GAME AQUAQUIK 4510 Owner's Manual

Universal pool filter system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
UNIVERSAL PooL FILtER SyStEm
owNER'S mANUAL
MODELS 4510 AND 4511
ImPoRtANt
SAFEty RULES
Read all instructions BEFORE
assembling and using
this product.
KEEP THIS MANUAL.
MODEL 4511
MODEL 4510
Sand not included. USE ONLY No. 20 Silica Sand with a particle size of 0.45 mm – 0.55 mm
ImPoRtANt
Do Not REtURN PRoDUct to StoRE
For technical assistance and missing parts, call Customer Service toll-free
1.888.382.5988
(press 135 at any time)
Monday through Friday, 8 am to 5:00pm MST
Saturday, 8:00am to 1:00pm MST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQUAQUIK 4510 and is the answer not in the manual?

Questions and answers

Raishawn Stewart
August 7, 2025

When i put filter into filtration mode, water comes out of the backwash port.

0

Related Manuals for GAME AQUAQUIK 4510

Summary of Contents for GAME AQUAQUIK 4510

  • Page 1 UNIVERSAL PooL FILtER SyStEm owNER’S mANUAL MODELS 4510 AND 4511 ImPoRtANt SAFEty RULES Read all instructions BEFORE assembling and using this product. KEEP THIS MANUAL. MODEL 4511 MODEL 4510 Sand not included. USE ONLY No. 20 Silica Sand with a particle size of 0.45 mm – 0.55 mm ImPoRtANt Do Not REtURN PRoDUct to StoRE For technical assistance and missing parts, call Customer Service toll-free...
  • Page 2 SAVE THESE INSTRUCTIONS...
  • Page 3 Your AquaQuik™ Universal Pool Filter System has been engineered and manufactured to our highest standard for dependability, ease of operation and safety. With proper care, it will give you years of durable, trouble-free performance. Thank you for your purchase. PRIoR to ASSEmbLINg AND USINg thIS PRoDUct, cAREFULLy READ AND ADhERE to ALL cAUtIoN AND ImPoRtANt NotIcES LocAtED thRoUghoUt thIS mANUAL.

  • Page 4: Table Of Contents

    tAbLE oF coNtENtS 1. Safety Warnings ........5 2.

  • Page 5: Safety Warnings

    SAFEty wARNINgS READ ALL wARNINgS bELow. FAILURE to Do So coULD RESULt IN SERIoUS PERSoNAL INjURy oR DEAth. • RISK OF SUCTION ENTRAPMENT HAZARD, WHICH, IF NOT AVOIDED CAN RESULT IN SERIOUS INJURY OR DEATH. • Do not block pump suction at the pump or in the pool as this can cause severe injury or death.

  • Page 6: General Information

    gENERAL INFoRmAtIoN This manual provides information relating to the installation, utilization and maintenance of the Universal Pool Filter System. The pump included with the filtration system is a horizontal, self-priming centrifugal pump. For the pump to function correctly, the water temperature must not exceed 95°F/35°C. The filter included in the filtration system is equipped with a container drainage system, pressure gauge and built-in container components.

  • Page 7: Sand & Initial Preparation

    Sand & Initial Preparation The Universal Pool Filter System requires a specific type of sand (not included) for optimum operation: namely, Number 20 Silica Sand with a particle size of 0.45 mm - 0.55 mm. You can purchase this sand at most pool supply stores. While the sand will come packaged, it is important that the sand be cleaned prior to running the filter system in filtration mode (see Filter Operations, page 20).

  • Page 8: Parts List/Reference

    PARtS LISt/REFERENcE Before starting installation, check to make sure all parts are present in package. Primary Components BASE PLATE (1) WATER PUMP (1) FILTER TANK (1) TANK COVER / VALVE ASSEMBLY (1) TANK COVER LOCK RING ASSEMBLY (1) FILTER-PUMP HOSE (Model 4510 has threaded end) TANK SEPARATOR PLATE (1) UPPER DISTRIBUTOR (1)
  • Page 9 Parts Bag A 1 ¼”-1 ½” HOSE CONNECTOR (2) FLAT GASKET “A” (1) O-RINGS (2) A: 2 ¼ “ Dia, B: 3” Dia HAIR & LINT STRAINER COVER (1) Parts Bag B SHORT INTEX® CONNECTOR (1) LONG INTEX® CONNECTOR (1) PUMP MOUNTING HARDWARE O-RING (1) C: 1¼”...

  • Page 10: Getting Started

    gEttINg StARtED Unpacking Your Filter System This product requires assembly. Carefully remove the product and all parts. Make sure all items listed in the Parts List/Reference are included. Please note that some parts may be pre-assembled. Inspect everything carefully to make sure nothing is damaged. Do not discard packing material until you have satisfactorily operated the product.

  • Page 11: Filter Location

    Filter Location The Universal Pool Filter System needs to be located on a 2’ x 3’ completely level, hard surface lower than the pool’s water level and at least 10 feet away from the pool. The hard surface may be made of concrete, gravel, patio pavers, etc. Power Source Requirements The Universal Pool Filter System is equipped with a US standard electrical cord and plug which should only be connected to a power outlet protected by a qualified...

  • Page 12: Filter Tank Assembly

    Filter Tank Assembly 1. Place the filter tank on the base plate as shown. The feet on the bottom of the filter tank fit within the holes provided on the base plate. 2. Insert the tank separator plate inside the main tank in the guides provided. The plate divides the tank into two compartments, the Filtered Water Chamber and the Sand Filter Chamber.
  • Page 13 ImPoRtANt It is important to ensure that sand does not exceed the recommended quantity/weight. 4. Securing Filter Assembly a. Ensure the main tank seal around the top of the filter tank is in good condition and securely seated in the groove.
  • Page 14 6. Connecting Filter Hose to the Tank Tank Intake a. First lightly lubricate the tank intake port (tank intake) on the tank cover with silicone based lubricant. b. Attach the loose end of the filter- pump hose to the tank intake port on the tank cover.

  • Page 15: Connecting The Filter System

    coNNEctINg thE FILtER SyStEm The next section outlines installation instructions for connecting the Universal Pool Filter System to your pool. Since the hoses utilized for filtration and return lines differ for various types of above-ground pools, the pool-filter connection section is broken down by pool hose size and type.

  • Page 16: For Pools With 2¼" Diameter Threaded Hose Connectors

    ImPoRtANt Ensure that all HOSE connections are tight and that the hoses are NOT kinked or bent at severe angles. 4. Completed Filter-Pump Installation To Pool 4511 Return Should resemble the figure shown shown at right. From Pool Skimmer B. For Pools with 2¼” Diameter Threaded Hose Connectors These instructions assume that the pool is already assembled with hoses attached to the water intake and return ports on the pool.
  • Page 17 3. Long INTEX® Adapter Installation a. Insert o-ring “C” inside the long INTEX® adapter. b. Screw the long INTEX® adapter onto the pool return port on the tank cover. 4. Pool Return Hose Attachment a. Screw the pool return hose (inlet of pool) to the long INTEX®...

  • Page 18: Valve Operations

    VALVE oPERAtIoNS Make yourself familiar with your filter system’s valve settings and functions. Filter Valve Settings & Functions Setting Complete Water Flow/Function Valve Diagram Filtration Function: Vacuum, regular pool filter action. Position 1 This is the setting the filter will be set to most of the time.

  • Page 19: Changing Valve Positions

    Closed Function: Cleaning the hair and lint strainer. Position 5 This position stops the flow of water into the pump and filter. CAUTION: Do not run pump with valve in this position. Purge/ Function: bypass the filter. This position Drain is ideal for vacuuming pools with large Position 6 amounts of debris or after an algae treat-...

  • Page 20: Filter Operations

    FILtER oPERAtIoNS Start Up Once the filter system has been properly assembled, the sand chamber filled with sand and the hoses connected, you may begin with filtration. However, we recommend that you clean and prepare the new sand that is in the sand chamber first.

  • Page 21: Backwash Do's & Don't's

    NOTE: When the filter pump is properly connected to the power supply, the pump will begin to push the water through the bed of sand and out the backwash hose. In this process, water will be drained from your pool as it cleans the bed of sand within the tank. You may want to put a garden hose in the pool to add water in while the pump is pulling water out so that the water level does not go below the intake return ports.

  • Page 22: Adding Sand

    Adding New Sand • P rotect bottom strainer while replacing or adding sand. Fill the tank with a foot of water and cover the water chamber to avoid getting sand inside. • S tart filter in rinse mode for 1 – 3 minutes after initial start up or after adding new sand. By doing this you can avoid blowing small particles and impurities from the new sand into your pool. If some debris from the new sand does go into your pool, vacuum it up with the system in purge mode, otherwise you may keep sending it back to the pool.

  • Page 23: Troubleshooting

    11. tRoUbLEShootINg Problem Cause Solution Pressure gauge Dirty filter bed Backwash the filter has reading over (position 4) 15 psi Pressure is too Hair and lint strainer basket Clean the hair and lint is dirty strainer Air in the pump Poor seal on the intake side Tighten hose clamps and of the pump.

  • Page 24: Limited Warranty Statement

    (ii) by operation outside the usage parameters stated in the manual that shipped with the Product; (iii) by the use of parts not manufactured or sold by GAME; or (iv) by modification or service by anyone other than GAME or an authorized GAME distributor.
  • Page 25 GAME and the purchaser of the Product, superseding all prior agreements, oral or written, and all other communications between such parties relating to the Product. No employee or representative of GAME or any other party is authorized to make any warranty in addition to the limited warranty set forth above.

  • Page 26: Appendix

    13 . APPENDIx Key Part Name Game Part # For Model # 19 Valve Cover Screws V1010 BOTH 1 Valve Handle V1000 BOTH 20 Tank O-Ring T2005 BOTH 2 Valve Stem Pin V1001 BOTH 21 Upper Distributor T2006 BOTH 3 Valve Cover...

  • Page 27: Model 4511 Exploded View Parts List Diagram

    32 Filter Pump Hose P6001 / P6002 4510 / 4511 33 Hose Clamp P6003 BOTH 34 Pump Bolt Wing Nut P6004 BOTH PUMP MOUNTING HARDWARE 35 Pump Bolt Flat Water P6005 BOTH PUMP MOUNTING HARDWARE 36 Pump Bolt Lock Washer P6006 BOTH PUMP MOUNTING HARDWARE...
  • Page 28 Great American Merchandise & Events™ tel: 888.382.5988, 602.957.3825 16043 N. 82nd Street fax: 602.957.7665 Scottsdale, AZ 85260-1800 U.S.A. email: products@game-group.com www.game-group.com/retailers © 2008 GAME™ All rights reserved. Information subject to change. 4510_11 R1 INSTR (012109)

This manual is also suitable for:

Aquaquik 4511
