Related Manuals for Prestige PRT55FFBK
Summary of Contents for Prestige PRT55FFBK
- Page 1 Frost Free Fridge Freezer USER'S MANUAL PRT55FFSL PRT55FFSS PRT55FFW PRT55FFBK PLEASE READ THE USER S O PERATION MANUAL CAREFULLY BEFORE USING...
-
Page 2: Table Of Contents
INDEX Structure Illustration ................01 Safety information ................02 Installation ..................02 Important Safety Information...............03 Electrical Connection (UK ONLY) ............04 Instructions for use ................05 Temperature Control ................05 The Internal Light ................05 Storage of fresh food in the refrigerator ..........06 Store frozen food .................06 Freezing fresh food (Freezer) ..............06 Making ice cubes .................06... -
Page 3: Structure Illustration
STRUCTURE ILLUSTRATION 5.Drawer C/ D 1.Temperature control knob 2.Refrigerator shelf 6.Drawer B 3.Lamp switch 7.Door rack 4.Crisper Drawer 8.Bottle rack Note : Compartment design may change due to product improvement, No prior notice will be given. -
Page 4: Safety Information
This booklet contains the information you will require to install and operate your new appliance. It is important and worthwhile spending time to fully read this booklet so you will understand how to operate the appliance safely and efficiently. Please keep this booklet in a safe place so that you can refer to it when required. Safety information This information is provided in the interest of your safety. -
Page 5: Important Safety Information
IMPORTANT SAFETY INFORMATION Please ensure that the voltage marked on the rating label matches the supply voltage in your location. The rating label is located on the rear of this product. Failure to use the correct voltage will render the guarantee VOID and may damage the appliance. This appliance is intended for domestic use only;... -
Page 6: Electrical Connection (Uk Only)
ELECTRICAL CONNECTION (UK ONLY) For your safety please read the following information. Warning: This appliance must be earthed. The appliance must be connected to a 220 - 240 volts 50 cycle AC supply by means of a three pin socket, suitably earthed and should be protected by a 13 amp fuse in the plug. The appliance is supplied with a standard 13 amp 3-pin plug fitted with a 13-amp fuse. -
Page 7: Instructions For Use
Instructions for use Remove all packing materials and wash the interior of the appliance using lukewarm water containing a little bicarbonate of soda in the proportion of 1 teaspoon to 1.2 liters (2 pints) of water. Do not use detergents or soaps as they may taint the food. After cleaning, dry all parts thoroughly. -
Page 8: Storage Of Fresh Food In The Refrigerator
Storage of fresh food in the refrigerator Food should always be covered tightly with foil, plastic film, placed in bags or stored in airtight containers. This will prevent food from dehydrating and prevent the strong smell of some foods transferring to milder ones. To store raw meat wrap in polythene bags or airtight containers and place on the lowest shelf. -
Page 9: Refrigerator Defrost Process
Refrigerator defrost process The refrigerator defrosting process is carried out automatically every time the compressor stops. The defrost water drains from the cabinet into a tray placed on the top of the compressor to the rear of the unit where it evaporates. Freezer defrost process This Freezer is frost-free and does not need defrosting. -
Page 10: Reversing The Doors
Reversing the doors The doors are able to be reversed on this model. Remove Remove the hinge cover (1) and the top hinge (2). Pull Lift the refrigerator door upwards to disengage it from the middle hinge. Put the door to one side, laying it down gently on a padded surface. - Page 11 Fridge Freezer door door Remove the hinge pin that is in the bottom of the fridge and freezer door. On the other side of the fridge and freezer door, insert the replacement Remove Remove Insert hinge pin that is supplied with the Insert appliance.
-
Page 12: If The Appliance Is Not Operating Correctly
If the appliance is not operating correctly: Please check the following points. Is there a power failure? (Check by turning on a house light) Has the fuse blown or has the circuit breaker tripped. Has the door been closed correctly? Check the thermostat has been set correctly. -
Page 13: Do's And Don'ts
Do's and don'ts Do- keep raw meat and poultry below cooked food and dairy products. Do- Leave lettuce, cabbage, parsley and cauliflower on the stem. Do- Wrap cheese firstly in greaseproof paper and then in a polythene bag, excluding As much air as possible. -
Page 14: Technical Data
Technical data Brand Fridge freezer Appliance type Star rating Frequency ( Hz ) 50 Hz Light Power (Watts) Net Freezer volume Net Refrigerator Volume 122L Freezing capacity (kg/24h) 3.0kg/24h Rated Voltage ( V ) 220-240V~ Climate Class +Ambient Range Gross Weight (Kg) 67Kg Energy consumption (kWh/24h) 0.79kWh/24h... - Page 15 We apologise for any inconvenience caused by minor inconsistencies in these instructions, which may occur as a result of product improvement and development. Prestige @ is a registered trademark of Meyer Intellectual Properties Limited and is sold pursuant to a license.
