Steel Cargo Carrier, 500-Lb. Capacity
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item # 101459
READ & SAVE THESE INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 101459 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ironton 101459

  • Page 1 Steel Cargo Carrier, 500-Lb. Capacity Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item # 101459 READ & SAVE THESE INSTRUCTIONS...
  • Page 2 Thank you very much for choosing an Ironton product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.

  • Page 3: Table Of Contents

    Table of Contents Intended Use ............................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Main Parts of Product ........................... 6 Assembly Instructions .......................... 6 Operating Instructions .......................... 8 Maintenance ............................8 Parts Diagram ............................9 Parts List ..............................

  • Page 4: Intended Use

    Intended Use The Ironton 500-Lb. Capacity Steel Cargo Carrier fits in a 2 inch receiver and can carry up to a 500-lb. load. The cargo carrier is easy to assemble with heavy-duty, tubular steel construction and rails on all four sides providing maximum stability during travel.
  • Page 5  Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to these chemicals: work in a well-ventilated area, and work with approved safety equipment, such as dust masks that are specially designed to filter out microscopic particles.

  • Page 6: Specific Operation Warnings

     Always check of damaged or worn out parts before using the cargo carrier. Broken parts will affect the cargo carrier operation. Replace or repair damaged or worn parts immediately.  Store idle the cargo carrier. When the cargo carrier is not in use, store it in a secure place out of the reach of children.
  • Page 7 Assembly steps Step 1： Unpack all contents and compare to the parts list. Step 2：  Install four bolts (10) through the left frame (2), tube assembly (1), and right frame (3).  Install the flat nuts onto the bolts ...

  • Page 8: Operating Instructions

    Operating Instructions ⚠WARNING  Follow all federal DOT and any applicable state laws and regulations for installation and use.  Ensure vehicle tail lights are not obstructed by the carrier or the load.  Prior to transporting make the load is properly secured to the carrier. ...

  • Page 9: Parts Diagram

    Parts Diagram Parts List VENDOR: List all of the parts that are shown in the exploded diagram. Reference Part Number Part Description Quantity 2’’ Post Frame (Left) Frame (Right) R Pin 5/8’’ Hitch Pin Cross Brace Bolt - M8x35 Lock Nut - M8 Lock Nut - M10 Bolt - M10x75 Page 9 of 12...

  • Page 10: Replacement Parts

    Replacement Parts  For replacement parts and technical questions, please call Customer Service at 1-800-222-5381.  Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. ...

  • Page 11: Limited Warranty

    Northern Tool and Equipment Company, Inc. ("We'' or ''Us'') warrants to the original purchaser only (''You'' or ''Your'') that the Ironton product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase.
  • Page 12 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in Vietnam Page 12 of 12...
