 GigaFast EE 410-R Broadband Router User Guide...

  • Page 3: Fcc Warning

    FCC Warning This equipment has been tested and found to comply with the regulations for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 5: Table Of Contents

    TABLE OF CONTENT About This Guide... 1 Purpose ... 1 Overview of this User’s Guide ... 1 Introduction... 3 Applications: ... 3 Features: ... 4 Unpacking and Setup ... 5 Unpacking ... 5 Setup ... 5 Hardware Installation... 7 Front Panel... 7 Rear Panel ...

  • Page 7: About This Guide

    ABOUT THIS GUIDE Congratulations on your purchase of this 4-port Broadband Router. This device integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities in a highly flexible desktop package. It provides a complete solution for Internet surfing and office resources sharing, and it is easy to configure and operate for even non-technical users.

  • Page 9: Introduction

    INTRODUCTION With the explosive growth of the Internet, accessing information and services at any time, day or night has become a standard requirement for most people. The era of the standalone PC is waning. Networking technology is moving out of the exclusive domain of corporations and into homes with at least two computers.

  • Page 10: Features

    Resource sharing: Share resources such as printers, scanners and other peripherals. File sharing: Exchange data, messages, and distribute files thus making good use of hard disk space. Online gaming: Through the local area network, online gaming and e-commerce services can be easily setup. Firewall: A built-in firewall functions for security and anti-hack system.

  • Page 11: Unpacking And Setup

    UNPACKING AND SETUP This chapter provides unpacking and setup information for the Broadband Router. Unpacking Open the box of the Broadband Router and carefully unpack it. The box should contain the following items: One 4-port Broadband Router One external power adapter This User’s Guide If any item is found missing or damaged, please contact your local reseller for replacement.

  • Page 13: Hardware Installation

    HARDWARE INSTALLATION Front Panel The figure below shows the front panel of the Broadband Router. 4 Port 10/100Mbps Ethernet Broadband Router Front Panel POWER This indicator lights green when the hub is receives power, otherwise, it is off. SYSTEM This indicator blinks green means the Internet Broadband Router is working successful.

  • Page 14: Rear Panel

    blinks green while transmitting or receiving data on the 100Mbps Fast Ethernet or 10Mbps Ethernet network. Rear Panel The figure below shows the rear panel of the Broadband Router. RESET 4 Port 10/100Mbps Ethernet Broadband Router Rear Panel In the four port broadband router, there are two RJ-45 ports for the WAN, the port can be either connected to “II”...

  • Page 15: Hardware Connections

    Hardware connections xDSL Modem Connect the Internet Broadband Router 1. Plug in one end of the network cable to the WAN port of the four ports Internet Broadband Router, either the “X” or “II” port to be connected, depends of what the broadband modem specification is using.

  • Page 16: Check The Installation

    Check the installation The control LEDs of the Internet Broadband Router are clearly visible and the status of the network link can be seen instantly: 1. With the power source on, once the device is connected to the broadband modem, the Power, CPU, LAN and WAN port link LEDs of the Internet Broadband Router will light up indicating a normal status.

  • Page 17: Pc Network Tcp/Ip Setting

    PC NETWORK TCP/IP SETTING The network TCP/IP settings differ based on the computer’s operating system (Win95/98/ME/NT/2000) and are as follows. Windows 95/98/ME 1. Click on the “Network neighborhood” icon found on the desktop. 2. Click the right mouse button and a context menu will be show.
  • Page 18 5. Select “Disable DNS” in the “DNS” field. 6. Select “None” for the “Gateway address” field.

  • Page 19: Windows 2000

    Windows 2000 Double click on the “My computer” icon on the desktop. When “My computer” window opens, open the “Control panel” and then open the “Network dialup connection” applet. Double click on the “Local area network connection” icon. Select “Properties” to enter the TCP/IP setting window. 1.

  • Page 20: Windows Nt4.0

    Windows NT4.0 Click on the “Start” button located on the lower left corner of the menu bar. Select “Settings” and then “Control panel.” In the “Control panel” window, select “Network” to enter the TCP/IP setting window. 1. Set “IP address” to “Obtain an IP address automatically.” 2.

  • Page 21: Windows Xp

    Windows XP Point the cursor and click the right button on the “My Network Place” icon. Select “properties” to enter the TCP/IP setting window. “IP address” automatically.” “DNS” automatically.” “Obtain “Obtain address server address...

  • Page 23: Internet Broadband Router Configuration

    INTERNET BROADBAND ROUTER CONFIGURATION First make sure that the network connections are functioning normally. This Internet Broadband Router can be configured using Internet Explorer 4.0 or newer web browser versions. Login to the Internet Broadband Router Before you configure this device, note that when the Broadband Router is configured through an Ethernet connection, make sure the host PC must be set on the IP sub network that can be accessed by the xDSL/Cable modem.

  • Page 24: Quick Setup

    After entering the password, the main web page comes up, there are two choices for setting, Quick Setup or Advanced Setup, it is recommended that the beginner to use the Quick Setup, it will lead you step by step to configure the Broadband Router.
  • Page 25 1-2 WAN Connection Type To select which the WAN connection type will be connected to, point the cursor to the Cable modem (DHCP), Fixed IP, or Dial- up xDSL (PPPoE) to process. 1-2-1 Cable modem (DHCP) To connect a cable modem with the Broadband Router, check the cable modem with the related user’s guide, then the Cable modem will automatically configure itself;...
  • Page 26 1-2-2 Fixed IP If the Internet Service Providers assign a fixed IP address, choose this option and enter the assigned IP address, subnet mask, gateway IP and DNS IP addresses for your Broadband Router. 1-2-3 Dial-up xDSL (PPPoE) If connected to the Internet using a Dial-up xDSL (PPPoE) Modem, the ISP will provide a Password and User Name, and then the ISP uses PPPoE.
  • Page 27 button to dial up to the ISP when only on demand, while there is a need of connecting to the ISP automatically. 1-2-4 PPTP If connected to the Internet using (PPTP) xDSL Modem, enter the PPTP Account Name, PPTP Password, Host Name, Service IP Address, Your IP...

  • Page 28: Advance Setup

    located and translated into Internet Protocol (IP) addresses. If your ISP provided at least one DNS Server IP Address, type that IP Address in the Primary DNS address fields. You can type up to another DNS Server IP Addresses. The Router will utilize these for quicker access to functioning DNS Servers.
  • Page 29 2-1 System This page includes all the basic configuration tools for the Broadband Router. Point the selections in the left side of the menu screen. 2-1-1 System Time Connecting to a Simple Network Time Protocol (SNTP) server allows the Broadband Router to synchronize the system clock global through the SNTP Server.
  • Page 30 To manage the Broadband Router from a remote location (outside of the local network through WAN port), it must specify the IP address of the remote PC, otherwise, leave the IP address 0.0.0.0, means all legal IP address can access the device.
  • Page 31 2-1-4 Configuration Tools Use the "Backup Settings" tool to save the Broadband Router's current configuration to a file named "config.bin" on your PC. You can then use the "Restore Settings" tool to restore the saved configuration of the Broadband Router that you set before.
  • Page 32 2-1-6 System Log View any attempts that have been made to gain access to the network. 2-1-7 Reset In the event that the Broadband Router stops responding correctly or in some way stops functioning, perform the reset function. The settings will not be changed. To perform the reset, click on the "Reset"...
  • Page 33 2-2 WAN The Broadband Router can be connected to the service provider in any of the following ways: Dynamic IP Address, Static IP Address, PPPoE and PPTP. 2-2-1 Dynamic IP The Host Name is optional, but may be required by some Service Providers.
  • Page 34 2-2-2 Static IP If the Service Provider has assigned a fixed IP address, enter the assigned IP address subnet mask and gateway address provided. Click “yes” if using two or more IP addresses. 2-2-3 Dial-up xDSL (PPPoE) If connected to the Internet using a Dial-up xDSL (PPPoE) Modem, the ISP will provide a Password and User Name, and then the ISP uses PPPoE.
  • Page 35 2-2-4 PPTP If connected to the Internet using (PPTP) xDSL Modem, enter the PPTP Account Name, PPTP Password, Host Name, Service IP Address, Your IP Address, Your Subnet Mask required by your ISP in the appropriate fields. If your ISP has provided you with a Connection ID, enter it in the Connection ID field, otherwise, leave it zero.
  • Page 36 2-2-5 DNS The Domain Name System (DNS) is the way that Internet domain names are located and translated into Internet Protocol (IP) addresses. If your ISP provided at least one DNS Server IP Address, type that IP Address in the Primary DNS address fields. You can type up to another DNS Server IP Addresses.
  • Page 37 address. Enter the amount of time, in hours, days or weeks, which the user will be “leased” this dynamic IP address. You can enter your local domain name in the Local Domain Name fields. 2-3-2 DHCP Client List The DHCP client list allows you to see which clients are connected to the Barricade via IP address, host name, and MAC address.
  • Page 38 TCP (Transmission Control Protocol) - A method (protocol) used along with the Internet Protocol (Internet Protocol) to send data in the form of message units between computers over the Internet. While IP takes care of handling the actual delivery of the data, TCP takes care of keeping track of the individual units of data (called packets) that a message is divided into for efficient routing through the Internet.
  • Page 39 Example: Trigger Port 28800 28800 6112 2-4-2 Virtual Server Configure the Broadband Router as a virtual server to allow the Router to watch outgoing data for specific port numbers. The IP address of the computer that sends the matching data is remembered by the Router, so that when the requested data returns through the Router, the data is pulled back to the proper computer by way of IP address and port mapping rules such as...
  • Page 40 Example: Server IP 192.168.2.20 192.168.2.12 192.168.2.12 192.168.2.28 2-5 Firewall The Broadband Router provides extensive firewall protection by restricting connection parameters to limit the risk of hacker attack, and defending against a wide array of common hacker attacks. The Broadband Router provides packet filtering rules by restricting service ports, IP address or MAC address.
  • Page 41 common method used by hackers to test whether the WAN IP address is valid and supports a network. 2-5-2 Client Filtering To block a certain client PCs accessing the Internet based on time. You can filter Internet access for local clients based on IP addresses, application types, (i.e., HTTP port), and time of day.
  • Page 42 2-5-4 DMZ (Demilitarized Zone) If a local client PC cannot run an Internet application properly from behind the NAT firewall, open the client up to unrestricted two-way Internet access by defining a virtual DMZ Host.

  • Page 43: Technical Specifications

    TECHNICAL SPECIFICATIONS Standards IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet ANSI/IEEE 802.3 Auto-negotiation Protocol CSMA/CD Data Transfer Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex) Rate Fast Ethernet: 100Mbps (half duplex), 200Mbps (full- duplex) Topology Star Network 10BASET: 2-pair UTP Cat. 3,4,5 (100 m), EIA/TIA- 568 100-ohm Cables 100BASE-TX: 2-pair UTP Cat.
