Block Diagram

PCIe CLK
(100 MHz)
PCIe CLK (100 MHz)
PCI Express x1
PCI Bus
2 PCI
PCI CLK
(33 MHz)
(Note) Use of a 1066/800 MHz FSB CPU is required if you wish to install DDR2 667 MHz memory.
D-Sub
PCI Express x16
PCI Express Bus
x 1
RTL8201
RJ45
LAN
LGA775
Processor
Host
Interface
VIA
P4M900
VIA
VT8237S
CODEC
- 8 -
CPU CLK+/-(266/200/133 MHz)
DDR2 667/533/400 MHz DIMM
DDR2
2 SATA 3Gb/s
8 USB Ports
PS/2 KB/Mouse
ATA-133/100/66/33
IDE Channel
BIOS
Winbond
W83627
(Note)
Floppy
LPT Port
COM Ports
