Summary of Contents for AMobile IOT-500
- Page 1 IOT-500 5" Risc-based IoT Terminal User's Manual Version 1.1...
- Page 2 This page is intentionally left blank. - II -...
- Page 3 Revision History Version Release Time Description 2016.03 Initial release 2017.11 Revision - i -...
- Page 4 We recommend that you keep one copy of this manual for the quick reference for any necessary maintenance in the future. Thank you for choosing AMobile products. - ii -...
-
Page 5: Table Of Contents
Contents Contents Preface......................iv Declaration of Conformity..................iv CE .......................iv FCC Class B ....................iv RoHS ......................v SVHC / REACH ....................v Safety Symbols ....................vi Important Safety Instructions ................vi General Cleaning Tips..................viii Cleaning Tools ................... viii Recommended Cleaning Procedures ............ix Disposing of the Equipment .................x Additional Information &... -
Page 6: Preface
This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from AMobile. Please contact your local supplier for ordering information. -
Page 7: Rohs
SVHC / REACH To minimize the environmental impact and take more responsibility to the earth we live, AMobile hereby confirms all products comply with the restriction of SVHC (Substances of Very High Concern) in (EC) 1907/2006 (REACH --Registration, Evaluation, Authorization, and Restriction of Chemicals) regulated by the European Union. -
Page 8: Safety Symbols
Preface Safety Symbols This symbol of “CAUTION” indicates that there is a danger of injury to the user or a risk of damage to the product, should warning notices be disregarded. This symbol indicates electrical warning. Important Safety Instructions Read these safety instructions carefully: 1. - Page 9 Preface 13. If the equipment will not be used for a long time, disconnect it from the power source to avoid damage by transient overvoltage. 14. Never pour any liquid into openings. This may cause fire or electrical shock. 15. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel.
-
Page 10: General Cleaning Tips
Preface Do not use the power adapter that isn’t made for the equipment. Supplying the equipment with inappropriate voltage may cause harm to or burn the equipment. To prevent possible hearing damage, do not listen at high volume levels for long periods General Cleaning Tips You may need the following precautions before you begin to clean the device. -
Page 11: Recommended Cleaning Procedures
Preface • Cloth: A piece of cloth is the best tool to use when rubbing up a component. Although paper towels or tissues can be used on most hardware as well, we still recommend you to rub it with a piece of cloth. •... -
Page 12: Disposing Of The Equipment
Preface Disposing of the Equipment • Within the European Union EU-wide legislation, as implemented in each Member State, requires that waste electrical and electronic products carrying the mark (left) must be disposed of separately from normal household waste. This includes monitors and electrical accessories, such as signal cables or power cords. -
Page 13: Additional Information & Technical Support
Please do not hesitate to call or e-mail our customer service when you still cannot get the information you need. http://amobile-solutions.com/web_en/contact.php E-mail: support@amobile.com.tw Warranty This product is warranted to be in good working order during the warranty period. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms. - Page 14 This page is intentionally left blank. - xii -...
-
Page 15: Chapter 1 Introduction
Chapter 1 Introduction Chapter 1 Introduction - 1 -... -
Page 16: Product Highlights
Upon opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, contact your local dealer or distributor. The package should contain the following items: IOT-500 5" Risc-based IoT Terminal 2-pin DC Terminal Block, Plug, Green 10-pin Terminal Block, Plug, Green... -
Page 17: Parts Of The Device
Introduction 1.3 Parts of the Device 2.0 megapixel camera 10/100 Mbps RJ-45 LAN port Microphone 10 2 x USB 2.0 ports 5-point projected capacitive touch 11 DB-9 RS-232/422/485 port screen Power/Resset button Integrated 0.8W speaker • Press and hold to power on/off the device. •... -
Page 18: Dimensions
Introduction 1.4 Dimensions 149.33 38.30 139.00 36.80 110.30 9.40 35.8 Unit:mm 50.00 - 4 -... -
Page 19: Specifications
Introduction 1.5 Specifications System Dual-core ARM Cortex-A7 1.0GHz Android™ v5.1 Memory 512MB LPDDR2 Flash 4GB eMMC Peripherals and Devices Front Camera 2.0 megapixel camera Sensor Magnetometer (M-Sensor) 1 x built-in speaker (0.8W) Audio 1 x built-in microphone Wireless WLAN Integrated IEEE 802.11 a/b/g/n/ac Bluetooth Bluetooth 4.1 (BLE, HS compliant) 2G GSM/GPRS/EDGE (Band 850 / 900 / 1800 / 1900) - Page 20 Introduction Power Input 2-pin terminal block DC Input 12V~24V Auto-Detection Mechanical & Environmental Ingress Protection Front bezel IP65 Operating Temp. -10°C ~ 50°C (14°F ~ 122°F ) Storage Temp. -20°C ~ 60°C (-4°F ~ 140°F) Operating Humidity 5% ~ 90% RH Dimensions 149.3 x 110 x 36.8 mm (5.88”...
-
Page 21: Chapter 2 Installation
Installation Chapter 2 Installation Chapter 2 Installation - 7 -... -
Page 22: Sim Card Installation
DC power connection. 2.2 Power Connection 2.2.1 Using the DC Terminal Block Connector The IOT-500 comes with one 2-pin DC terminal block connector to connect power to DC power connector on the device. To use the block connector: 1. -
Page 23: Using The Power Adapter (Optional)
2.2.2 Using the Power Adapter (Optional) If your IOT-500 comes with the optional AC-DC power adapter, just connect the 2-pin terminal block plug of the power adapter to the 2-pin terminal block receptacle on the device. Then connect the adapter to a power source. -
Page 24: Connector Pintouts
Installation 2.4 Connector Pintouts 2.4.1 PWPIN Description: Power Input Connector Connector Type: 2-pin Terminal Block Description Power_GND +12V- 2.4.2 GPIO and CAN Bus Description Digital General Purpose Signal Input/ Output and CAN Connector Type: 4x 3.3V Digital GPIO connector and 1 x CAN 2.0b Bus Pin Description Pin Description IO_GND... -
Page 25: Chapter 3 Using The Device
Using the Device Chapter 3 Using the Device Chapter 3 Using the Device - 11 -... -
Page 26: Power On/Off The Device
Using the Device 3.1 Power On/Off the Device Once the device is connected to a power supply, it will be turned on automatically. Then the device will enter the Android system directly. To power off the device. press and holde the Power button on the bottom of the device. -
Page 27: Configurations
Using the Device The Notification Area is visible across the Home screens. The icons on the left side inform you of new messages, events, alarms, and activities in progress, while the icons on the right side shows the time, signal strength, and other information. Notification Area Applications you install on your device may show their own icons in this area. - Page 28 This page is intentionally left blank. - 14 -...
