CT-F2936LP 1 Safety Precautions 1.3. Leakage Current Hot Check (See Fig. 1) 1.1. General Guide 1. Plug the AC cord directly into the AC outlet. Do not use an 1. It is advisable to insert an isolation transformer in the AC isolation transformer for this check.
CT-F2936LP 3 Market Mode Function 3.1. Service Mode Access 1. Set timer ON. 2. Press remote’s RECALL ( ) and panel’s volume down key simultaneously to enter SERVICE 1. 3. Set to normal mode : Press the volume down button on front, together press the off timer button on remote control.
CT-F2936LP 4.3. CONVERGENCE 1. Apply a crosshatch pattern signal and set Contrast control to the maximum position. 2. Adjust Bright control to obtain a clear pattern. 3. Adjust Red and Blue line at center of the screen. 4. Adjust Red and Blue with Green line at center of the screen by rotating (RB)-G static convergence magnet.
CT-F2936LP 4.4. WHITE BALANCE (MARKET MODE CHK 4) Preparation 1. Receive a colour bar signal with colour “OFF”, and operate the TV set for more than 30 minutes. 2. Set the picture menu to “DYNAMIC NORMAL” and the AI to off.
CT-F2936LP 4.5. ADJUSTMENT OF CRT VRS NOTE: FOR FLAT CRT ONLY PREPARATION 1. Set DY to CRT not to tilt up and down left and right deflection. 2. Set CY to CRT and set CY magnet primarily. Pur Mg : Set Pur Mg that 2 magnets are (top position) VRS Mag : Set VRS Mg that 2 magnets are (horizontal position) only 21”, 25”...
CT-F2936LP 8.2. Replacement Parts List Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks A68LZU185X-E PICTURE TUBE C3151 F2A1H2R2A118 E 2.2UF, 50V EASG15S02H2 SPEAKER C355 ECWF2334JSR P 0.33UF, J, 250V EUR7717050 REMOTE CONTROL...
Page 29
CT-F2936LP Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks C662 F2A0J101A317 E 100UF, 6.3V D364 B0AACK000004 DIODE C665 ECJ2VC1H150J C 15PF, J, 50V D365 B0AACK000004 DIODE C666 ECJ2VC1H150J C 15PF, J, 50V...
Page 30
CT-F2936LP Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks L2323 J0JKA0000038 BEAD CORE Q955 B1BCCL000010 TRANSISTOR L2324 J0JKA0000038 BEAD CORE Q956 B1BACL000023 TRANSISTOR L351 J0JKA0000022 BEAD CORE Q957 B1ADCE000012 TRANSISTOR L376 J0JKB0000038...
Page 31
CT-F2936LP Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks R312 D0AE181JA046 C 180OHM,J,1/4W R620 ERJ6ENF1002 M 10KOHM, 1/10W R3140 ERJ6GEY0R00 M 0OHM,J,1/10W R621 ERJ6ENF2002 M 20KOHM, 1/10W R3152 ERJ6GEYJ104 M 100KOHM,J,1/10W R624...
Page 32
CT-F2936LP Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks R893 ERJ6ENF5102 M 51KOHM, 1/10W JS3045 ERJ6GEY0R00 M 0OHM,J,1/10W R894 ERJ6ENF1303 M 130KOHM, 1/10W JS3046 ERJ6GEY0R00 M 0OHM,J,1/10W R918 ERQ1CJP331S F 330OHM,J, 1W...
