Gigabyte GA-6VX7B-4X User Manual
Gigabyte GA-6VX7B-4X User Manual

Gigabyte GA-6VX7B-4X User Manual

Socket 370 processor motherboard

Advertisement

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
Model Number:
GA-6VX7B-4X
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
Sep. 13, 2000
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection
against
residential
installations.
generates,
uses,
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
harmful
interference
This
equipment
and
can
radiate
in
radio

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GA-6VX7B-4X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gigabyte GA-6VX7B-4X

  • Page 1 Phone/Fax No: (818) 854-9338/ (818) 854-9339 hereby declares that the product Product Name: Mother Board Model Number: GA-6VX7B-4X Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), Class B Digital Device Supplementary Information: This device complies with part 15 of the FCC Rules. Operation is subject to the...
  • Page 2: Declaration Of Conformity

    Safety of household and similar electrical appliances (Stamp) Declaration of Conformity We, Manufacturer/Importer (full address) G.B.T. Technology Träding GMbH declare that the product Mother Board GA-6VX7B-4X is in conformity with EN 61000-3-2* EN60555-2 EN61000-3-3* EN60555-3 EN 50081-1 EN 50082-1 EN 55081-2...
  • Page 3 6VX7B-4X Socket 370 Processor Motherboard USER'S MANUAL Socket 370 Processor Motherboard REV. 3.2 Second Edition R-32-02-010627 12ME-6VX7B4X-3202...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: 1) Revision History 2) Item Checklist 3) Features 4) Hardware Setup 5) Performance & Block Diagram 6) Suspend to RAM 7) BIOS Setup 8) Appendix Manual revision information Product item list Product information &...
  • Page 7: Table Of Contents

    Revision History Item Checklist Summary of Features 6VX7B-4X Motherboard Layout Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition Performance List Block Diagram Suspend to RAM Installation Memory Installation Page Index for BIOS Setup Appendix Table Of Content P.34 P.35 P.36 P.42 P.43...
  • Page 8: Revision History

    6VX7B-4X Motherboard Revision History Revision Revision Note Initial release of the 6VX7B-4X motherboard user’s manual. Second release of the 6VX7B-4X motherboard user’s manual. The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein. Third-party brands and names are the property of their respective owners.
  • Page 9: Item Checklist

    Item Checklist Item Checklist The 6VX7B-4X motherboard Cable for IDE / floppy device Diskettes or CD (TUCD) for motherboard driver & utility 6VX7B-4X user’s manual...
  • Page 10: Summary Of Features

    6VX7B-4X Motherboard Summary Of Features Form Factor Chipset Clock Generator Memory I/O Control Slots On-Board IDE up to 4 ATAPI devices On-Board Peripherals 30.4 cm x 20.3 cm ATX Size form factor, 4 layers PCB. Socket 370 processor Intel Pentium !!! 100/133MHz FSB, FC-PGA Intel Celeron 66MHz FSB, FC-PGA VIA Cyrix III 100/133MHz FSB, PPGA...
  • Page 11 Hardware Monitor PS/2 Connector BIOS On-Board Sound Additional Features CPU / System fan revolution detect CPU / System temperature detect System voltage detect CPU overheat shutdown detect PS/2 keyboard interface and PS/2 mouse interface Licensed AMI BIOS, 2M bit flash ROM Build –in VIA sound (VIA VT82C686B) Creative CT5880 sound (Optional) Supports Wake-on-LAN (WOL)
  • Page 12: 6Vx7B-4X Motherboard Layout

    6VX7B-4X Motherboard 6VX7B-4X Motherboard Layout PS/2 JP16 USB1 PGA 370 JP18 PCI1 PCI2 Creative CT5880 PCI3 PCI4 JP20 PCI5 JP19 VT82C694X 6VX7B-4X VT82C686B JP30 LED1 JP15 BAT1 JP23 USB2 BIOS JP22 JP24...
  • Page 13: Page Index For Cpu Speed Setup/Connectors/Panel And Jumper Definition

    Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors Game & Audio Port COM A / COM B / LPT Port USB1 Connector PS/2 Keyboard & PS/2 Mouse Connector JP16 (CPU Fan) JP15 (Power Fan) JP2 (System Fan) ATX Power USB 2 Connector IR Connector...
  • Page 14: Cpu Speed Setup

    6VX7B-4X Motherboard CPU Speed Setup The system bus speed is selectable at 66,100,133MHz and Auto. The user can select the system bus speed (SW1) and change the DIP switch (SW2) selection to set up the CPU speed for 500MHz – 1GHz processor. SW1: O: ON, X: OFF PCI CLK...
  • Page 15 For Auto Jumper setting: Note: 1. If you use 66, 100, 133 MHz CPU, we recommend you to set up your system speed to “Auto” value. 2. We don’t recommend you to set up your system speed to 75,83,112, 124, 140,150 MHz because these frequencies are not the standard specifications for CPU, Chipset and most of the peripherals.
  • Page 16 6VX7B-4X Motherboard Celeron 566 / 66 MHz FSB Celeron 600 / 66 MHz FSB Celeron 633 / 66 MHz FSB...
  • Page 17 Celeron 667 / 66 MHz FSB Celeron 700 / 66 MHz FSB Cyrix III 550 / 100 MHz FSB (Optional) ® CPU Speed Setup...
  • Page 18 6VX7B-4X Motherboard Cyrix III 533 / 133 MHz FSB (Optional) ® Cyrix III 600 / 133 MHz FSB (Optional) ® !!! 500 / 100MHz FSB 10. Pentium ®...
  • Page 19 !!! 550 / 100MHz FSB 11. Pentium ® !!! 600 / 100MHz FSB 12. Pentium ® !!! 650 / 100MHz FSB 13. Pentium ® CPU Speed Setup...
  • Page 20 6VX7B-4X Motherboard !!! 700 / 100MHz FSB 14. Pentium ® ® !!! 750 / 100MHz FSB 15. Pentium ® !!! 800 / 100MHz FSB 16. Pentium...
  • Page 21 ® !!! 850 / 100MHz FSB 17. Pentium ® !!! 533 / 133MHz FSB 18. Pentium ® !!! 600 / 133MHz FSB 19. Pentium CPU Speed Setup...
  • Page 22 6VX7B-4X Motherboard ® !!! 667 / 133MHz FSB 20. Pentium ® !!! 733 / 133MHz FSB 21. Pentium ® !!! 800 / 133MHz FSB 22. Pentium...
  • Page 23 ® !!! 866 / 133MHz FSB 23. Pentium ® !!! 933 / 133MHz FSB 24. Pentium ® !!! 1GHz / 133MHz FSB 25. Pentium CPU Speed Setup...
  • Page 24: Connectors

    6VX7B-4X Motherboard Connectors Game & Audio Port Game Port MIC In Line Out Line In COM A / COM B / LPT Port LPT Port COM A COM B...
  • Page 25: Usb1 Connector

    USB 1 Connector PS/2 Keyboard & PS/2 Mouse Connector Pin No. Definition USB V0 USB D0- USB D0+ USB V1 USB D1- USB D1+ 5 6 7 8 PS/2 Mouse PS/2 Keyboard PS/2 Mouse/ Keyboard Pin No. Definition Data VCC(+5V) Clock Connectors...
  • Page 26: Jp16: Cpu Fan

    6VX7B-4X Motherboard JP16: CPU Fan JP15: Power Fan Pin No. Definition +12V SENSE Pin No. Definition +12V...
  • Page 27: Jp2: System Fan

    JP2: System Fan ATX Power Pin No. Definition +12V SENSE Pin No. 3,5,7,13,15-17 1,2,11 4,6,19,20 5V SB stand by+5V PS-ON(Soft On/Off) Connectors Definition 3.3V +12V -12V Power Good...
  • Page 28: Usb 2 Connector

    6VX7B-4X Motherboard USB 2 Connector IR Connector Pin No. PIN No. Definition VCC(+5V) IR data input IR data output Definition USB D0- USB D0+ USB D1- USB D1+...
  • Page 29: Floppy Port

    Connectors Floppy Port Red Line IDE1 (Primary), IDE2(Secondary) Port Red Line IDE 1 IDE 2...
  • Page 30: J3 (Ring Power On)

    6VX7B-4X Motherboard J3: Ring Power On (Internal Modem Card Wake Up) J1: Wake On LAN Pin No. Definition Signal Pin No. Definition +5V SB Signal...
  • Page 31: J7 (Tel)

    J7: TEL: The connector is for Modem with internal voice connector J5: AUX_IN Pin No. Definition Signal-In Signal-Out Pin No. Definition AUX-L AUX-R Connectors...
  • Page 32: J8: Cd Audio Line In

    6VX7B-4X Motherboard J8: CD Audio Line In JP5: STR LED Connector & LED1: DIMM LED Pin No. Definition CD-L CD-R STR LED Connector External DIMM LED...
  • Page 33: Front Usb Port (Optional)

    Front USB Port (Optional) J11: SM BUS Pin No. Definition 1,4,5,10 3,7,9 USBP0+ USBP0- Pin No. Definition SMB CLK SMB DATA Connectors...
  • Page 34: Panel And Jumper Definition

    6VX7B-4X Motherboard Panel And Jumper Definition J2: For 2x11 Pins Jumper GN (Green Switch) GD (Green LED) HD (IDE Hard Disk Active LED) SPKR (Speaker Connector) RE (Reset Switch) P+P P (Power LED) PW (Soft Power Connector) Open: Normal Operation Close: Entering Green Mode Pin 1: LED anode(+) Pin 2: LED cathode( )
  • Page 35: Jp1: Clear Cmos Function

    JP1: Clear CMOS Function JP7/JP8/JP18: Onboard AC97 & AMR (Primary or Secondary) Select (AMR Audio Modem Riser) Panel and Jumper Definition Pin No. Definition 1-2 close Normal (Default) 2-3 close Clear CMOS JP18 Jumper Function Only AC97 Close Close Only AMR (Primary) Close Close...
  • Page 36: Jp11: Str Enable

    6VX7B-4X Motherboard JP11: STR Enable JP20: Onboard Sound Function Selection (Optional) Pin No. Definition Open STR Disabled (Default) Close STR Enabled Pin No. Definition Enabled Onboard Sound 1-2 close (Default) 2-3 close Disabled Onboard Sound...
  • Page 37: Jp24 (Normal/Recovery) [Optional]

    Panel and Jumper Definition JP24: Normal/ Recovery mode (Optional) Pin No. Definition Open Normal Close Recovery JP19: Cyrix CPU Turbo Function (Optional) Pin No. Definition Open Normal Close Turbo...
  • Page 38: Jp9: Usb Device Wake Up Selection

    6VX7B-4X Motherboard JP9: USB Device Wake up Selection (If you want to use “ USB KB Wakeup from S3~S5 ” function, you have to set the BIOS setting “USB KB Wakeup from S3~S5” enabled, and the jumper “ JP9 ” enabled). *(Power on the computer and as soon as memory counting starts, press <Del>.
  • Page 39: Jp30 (Over Voltage Cpu Speed Up) [Optional]

    JP22: BIOS Flash ROM Write Protect JP30: Over Voltage CPU Speed Up (Magic Booster) (Optional) (When JP30 set “7-8 Close”, CPU Voltage is rising 10%) Panel and Jumper Definition Pin No. Definition Close BIOS Write Disabled BIOS Write Enabled Open (Default) Please set Jumper JP22 to “Open”...
  • Page 40: J12: Front Panel Jumper (Optional)

    6VX7B-4X Motherboard J12: Front Panel Jumper (Optional) BAT1: Battery Pin No. PWR LED+ RESET SW Soft ON/OFF 10,12 Green SW Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.
  • Page 41: Performance List

    Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Intel ®...
  • Page 42: Block Diagram

    6VX7B-4X Motherboard Block Diagram AGP 2X/4X AGP Bus VT82C694X Ultra DMA 33/ATA66 IDE Ports PCI Bus ISA Bus IDE Bus AC’97-Link Creative CT5880 AC97 CODEC Slot PGA 370 CPU Host Bus ICS 9248DF-39 33 MHz 33 MHz 24MHz 48MHz 14.318MHz VT82C686B COM Ports Floppy...
  • Page 43: Suspend To Ram Installation

    Suspend To RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 44 6VX7B-4X Motherboard Step 2: (If you want to use STR Function, please set jumper JP11 Closed.) Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup. Select the item “POWER MANAGEMENT SETUP”, then select “ Type : S3 / STR”...
  • Page 45 Suspend to RAM Installation A.3 How to put your system into STR mode? There are two ways to accomplish this: Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” B.
  • Page 46 6VX7B-4X Motherboard Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 47 C. Select the “Advanced” tab and “Standby” mode in Power Buttons. Step 4: Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button.. A.4 How to recover from the STR sleep mode? There are five ways to “wake up”...
  • Page 48 6VX7B-4X Motherboard A.5 Notices: In order for STR to function properly, several hardware and software requirements must be satisfied: Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). Your SDRAM must be PC-100 compliant. Jumper JP5 is provided to connect to the STR LED in your system chassis.
  • Page 49: Memory Installation

    Memory Installation The motherboard has 3 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 50: Page Index For Bios Setup

    6VX7B-4X Motherboard Page Index for BIOS Setup The Main Menu Standard CMOS Setup BIOS Features Setup Chipset Features Setup Power Management Setup PNP/ PCI Configuration Load BIOS Defaults Load Setup Defaults Integrated Peripherals Hardware Monitor Setup Supervisor Password / User Password IDE HDD Auto Detection Save &...
  • Page 51: Entering Setup

    BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Power ON the computer and press <Del>...
  • Page 52: Getting Help

    6VX7B-4X Motherboard GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 53 Chipset Features Setup This setup page includes all the items of chipset special features. Power Management Setup This setup page includes all the items of Green function features. PnP/PCI Configurations This setup page includes all the configurations of PCI & PnP ISA resources. Load BIOS Defaults Bios Defaults indicates the value of the system parameter which the system would be in the safe configuration.
  • Page 54: Standard Cmos Setup

    6VX7B-4X Motherboard Standard CMOS Setup The items in Standard CMOS Features Menu (Figure 2) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. AMIBIOS SETUP –...
  • Page 55 Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 56: Extended Memory

    6VX7B-4X Motherboard Boot Sector Virus Protection If it is set to enable, the category will flash on the screen when there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the following error message will appear in the mean time.
  • Page 57: Bios Features Setup

    BIOS Features Setup AMIBIOS SETUP – BIOS FEATURES CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved 1st Boot Device :Floppy 2nd Boot Device 3rd Boot Device :CDROM S.M.A.R.T for Hard Disks :Disabled BootUp Num-Lock Floppy Drive Seek Password Check :Setup Process Serial Number...
  • Page 58: Password Check

    6VX7B-4X Motherboard Boot Up Num-Lock Keypad is number keys. (Default Value) Keypad is arrow keys. Floppy Drive Seek During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360 type is 40 tracks while 720 , 1.2 and 1.44 are all 80 tracks. Enabled BIOS searches for floppy disk drive to determine if it is 40 or 80 tracks.
  • Page 59: Chipset Features Setup

    Chipset Features Setup AMIBIOS SETUP –CHIPSET FEATURE CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved *** DRAM Timing *** Top Performance SDRAM Timing by SPD SDRAM CAS# Latency DRAM Frequency C2P Concurrency & Master DRAM Integrity Mode AGP Mode AGP Comp.
  • Page 60 6VX7B-4X Motherboard C2P Concurrency & Master Enabled C2P Concurrency & Master. (Default Value) Enabled Disabled Disabled C2P Concurrency & Master. DRAM Integrity Mode For 72 bit ECC type DIMM Modle. Normal Setting. (Default Value) Disabled AGP Mode Set AGP Mode is 4X. (Default Value) Set AGP Mode is 1X.
  • Page 61: Usb Controller

    USB Controller USB Port 0&1 USB Controller for USB Port 0&1. USB Port 2&3 USB Controller for USB Port 2&3. USB Controller for All USB Port. (Default Value) All USB Port Disabled USB Controller Function Disabled. USB Legacy Support Keyboard Set USB Legacy Support Keyboard.
  • Page 62 6VX7B-4X Motherboard Power Management Setup AMIBIOS SETUP –POWER MANAGEMENT SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Sleep Type USB KB Wakeup From S3~S5 Video Power Down Mode Hard Disk Power Down Mode Suspend Time Out(Minute) Display Activity IRQ3 IRQ 4...
  • Page 63 Suspend Time Out (Minute.) Disabled Suspend Time Out Function. (Default Value) Disabled Enabled Suspend Time Out after 1min. Enabled Suspend Time Out after 2min. Enabled Suspend Time Out after 4min. Enabled Suspend Time Out after 8min. Enabled Suspend Time Out after 10min. Enabled Suspend Time Out after 20min.
  • Page 64 6VX7B-4X Motherboard MODEM Use IRQ Set MODEM Use IRQ to NA. Set MODEM Use IRQ to 3. Set MODEM Use IRQ to 4. (Default Value) Set MODEM Use IRQ to 5. Set MODEM Use IRQ to 7. Modem Ring On/Wake On Lan Disabled Disabled Modem Ring On/Wake On Lan.
  • Page 65: Reset Configuration Data

    PnP/PCI Configurations AMIBIOS SETUP –PNP/PCI CONFIGURATION SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Plug and Play Aware O/S Reset Configuration Data VGA Boot From PCI VGA Palette Snoop DMA Channel 0 DMA Channel 1 DMA Channel 3 DMA Channel 5 DMA Channel 6 DMA Channel 7...
  • Page 66 6VX7B-4X Motherboard DMA Channel (0,1,3,5,6,7) The resource is used by PnP device. ISA / EISA The resource is used by ISA / EISA device (PCI or ISA). IRQ (3,4,5,7, 9,10,11,14,15) PCI/PnP The resource is used by PCI/PnP device. ISA / EISA The resource is used by ISA / EISA device (PCI or ISA).
  • Page 67: Power Management Setup

    Load BIOS Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP Load BIOS Defaults (Y/N)? N PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item...
  • Page 68: Load Setup Defaults

    6VX7B-4X Motherboard Load Setup Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP Load SETUP Defaults (Y/N)? N PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item...
  • Page 69: Integrated Peripherals

    Integrated Peripherals AMIBIOS SETUP –INTEGRATED PERIPHERAL ( C ) 1999 American Megatrends, Inc. All Rights Reserved OnBoard IDE OnBoard FDC OnBoard Serial Port 1 OnBoard Serial Port 2 Serial Port 2 Mode Duplex Mode OnBoard Parallel Port Parallel Port Mode Parallel Port DMA Parallel Port IRQ OnBoard AC’97 Audio...
  • Page 70 6VX7B-4X Motherboard OnBoard Serial Port 2 BIOS will automatically setup the port 2 address. (Default Value) Auto 3F8/COM1 Enable onBoard Serial port 2 and address is 3F8. 2F8/COM2 Enable onBoard Serial port 2 and address is 2F8. 3E8/COM3 Enable onBoard Serial port 2 and address is 3E8. 2E8/COM4 Enable onBoard Serial port 2 and address is 2E8.
  • Page 71 Parallel Port IRQ Set Parallel Port IRQ is 7. Set Auto to parallel Port IRQ DMA Channel. (Default Value) Auto Set Parallel Port IRQ is 5. OnBoard AC’97 Audio Set OnBoard AC’97 Audio to Auto. (Default Value) Auto Disabled Disabled OnBoard AC’97 Audio. OnBoard MC’97 Modem Set OnBoard MC’97 Modem to Auto.
  • Page 72 6VX7B-4X Motherboard MUP-401 I/O Address Set MUP-401 I/O Address is 330h-333h. (Default Value) 330h-333h 300h-303h Set MUP-401 I/O Address is 300h-303h. 310h-313h Set MUP-401 I/O Address is 310h-313h. 320h-323h Set MUP-401 I/O Address is 320h-323h. FM Port (388h-38Bh) Disabled FM Port (388h-38Bh). (Default Value) Disabled Enabled Enabled FM Port (388h-38Bh).
  • Page 73 Hardware Monitor AMIBIOS SETUP –HARDWARE MONITOR ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Shut Down Temp. Current CPU Temp. Current System Temp. Case Status Current CPU Fan Speed Current System Fan Speed Vcore +3.300V +5.000V +12.000V ACPI Shutdown Temp.
  • Page 74 6VX7B-4X Motherboard Current CPU Temp. ( C / F) Detect CPU Temperature automatically. Current System Temp. ( C / F) Detect System Temperature automatically. Case Status If the case is closed, “Case Status” will show “Closed”. If the case have been opened, “Case Opened” will show “Open”. Current CPU Fan Speed Detect CPU Fan speed status automatically .
  • Page 75: Hardware Monitor Setup

    Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP...
  • Page 76: Ide Hdd Auto Detection

    6VX7B-4X Motherboard IDE HDD AUTO Detection AMIBIOS SETUP – STANDARD CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy) : Tue Feb 17, 2000 Time (hh/mm/ss) : 10:36:24 TYPE SECTOR MODE Pri Master :Auto Pri Slave :Auto Sec Master :Auto...
  • Page 77: Save & Exit Setup

    Save & Exit Setup AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP SAVE to CMOS and EXIT(Y/N)? Y PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item...
  • Page 78: Exit Without Saving

    6VX7B-4X Motherboard Exit Without Saving AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP Quit without saving (Y/N) ? N PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit...
  • Page 79: Appendix

    Appendix Appendix A : VIA Chipsets Driver Installation A.VIA 4 in 1 Service Pack Utility: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “VIA 4in 1 Service Pack Utility”...
  • Page 80 6VX7B-4X Motherboard 7.Click “Next”. 9.Click “Next”. 8.Click “Next”. 10.Click “Finish” to restart computer. (10)
  • Page 81 Appendix B: VIA Sound Driver A. AC’97 Audio Driver: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. Audio 1.Click “AC’97 Audio Driver” item. 3.Click “Next”...
  • Page 82 6VX7B-4X Motherboard Appendix C: Creative Sound Driver Installation (Optional) Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. Audio 1.Click “Creative 5880 Sound Driver”.
  • Page 83 Appendix 7.Click “Finish” to restart computer.
  • Page 84 C:\utility\ AWDFlash or AMIFlash <filename of the BIOS binary file intended for flashing> Once the process is finished, reboot the system Note: Please download the newest BIOS from our website (www.gigabyte.com.tw) or contact your local dealer for the file.
  • Page 85 Appendix E: Acronyms Acro. Meaning ACPI Advanced Configuration and Power Interface POST Power-On Self Test Local Area Network Extended Capabilities Port Advanced Power Management Direct Memory Access Megahertz ESCD Extended System Configuration Data Central Processing Unit Symmetric Multi-Processing Universal Serial Bus Operating System Error Checking and Correcting Integrated Dual Channel Enhanced...
  • Page 86 6VX7B-4X Motherboard Acro. Meaning Peripheral Component Interconnect RIMM Rambus in-line Memory Module Dual Retention Mechanism Industry Standard Architecture Memory Translator Hub CRIMM Continuity RIMM...
