3
Insert the tab of the top of the back cover into
the FOMA terminal slot (1), attach it in the
direction of the arrow (2) and securely push
down with both hands (3)
The back of the back cover has also six tabs to
insert the back cover. Securely push tab areas
down with both hands so that gaps are not left
between the FOMA terminal and the back cover.
Back cover
Securely push
tab areas down
with both hands
4
Slide the back cover lever in the direction of the
arrow (4) to lock
Lever
118
その他
Using unnecessary force when attaching or
removing the battery pack may damage the
connector terminal for the battery pack (charger
terminal) on the FOMA terminal.
Securely close the back cover. If not closed
securely, the back cover may come off and the
battery pack may fall out due to vibration. May
damage the waterproof/dust-proof performance
and allow water to seep or dust to get in.
Charging
It is recommended that the accompanying desktop
holder be used for charging to prevent water from
seeping or dust from getting in caused by forgetting
to close the external connector terminal cover.
The AC adapter and desktop holder are not
waterproof/dust-proof. Never try to charge the
battery pack when the FOMA terminal is wet.
1
Turn the arrow side of the AC adapter connector
up and insert it into the connector terminal of the
desktop holder
Keep the connector parallel with the desktop
holder and securely push all the way in until it
clicks.
2
Insert the AC adapter power plug into an outlet
