  • Page 1 INSTRUCTION MANUAL Model GCE 5007DVD In Car DVD Player with Monitors 023286...
  • Page 2 Features Compatible with PAL DVD and NTSC This player can play discs recorded in either PAL or NTSC format. • L/R stereo analog audio outputs. Use This Product Safely Use the Proper Power Supply This product is designed to operate with a 12 volt DC, negative ground battery system (normal in an English car).

  • Page 3: Table Of Contents

    CONTENTS Safety Information...................4 Disc Notes......................5 Installation .......................6 The Player ......................10 Cables Supplied ....................13 Electrical Connection ...................15 Remote Control .....................17 Location and Function of Keys..............17 Preparing the Remote Control..............19 Loading/Ejecting a disc ................19 Loading a disc ...................19 Ejecting a disc ....................19 Operation .......................20 Basic Play ....................20 On-Screen Display ..................21...

  • Page 4: Safety Information

    SAFETY INFORMATION CAUTION: Macrovision Corporation, and is THIS PORTABLE DVD PLAYER IS A intended for home and other limited CLASS I LASER PRODUCT. viewing uses only unless otherwise HOWEVER THIS MOBILE DVD authorized by Macrovision PLAYER USES A VISIBLE/INVISIBLE Corporation. Reverse engineering or LASER BEAM WHICH COULD CAUSE disassembly is prohibited.

  • Page 5: Disc Notes

    DISC NOTES Disc formats supported by this player Label side up 12 cm disc (Single-sided disc only) Do not touch the underside 12 cm disc of the disc Discs which cannot be played with this player Do not bend • DVD-ROM •...

  • Page 6: Installation

    INSTALLATION A base stand is supplied with this unit. Use the supplied screws to attach the base to the unit. P. 6...
  • Page 7 INSTALLATION Separated The bag contains three separated parts which can be combined together . PART A (MONITOR 1) PART B (MONITOR 2) PART C (DVD PLAYER) Fig A Combined When combined, the whole bag can be used as a carrying case. PART A (MONITOR 1) PART B...
  • Page 8 INSTALLATION There are two straps on the rear of the monitor. Pass the straps through the monitor bag (fig C), then attach to the headrest (fig D). Strap Strap Monitor Fig C Fig D P. 8...
  • Page 9 INSTALLATION Insert the DVD player into part C of the bag as shown in fig. E. Fig E Attach the cables between the DVD player and monitors (see pages 13-16). P. 9...

  • Page 10: The Player

    THE PLAYER FRONT VIEW 1. AUDIO 18. COVER OPEN 2. SETUP 19. Disc Slot 3. MODE 20. Earphone socket 4. PREV( 21. VIDEO INPUT 1 socket 5. STOP ( 22. AUDIO L INPUT 1 socket 6. PLAY/PAUSE( 23. AUDIO R INPUT 1 socket 7.
  • Page 11 LOCATION AND FUNCTION OF KEYS 1. 16:9/4:3 selector Earphone socket 7. Power Indicator Light 10. BRIGHTNESS control Knob 2. Colour Contorl Knob Earphone volume control 8. IR (Remote Sensor) 11. Volume control for speakers 3. CONTRAST Control Knob REMOTE Socket 9.
  • Page 12 1. 16:9/4:3 SELECTOR SOCKETS FOR EARPHONE Slide the 4:3/16:9 switch (1) on the side of the monitor to select appropriate There are two sockets (1) for earphones. Earphones can be connected to TV aspect ratio (16:9 or 4:3). either one of these sockets. 2.

  • Page 13: Cables Supplied

    CABLES SUPPLIED Before connecting the cables please identify each cable using the guide below. Please see next page for connections. Audio/Video(AV) Cable YELLOW VIDEO For monitor 1 YELLOW (VIDEO 1) AUDIO R WHITE BLACK (AUDIO) AUDIO L 3.5 mm plugs RCA plugs connect to AV YELLOW...
  • Page 14 CABLES SUPPLIED AC Adaptor Cable Connect to Figure of eight plug Connect to DC 12V in socket household insert into figure of eight socket on DVD player mains supply on transformer Transformer Cigarette Lighter Adaptor Insert into Connect to DC 12V cigarette lighter in socket socket in car...

  • Page 15: Electrical Connection

    ELECTRICAL CONNECTION Scart Adaptor Cable Scart Adaptor Cable Scart (TV) YELLOW BLACK Scart (TV) YELLOW YELLOW BLACK YELLOW REMOTE AC Adaptor Cable AC/DC ADAPTOR AC Adaptor Cable AC/DC ADAPTOR CIGARETTE LIGHTER Cigarette Lighter Adaptor CIGARETTE LIGHTER BLACK Cigarette Lighter Adaptor connect to monitor Monitor 1 Power BLACK...
  • Page 16 ELECTRICAL CONNECTION Connect power cable to monitor. (3) YELLOW to 12V output on DVD player (4) WHITE PVC CABLE (BLACK) (5) RED (7) RED (6) BLACK (8) BLACK P. 16...

  • Page 17: Remote Control

    REMOTE CONTROL LOCATION AND FUNCTION OF KEYS P. 17...
  • Page 18 REMOTE CONTROL 1. SETUP Display the SETUP menu. 2. SUBTITLE Change SUBTITLE language on multi-subtitle language DVD disc. POWER Press POWER to turn the unit ON or OFF. 4. MUTE Press to mute the sound. 5. MODE Change between DVD mode, AV1 input mode and AV2 input mode.

  • Page 19: Preparing The Remote Control

    REMOTE CONTROL LOADING / EJECTING A DISC LOADING A DISC Preparing the Remote Control 1. When using in-car, turn the ignition to the ON position. When using Inserting the Batteries mains power, insert plug into 1. Open the battery compartment mains outlet.

  • Page 20: Operation

    OPERATION BASIC PLAY MUTE Press to mute the sound, but the disc STOP PLAYBACK continues playing. When you unmute - Briefly press the (STOP) button the sound (press MUTE again), to stop playback, when the sound will resume. (PLAY) button is pressed, playback REPEAT will resume from the point stopped.

  • Page 21: On-Screen Display

    OPERATION Disc Search (GOTO) among DVD, AV1 and AV2 mode. The corresponding indicator will illuminate FOR DVD on the front panel. Press GOTO button twice, the screen wil display the following: Volume Level Adjustment Press on the front panel or TITLE 01/01 TIME --:--:-- VOLUME +/- on the remote control 00:00:25...

  • Page 22: Multi-Audio Language

    OPERATION - The number of language is dependent CHAPTER REMAIN on the disc. - Some discs may contain one 00:01:39 language soundtrack. - When no alternative language soundtracks are recorded, will be (5) Press DISPLAY a fifth time: displayed at top left corner of the screen The ON SCREEN DISPLAY will be removed.

  • Page 23: Setup

    SETUP SETUP MANU --- MAIN PAGE GENERAL SETUP -- GENERAL SETUP -- GENERAL SETUP TV DISPLAY NORMAL/PS SPEAKER SETUP PIC MODE NORMAL/LB AUDIO SETUP ANGLE MARK WIDE PREFERENCES OSD LANG CAPTIONS SCR SAVER EXIT SETUP 1. Press SETUP on the remote control or on the front panel in the stop mode.
  • Page 24 SETUP --- GENERAL SETUP --- --- GENERAL SETUP --- TV DISPLAY TV DISPLAY PIC MODE AUTO PIC MODE ANGLE MARK HI-RES ANGLE MARK OSD LANG N-FLICKER OSD LANG ENGLISH CAPTIONS CAPTIONS FRENCH SCR SAVER SCR SAVER GERMAN SPANISH MAIN PAGE MAIN PAGE PIC MODE (DEFAULT: AUTO) OSD LANG (DEFAULT: ENGLISH)

  • Page 25: Speaker Setup

    SETUP --- GENERAL SETUP --- AUDIO SETUP --- AUDIO SETUP --- TV DISPLAY AUDIO OUT ANALOG PIC MODE OP MODE SPDIF/RAW ANGLE MARK DYNAMIC SPDIF/PCM OSD LANG LPCM OUTPUT CAPTIONS SCR SAVER MAIN PAGE MAIN PAGE SCR SAVER (DEFAULT: ON) AUDIO OUT (DEFAULT: This player has a screen saver which, SPDIF/RAW)

  • Page 26: Preferences Setup

    SETUP --- AUDIO SETUP --- PREFERENCES SETUP --- PREFERENCES SETUP --- AUDIO OUT TV TYPE AUTO FULL OP MODE AUDIO NTSC DYNAMIC SUBTITLE LPCM OUTPUT DISC MENU PARENTAL PASSWORD DEFAULTS SMART NAV MAIN PAGE MAIN PAGE Dynamic Range Control (DEFAULT: OFF) TV TYPE (DEFAULT: AUTO) Dynamic Range Control is used to...
  • Page 27 SETUP -- PREFERENCES SETUP -- -- PREFERENCES SETUP -- TV TYPE TV TYPE AUDIO ENGLISH AUDIO SUBTITLE 3 PG SUBTITLE FRENCH DISC MENU SPANISH DISC MENU 4 PG 13 PARENTAL CHINESE PARENTAL PASSWORD JAPANESE PASSWORD 6 PG-R DEFAULTS GERMAN DEFAULTS 7 NC-17 SMART NAV SMART NAV...

  • Page 28: Defaults Table

    SETUP DEFAULTS TABLE -- PREFERENCES SETUP -- General Setup TV Display Normal/LB TV TYPE PIC Mode AUTO AUDIO Angle Mark SUBTITLE OSD Language English DISC MENU Captions PARENTAL SCR Saver PASSWORD Speaker Setup Downmix Stereo DEFAULTS RESET Audio Setup Audio Out SPDIF/RAW OP Mode Line Out...

  • Page 29: Trouble Shooting

    TROUBLE SHOOTING Please use this TROUBLE SHOOTING NO SOUND guide if the player appears to be faulty. • Check audio connections. • If using a HIFI amplifier, try another Under no circumstances should you sound source. try to repair the player yourself, as this will invalidate the warranty.
  • Page 30 TROUBLE SHOOTING - MONITOR Before going through the checklist, check wiring connection. If any of the NO POWER • Press the power button on the front of the monitor to turn the monitor on. • Check if the wires of DC power plug are properly connected. •...

  • Page 31: Specifications

    SPECIFICATIONS Supply voltage : 12V DC (11V-15V), test voltage 14.4V, negative ground Current consumption : Less than 2A : Compositive video 1.0Vp-p 75 Ω Signal system Discs played : (1) DVD-VIDEO disc 5”(12 cm) single-sided, single-layer 5”(12 cm) single-sided, double-layer (2) Compact disc (CD-DA/CD-R/CD-RW) Audio output level : 10kΩ...
  • Page 32 88-V2480-08...
