- Page 1 Distribution Limited Petrol Firewood Processor Operator’s Manual SSA400G FOR YOUR SAFETY READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING THIS MACHINE...
- Page 3 For the warranty to be valid the Warranty Registration Form must be completed and returned to Lumag Distribution Limited within 14 days of the purchase, together with a copy of the purchase invoice. We will use your email to confirm that we have received the completed Warranty Registration Form and contact you about any errors or omissions on the form.
- Page 5 All Other Moving Parts & Lubricate X (2) Cables 1 – First service only, 2 = Should be carried out by your Lumag Dealer, 3 = May need to be done more often in dusty areas & 4 = Replace paper element only...
-
Page 8: Table Of Contents
INSIDE Safety Instructions…………………………3-5 Identification……………………………..6 Operations………………………………….7 Inspection & Maintenance………………...8-9 Troubleshooting………………………….9-10 Specifications…………….…….…….……11 Exploded View………………………….12-13 Parts List………………………………..14-15 NOTE: Any modification to processor will void any and all warranty. - Page 9 INSIDE Safety Instructions…………………………3-5 Identification……………………………..6 Operations………………………………….7 Inspection & Maintenance………………...8-9 Troubleshooting………………………….9-10 Specifications…………….…….…….……11 Exploded View………………………….12-13 Parts List………………………………..14-15 NOTE: Any modification to processor will void any and all warranty.
-
Page 10: Safety Instructions
INSPECT √ Closely inspect all components and ensure all exterior bolts are tightened. √ Contact the freight company that delivered the unit to report delivery damage. INSPECT √ Choose a level surface to operate the firewood processor. Block the firewood processor wheels to prevent unintended √... - Page 11 OPERATION √ You must be 16 or older to operate this machine. √ Never tow or operate this processor while under the influence of alcohol, drugs or medication. √ Wear safety glasses and hearing protection, tight-fitting safety gloves and steel-toe boots. √...
- Page 12 High-pressure hydraulic fluid can inject under skin resulting in serious injury, including amputation. Ensure all fittings are tight before apply pressure. Relieve system pressure before servicing. Do not check for leaks with hand. Seek immediate medical help if skin if punctured. RISK OF FIRE &...
-
Page 13: Identification
IDENTIFICATION Key components of your Wood Processor 1. Safety Screen: Stops hydraulic operations when screen is raised. 2. Log Deck: The log deck is angled to help keep the log against the deck wall without operator assistance. 3. Coupler: Attaches the firewood processor to your vehicle. 4. -
Page 14: Operations
OPERATION 1. Preset the cut-off length using the measuring bar. Loosen the 2 wing nuts and slide the bar to the correct position. Re-tighten the wing nuts. 2. Load a log onto the log cradle and slide into processor until the end of the log touches the measuring bar. -
Page 15: Inspection & Maintenance
INSPECTION Check the following components EACH TIME the Processor is used. What HOSES Inspect for exposed wire mesh and leaks. Replace all worn or damaged hoses before starting engine. HYDRAULIC FITTINGS Inspect for cracks and leaks. Replace all damaged fittings before starting engine. NUTS&BOLTS Visually Check for loose bolts. -
Page 16: Troubleshooting
Every 10Hours of Operation √ Nuts & Bolts: Tighten all bolts, including motor mounts & large nut on hydraulic ram. √ Grease: Grease 3 conveyor bearings as well as wheel hubs and log rollers. √ Engine Oil: Check level and cleanliness use 10/30 oil. √... - Page 17 Cause Description Solution Description A- Insufficient oil to pump Check oil level in reservoir B- Air in oil Check oil level in reservoir Check pump inlet hose for blockage or C- Excessive pump inlet vacuum kinks Flush and clean the processor hydraulic D- Blocked hydraulic lines system Flush and clean the processor hydraulic...
-
Page 18: Specifications
MODEL SPECIFICATIONS Model: SSA400G Engine: 13HP Lifan gasoline engine Maximum Splitting Force: 10Ton Bar: 18in. Chain: 72section Hydraulic Oil Capacity: Max. Log Length: 55cm Max. Log Diameter: 40cm Conveyor belt width: 15cm Conveyor length: 3.2m Pump for Saw Motor: Hydraulic Cylinder Stroke:... - Page 19 Distribution Limited PART DRAWINGS FOR YOUR SAFETY READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING THIS MACHINE...
-
Page 20: Exploded View
EXPLODED VIEW... - Page 22 Model Qty. Model Qty. European head cover Coupling B Tow bar Pump bracket M12x80 Bolt M8x35 Socket head cap screw Hydraulic cylinder 3/4 Hose joint M12 Lock nut Compound gasket Φ27 Φ12Pad plate ZG1/2 Connector M12X45 Round head hex socket screw Filter Push plate G3/4-G1/2 Connector...
- Page 23 Model Qty. Model Qty. M6X35 Bolt Main frame Conveyor fixed pin Wedge spacing board Φ3 Spring pin M12X35 Bolt Bolt Block M12X110 Bolt UCFLU205 Chainsaw handle Torsional spring inner sleeve M10X50 Bolt Roller carriage supporting tube M10x30Bolt Oil filler cap M12X35 Round head hex socket screw Roller carriage Hopper A...
- Page 24 Unit 10, Hatchmoor Industrial Estate, Hatherleigh, Okehampton, Devon EX20 3LP www.lumag-gb.co.uk 01837 811741 Lumag Distribution Limited Company Number: 09267547 VAT Number: GB154566788 Hatherleigh Plant and Tool Hire is a trading name of Lumag Distribution LTD...
