Summary of Contents for PheeNet WLn-201
- Page 1 802.11n PCI Card Quick Installation Guide WLn-201...
- Page 2 Package Contents................Page 1 Network Card Installation............Page 2 Connect to Wireless Access Point..........Page 4 Package Contents Before you starting to use this wireless network card, please check if there’s anything missing in the package, and contact your dealer of purchase to claim for missing items: PCI Wireless Network Card.………………………………………….…………...
- Page 3 Network Card Installation Please follow the following instructions to install your new PCI wireless network card: 1. Turn off your computer, and remove the case as required so you can see PCI expansion slots (PCI slots are usually colored as white), and then insert the PCI wireless network card into any available the PCI slot.
- Page 4 4. Insert device driver CDOM into the CD/DVD ROM drive of your computer, and execute ‘Setup.exe’ program in ‘Driver’ folder. Please select ‘Allow’ if Windows indicates that ‘an unidentified program wants access to your computer’. 6. Please read the end user license agreement and click ‘Yes’...
- Page 5 7. When you see this message, please click ‘Finish’ to complete the driver installation process.
- Page 6 Connect to Wireless Access Point Using Configuration Utility to Connect to Wireless Access Point 1. After installation is complete, wireless configuration utility will be shown as an icon at the lower-right corner of your windows desktop. Please click the icon by right mouse key, and select ‘Launch Config Utilities’.
- Page 7 4. If the wireless access point uses encryption, you have to input WEP passphrase or WPA preshared key. Please ask the owner of the wireless access point you want to connect, and input the correct passphrase / preshared key here, then click ‘OK’.
